HOWO 4x2 Water Tanker Fire Truck 5000L
Tanker Capacity:5000L water
Engine : 140 HP (103 kW) / YC4E140-33
Fire Pump: CB10/30
Pump Flow: 60 L/s
Monitor Range:Water ≥70 m , Foam ≥60 m
Contact Us for Better Price, Cell /Wechat /WhatsApp:+8615271357675
| Quantity: | |
|---|---|
|
| |
-
DRZ5090XFZZ
-
DRZ
-
8705309000
HOWO 4x2 Water Tanker Fire Truck 5000L
| Truck Chassis: | SINOTRUK HOWO 4x2 |
| Tanker Capacity: | 5000L water |
| Engine Power: | 140 HP (103 kW) / YC4E140-33 |
| Fire Pump: | CB10/30 |
| Pump Flow: | 30 L/s |
| Work Pressure: | 1.0 Mpa |
| Fire Monitor: | PS30 |
| Monitor Flow: | 30 L/s (1800 L/min) |
| Monitor Range: | Water ≥55 m |
4000L/5000L water tank a CB10/30 fire pump (30 L/s at 1.0 MPa), and a roof mounted PS30 fire monitor with 55m water range
This fire truck carries a full set of standard firefighting equipment including hoses, suction tubes, couplings, and a foam gun. This HOWO foam water truck works well for Class B fires involving oil, gasoline, and chemicals. It suits firefighting tasks at oil depots, chemical plants, airports, and industrial facilities across Cambodia.
Working Capacity | Engine Model | Wheelbase | HOWO 4X2 5CBM water Fire Fighting vehicle Superstructure |
4000L water + 2000L foam | 140 HP / YC4E140-33 | 3800 mm | ★ Tank carbon steel, 6000L capacity ★ CB10/30 fire pump, 30 L/s flow at 1.0 MPa ★ PS30 roof monitor, 30 L/s flow with water ≥55 m, foam ≥42 m ★ PH32 foam proportioner, mixing ratio 3%-6%, flow range 8-32 L/s |
» Ⅰ. Main Features :
★ YC4E140-33 engine rated at 140 HP for foam fire suppression and emergency response
★ HOWO 4×2 chassis with 5000L water tank and CB10/30 fire pump (30 L/s at 1.0 MPa)
★ Roof mounted PS30 monitor with 30 L/s flow, water range ≥55 m, and foam range ≥42 m for long distance fire attack
» Ⅱ.Product Parameter :
Cambodia HOWO Emergency Water Fire Rescue Truck | |||
General | Work Capacity | 5000L water | |
Truck Chassis | SINOTRUK HOWO 4x2 | ||
Engine Power | 140 HP/ YC4E140-33 | ||
Fire Pump | CB10/30 | ||
Fire Monitor | PS30 | ||
Maximum Speed | 95 km/h | ||
Overall Dimensions L*W*H | 7680*2400*2870 mm | ||
Front Axle | 2.7 ton | ||
Rear Axle | 7.2 ton | ||
Gross Vehicle Weight | 18000 kg | ||
Curb Weight | 6800 kg | ||
Engine | Engine Model | YC4E140-33 | |
Fuel Type | Diesel | ||
Power | 140 HP（103KW） | ||
Emission Standard | Euro 3 | ||
Displacement | 4257 ml | ||
Engine Type | 4 cylinders in line, water cooling, turbo-charged diesel engine, inter-cooling | ||
Chassis | Drive Type | 4x2 | |
Wheelbase | 3800 mm | ||
Tire | 235/75R17.5 16PR | ||
Cabin | Double row cab, typically allowing for a crew of 2+4 or 2+3 firefighters | ||
Tire No. | 6 tires and 1 spare tire | ||
Model | CB10/30 | ||
Flux | 30L/s | ||
Pressure | 1MPa | ||
Fire Pump | Max Working Pressure | 1.251MPa | |
Max Allowable Inlet Pressure | 0.4MPa | ||
Max Suction Height | 3m | ||
Rated Speed | 3916±50r/min | ||
Speed Ratio | 1:1.4 | ||
Water Diversion Time | ≤50s | ||
Fire Monitor | Model | PS30 | |
Flow | 30L/s | ||
Flow | 1800 liter / min | ||
Rated Working Pressure | 1.0MPa | ||
Max Working Pressure | 1.2MPa | ||
Range | Water | ≥55m | |
Foam | ≥42m | ||
Pitch Rotation | - 35～+70° | ||
Horizontal Rotation | 0～360° | ||
Foam Proportioner | Model | PH32 | |
Mixing Ratio | 3%~6% | ||
Mixing Flow Rate | 8~32L/s | ||
Structural Type | Pump-in-ring Type | ||
Standard Configuration | All standard accessories: Fire hose, filter, coupling, wrench, water /foam gun, basic tool kit, English manual…… | ||
» Ⅲ.Products Description :
1. Chassis & Powertrain
♦ SINOTRUK HOWO 4×2 chassis with 3800 mm wheelbase, designed for stable operation on urban roads and rural routes.
♦ YC4E140-33 diesel engine, rated at 140 HP, delivering reliable torque for quick response, continuous pump operation, and long-duration foam fire suppression.
♦ Manual transmission for straightforward operation and easy maintenance in remote areas.
2. Fire Suppression System
♦ 5000L water tank , carbon steel construction (304 stainless steel optional) with internal baffles to reduce liquid surge.
♦ CB10/30 fire pump, 30 L/s flow at 1.0 MPa, PTO driven, 3m suction height, ≤50s priming time.
♦ PS30 roof monitor, 30 L/s flow, water range ≥55 m, horizontal 360° rotation, pitch -35° to +70°.
» Ⅳ.Fire Pump System :
Fire Pump:
A CB10/30 fire pump with a rated flow of 30 L/s at 1.0 MPa is installed in the rear pump room. This pump is built for reliable performance, providing steady water pressure to ensure fire hoses and monitors can deliver water or foam effectively over long distances for fire suppression.
Fire Pump Model | Flow | Pressure | Max Working Pressure | Max Allowable Inlet Pressure |
CB10/30 | 30L/s | 1.0MPa | 1.251 MPa | 0.4MPa |
Foam Proportioner:
PH32 pump-in-ring type foam proportioner, mixing ratio adjustable from 3% to 6%, flow range 8-32 L/s. Automatically mixes foam concentrate with water for efficient Class B fire suppression. Simple operation with no external power required.
Control panel:Includes operating instructions, tank piping diagram, pressure gauge, water level gauge, foam level gauge, emergency stop, PTO control, main power switch, pump controls, and compartment lighting. All controls are clearly marked for straightforward operation.
» Ⅴ.Fire Monitor System :
The PS30 fire monitor is mounted on the cab roof. It delivers a flow rate of 30 L/s with a water range of ≥55 m and a foam range of ≥42 m. The monitor supports both straight stream and spray patterns for flexible firefighting operations.
Fire Monitor Model | Flow | Range | Rated Pressure | Pitch Rotation | Horizontal rotation |
PS30 | 30L/s | Water≥55m | 1.0MPa | -35°～+70° | 0～360° |
» Ⅵ.Firefighting Equipment :
• Pump Room: Equipped with CB10/30 fire pump, control panel, pressure gauge, vacuum gauge, and lighting system. Accessories include fire hoses, suction hoses, collectors, strainers, fire nozzles, foam guns, suction hose wrenches, and reducers.
The HOWO emergency foam fire rescue truck comes with a rear-mounted CB10/30 fire pump and a cab top PS30 monitor. The water tank holds 5,000 liters, sitting on a sturdy HOWO 4×2 chassis powered by a 140 HP YC4E140-33 engine. Standard gear includes fire hoses, suction tubes, couplings,
Full specifications are listed below:
NO | Item | Unit |
1 | Water Suction Pipe (Suction hose Ø 125 mm, length: 4 m) | 2 PC |
2 | Water strainer (Ø 125) | 1 PC |
3 | Water segregator (Ø 80-65-65 mm) | 1 PC |
4 | Water collector (Ø 125-65-65 mm) | 1 PC |
5 | Soft-wall fire hose (Water hose Ø 65 mm, length: 20 m) | 6 SET |
6 | Soft-wall fire hose (Water hose Ø 80 mm, length: 20 m) | 4 SET |
7 | Fast conversion joint (80X65 mm) | 2 PC |
8 | Hose protector | 4 PC |
9 | Hose Hoist | 4 PC |
10 | Ground Hydrant-wrench | 1 PC |
11 | Underground Hydrant-wrench | 1 PC |
12 | Suction Wrench | 2 PC |
13 | Dry Powder Extinguisher | 1 PC |
14 | Fire Fighting Barrel | 1 PC |
15 | Straight flow switch water gun (Ø 65 mm) | 1 PC |
16 | Multi-purpose switch water gun | 1 PC |
17 | Fire Fighting Axe | 1 PC |
18 | Fire Fighting Shovel/Spade | 1 PC |
19 | Fire Axe | 1 PC |
20 | 4M Aluminum Ladder (Optional 10M Aluminum Ladder) | 1 PC |
21 | Original Chassis Tools | 1 PC |
22 | Protective (safety) spectacles | 1 PC |
