SITRAK Emergency Accident Rescue Vehicles
445HP
| FOB: | |
|---|---|
| Quantity: | |
|
| |
-
DRZ5
-
DONG RUN ZE
-
870590
GB17691-2005 National
SITRAK Emergency Accident Rescue Vehicles
SITRAK Emergency Rescue Truck
Technical specifications
| # | Engine model | Engine displacement | Engine power | Engine manufacturer | |||
|---|---|---|---|---|---|---|---|
| 1 | MC11.40-50 | 10 518 cc | 10.5 L | 642 cu in | 297 kW | 404 hp | China National Heavy Duty Truck Group Co., Ltd. (Sinotruk) |
| 2 | MC11.44-50 | 10 518 cc | 10.5 L | 642 cu in | 327 kW | 445 hp | China National Heavy Duty Truck Group Co., Ltd. (Sinotruk) |
| Performance | ||||
|---|---|---|---|---|
| Fuel | diesel fuel | |||
| Environmental standard | GB17691-2005 Euro 5, | |||
| Maximum speed | 90 km/h | 56 mph | ||
| ABS | have | |||
| Capacity | ||||
|---|---|---|---|---|
| Rated load capacity | 8410 kg | 8.4 t | 18,541 lbs | |
| Weights and Ground pressure | ||||
|---|---|---|---|---|
| Curb weight | 16460 kg | 16.5 t | 36,288 lbs | |
| Gross vehicle weight rating | 25000 kg | 25 t | 55,000 lbs | |
| Axle load distribution | 7000 kg / 18000 kg 7 t / 18 t 15,000 lbs / 40,000 lbs | |||
| Dimensions | ||||
|---|---|---|---|---|
| Overall length | 10010 mm | 32′11″ | ||
| Overall width | 2500 mm | 8′3″ | ||
| Overall height | 3760 mm | 12′5″ | ||
| Undercarriage and Suspension | ||||
|---|---|---|---|---|
| Number of axles | 3 | |||
| Wheelbase | 4325+1350 mm, 4300+1400 mm, 4625+1350 mm, 4600+1400 mm, 5225+1350 mm, 5200+1400 mm | 14′3″+4′6″, 14′2″+4′8″, 15′3″+4′6″, 15′2″+4′8″, 17′2″+4′6″, 17′1″+4′8″ | ||
| Front track | 2022 mm, 2041 mm | 6′8″, 6′9″ | ||
| Rear track | 1830 mm / 1830 mm | 6′1″ / 6′1″ | ||
| Front overhang | 2370 mm | 7′10″ | ||
| Rear overhang | 1940 mm | 6′5″ | ||
| Angle of approach | 9° | |||
| Angle of departure | 16° | |||
| Leaf springs | 4 / 5, 4 / 12, 4 / -, 10 / 12 | |||
| Tyres and Wheels | ||||
|---|---|---|---|---|
| Number of tyres | 10 | |||
| Tyres dimension | 12.00R20 14PR, 315/80R22.5 16PR | |||
| Miscellaneous | ||||
|---|---|---|---|---|
| Seating capacity | 2 | |||
| Steering control | steering wheel | |||
Emergency rescue for industry:
Gas emergency rescue heating emergency repair municipal pipe network project
Flood control and drainage emergency power generation rescue mine rescue project
Fire emergency rescue road emergency rescue communication emergency repair project
Highway rescue earthquake emergency rescue water supply power emergency
Iv. Product features and functions
1. Scope of application
The product is the only new type of emergency rescue vehicle specially developed in China for the technical cooperation with German units such as gas, heat supply, water supply, municipal, electric power, fire control, flood control, earthquake relief and expressway.
2. Functions that can be realized after modification
1) integrated emergency equipment tool transport function
The equipment cabinet adopts the aluminum alloy profile imported from Germany. The equipment on both sides of the equipment can be adjusted according to the size of the equipment.
2) emergency function
Equipped with a variety of emergency tools in the car, while providing temporary heating, emergency rescue launched
3) power supply function
A separate cummins 50KW generator set can provide 380V and 220v power.
4) all-round lighting
Vehicle configuration 2 lift lighting systems, of which a set of camera system, lighting lamp holder can rise by 2.4 meters, 360 ° rotating yuntai,
A set of mast lifting lighting provides lighting.
5) vehicle balance
Equipped with hydraulic support leg system, keep the vehicle balanced and stable when using the vehicle.
6) warning lights
The head of the car is equipped with a long row of warning lights, an alarm, and a flash module on the side, which serves as a warning.
7) safety function
The system has the technical support of lightning protection, fire protection and electricity utilization.
The body is equipped with grounding, lightning protection and 2 bottles of dry ice fire extinguisher to ensure the safety of the vehicle
Equipped with first aid medical kit to provide emergency personnel with the function of self-rescue
8) integrated control of electrical appliances
All electric equipment control systems of the vehicle are centralized in the side control console of the vehicle.
Heat supply intelligent control system is also provided
9) network data transmission function
Equipped with hard disk video recorder, wireless network, can carry out field monitoring, data transmission, image, etc
