SITRAK YT 42M Aerial Ladder Fire Fighting Truck

Share to:

SITRAK YT 42M Aerial Ladder Fire Fighting Truck

SITRAK YT 42M Aerial Ladder Fire Fighting Truck
42m ladder, fire cannon Pump Flow 50L/s
Water Tank 3700L, Foam Tank :1500L
Price for refer only. Final Price Offer Discount.

Price: $ 423000

Availability:

Quantity:

Model:
SXT5330JXFYT42
Brand:
DONG RUN ZE
Code:
8705301000

Product Description

SITRAK YT 42M Aerial Ladder Fire Fighting Truck

42m ladder, fire cannon Pump Flow 50L/s

Water Tank 3700L, Foam Tank :1500L

Chassis Sinotruck : ZZ5357TXFV464MF1

Aerial ladder fire trucks (189) Aerial ladder fire trucks (147)

Main technical parameters

Overall dimensions:	12258×2540×4000(mm)	Fuel Type:	Diesel oil
Total mass:	32600(Kg)
Net	27250(Kg)	Rated load mass:	5200(Kg)
Approach Angle/Departure Angle:	13/9 (°)	Front/rear overhang:	1500/2940(mm)
Axle Load:	7200/12700/12700	Wheelbase:	4300+1400,4325+1350,4600+1400,4625+1350,4800+1400,4825+1350,5200+1400,5225+1350,5800+1400,5825+1350,4925+1350,4900+1400(mm)
Number of shafts:	3	Maximum speed:	95(km/h)
Number of tires:	10(PCS)	Tire	385/65R22.5/315/80R22.5 18PR,385/65R22.5/12.00R20 18PR
Fuel consumption:	(L/100Km)	Number of spring pieces:	10/12,4/12,4/5,4/-/-,11/12
Front wheel base:	2110(mm)	Rear wheel base:	1830/1830,1850/1850(mm)

Aerial ladder fire trucks (149) Aerial ladder fire trucks (150)

Engine type	Engine manufacturer	Volume (ml)	Power (kw)
MC13.48-60; MC13H.57-61; MC13.50-61; MC11.46-61; MC11.43-61; MC13H.60-61; MC13.50-60; MC11.44-60; MC11.40-60; MC13.54-61; MC11.40-61; WP10.5 H430E62; WP10.5 H460E62; MC11H.46-61; MC11H.49-61; WP12.460 E62; WP10H400E62	China Heavy Duty Automobile Group Co., LTD.; Weichai Power Co., Ltd.	12419; 13020; 12419; 10518; 10518; 13020; 12419; 10518; 10518; 12419; 10518; 10520; 10520; 11050; 11050; 11596; 9500	356; 422; 371; 341; 319; 444; 371; 327; 297; 400; 297; 316; 338; 341; 363; 338; 294
The total volume of the tank is 5.200 cubic meters, the volume of the tank is 3.700 cubic meters, the size of the tank is 1425×2430×1120mm, the volume of the foam tank is 1.500 cubic meters, the size of the foam tank is 575×2430×1120mm. Integrated side and rear protection structure, rear protection height from the ground :475mm. Forward :1680mm, extension :138mm.ABS manufacturer is WABCO (Shanghai) Management Co., LTD.,ABS model is 4460046300, the main special equipment are fire pump, fire cannon, boom.
