Sanitary Hose， Vaccum Hose ，Sewage Hose， Acid Hose ，Septic Hose
Sanitary Hose， Vaccum Hose ，Sewage Hose， Acid Hose ，Septic Hose Black rubber hose reinforced spring pvc hose
Price: $ 20.6 - 56.25
Discount Price: $ 13.5 - 37.5
| FOB: | |
|---|---|
| Quantity: | |
|
| |
-
OEM
-
OEM
-
8708996000
Sanitary Hose， Vaccum Hose ，Sewage Hose， Acid Hose ，Septic Hose Black rubber hose reinforced spring pvc hose
| Item No. | British size | Working Pressure | Bursting Pressure | Metric size | Thickness | Length | Weight | Volume D×H | ||
| I.D. | O.D. | |||||||||
| Inch | Inch | Mpa | Mpa | Mpa | mm±0.2 | mm | m | kg/roll±0.1 | mm | |
| SWH6 | 1/4" | 0.8 | 7 | 1.6 | 6 | 11 | 2.5 | 100 | 11 | 410×190 |
| SWH8 | 5/16" | 0.8 | 6 | 1.6 | 8 | 13 | 2.5 | 100 | 14 | 430×200 |
| SWH9 | 3/8" | 0.8 | 5.5 | 1.5 | 9 | 15 | 3 | 100 | 18 | 480×230 |
| SWH12 | 1/2" | 0.6 | 4 | 1.5 | 12 | 18 | 3 | 100 | 22 | 580×240 |
| SWH15 | 5/8" | 0.6 | 3.5 | 1.3 | 15 | 22 | 3.5 | 100 | 31 | 600×160 |
| SWH19 | 3/4" | 0.5 | 3 | 1.2 | 19 | 26 | 3.5 | 100 | 19 | 680×200 |
| SWH25 | 1 | 0.4 | 2.5 | 1 | 25 | 33 | 4 | 50 | 27.5 | 740×180 |
| SWH32 | 1-1/4" | 0.4 | 2 | 0.9 | 32 | 41 | 4.5 | 50 | 31.6 | 820×180 |
| SWH38 | 1-1/2" | 0.4 | 1.8 | 0.8 | 38 | 48 | 5 | 50 | 40.5 | 900×210 |
| SWH45 | 1-3/4" | 0.4 | 1.7 | 0.8 | 45 | 56 | 5.5 | 50 | 53.5 | 930×280 |
| SWH48 | 1-7/8" | 0.4 | 1.6 | 0.7 | 48 | 59 | 5.5 | 40 | 56 | 940×300 |
| SWH50 | 2" | 0.4 | 1.6 | 0.7 | 50 | 62 | 6 | 30 | 63 | 1000×350 |
| SWH60 | 2-3/8" | 0.4 | 1.5 | 0.7 | 60 | 74 | 7 | 50 | 86 | 1050×150 |
| SWH64 | 2-1/2" | 0.4 | 1.5 | 0.5 | 64 | 78 | 7 | 50 | 94 | 1100×160 |
| SWH76 | 3" | 0.4 | 1.3 | 0.5 | 76 | 90 | 7 | 50 | 55.5 | 1300×200 |
| SWH90 | 3-1/2" | 0.4 | 1.2 | 0.5 | 90 | 106 | 8 | 40 | 70 | 1400×220 |
| SWH100 | 4" | 0.35 | 1 | 0.5 | 100 | 116 | 8 | 30 | 88 | 1600×300 |
| SWH127 | 5" | 0.35 | 1 | 0.5 | 127 | 141 | 7 | 30 | 100 | 1440×430 |
| SWH152 | 6" | 0.35 | 1 | 0.5 | 152 | 166 | 7 | 30 | 120 | 1700×430 |
| SWH200 | 8" | 0.35 | 1 | 0.5 | 200 | 220 | 10 | 30 | 100 | 1500×210 |
Sanitary Hose， Vaccum Hose ，Sewage Hose， Acid Hose ，Septic Hose Black rubber hose reinforced spring pvc hose
| Item No. | British size | Working Pressure | Bursting Pressure | Metric size | Thickness | Length | Weight | Volume D×H | ||
| I.D. | O.D. | |||||||||
| Inch | Inch | Mpa | Mpa | Mpa | mm±0.2 | mm | m | kg/roll±0.1 | mm | |
| SWH6 | 1/4" | 0.8 | 7 | 1.6 | 6 | 11 | 2.5 | 100 | 11 | 410×190 |
| SWH8 | 5/16" | 0.8 | 6 | 1.6 | 8 | 13 | 2.5 | 100 | 14 | 430×200 |
| SWH9 | 3/8" | 0.8 | 5.5 | 1.5 | 9 | 15 | 3 | 100 | 18 | 480×230 |
| SWH12 | 1/2" | 0.6 | 4 | 1.5 | 12 | 18 | 3 | 100 | 22 | 580×240 |
| SWH15 | 5/8" | 0.6 | 3.5 | 1.3 | 15 | 22 | 3.5 | 100 | 31 | 600×160 |
| SWH19 | 3/4" | 0.5 | 3 | 1.2 | 19 | 26 | 3.5 | 100 | 19 | 680×200 |
| SWH25 | 1 | 0.4 | 2.5 | 1 | 25 | 33 | 4 | 50 | 27.5 | 740×180 |
| SWH32 | 1-1/4" | 0.4 | 2 | 0.9 | 32 | 41 | 4.5 | 50 | 31.6 | 820×180 |
| SWH38 | 1-1/2" | 0.4 | 1.8 | 0.8 | 38 | 48 | 5 | 50 | 40.5 | 900×210 |
| SWH45 | 1-3/4" | 0.4 | 1.7 | 0.8 | 45 | 56 | 5.5 | 50 | 53.5 | 930×280 |
| SWH48 | 1-7/8" | 0.4 | 1.6 | 0.7 | 48 | 59 | 5.5 | 40 | 56 | 940×300 |
| SWH50 | 2" | 0.4 | 1.6 | 0.7 | 50 | 62 | 6 | 30 | 63 | 1000×350 |
| SWH60 | 2-3/8" | 0.4 | 1.5 | 0.7 | 60 | 74 | 7 | 50 | 86 | 1050×150 |
| SWH64 | 2-1/2" | 0.4 | 1.5 | 0.5 | 64 | 78 | 7 | 50 | 94 | 1100×160 |
| SWH76 | 3" | 0.4 | 1.3 | 0.5 | 76 | 90 | 7 | 50 | 55.5 | 1300×200 |
| SWH90 | 3-1/2" | 0.4 | 1.2 | 0.5 | 90 | 106 | 8 | 40 | 70 | 1400×220 |
| SWH100 | 4" | 0.35 | 1 | 0.5 | 100 | 116 | 8 | 30 | 88 | 1600×300 |
| SWH127 | 5" | 0.35 | 1 | 0.5 | 127 | 141 | 7 | 30 | 100 | 1440×430 |
| SWH152 | 6" | 0.35 | 1 | 0.5 | 152 | 166 | 7 | 30 | 120 | 1700×430 |
| SWH200 | 8" | 0.35 | 1 | 0.5 | 200 | 220 | 10 | 30 | 100 | 1500×210 |
