Shacman 10 wheels water Tanker Vehicle 4000 -5000gallon

Shacman 10 wheels water Tanker Vehicle 4000 -5000gallon SHACMAN 20m3 6x4 LHD Water Tanker Truck
Price: $ 46000  -  59000
Discount Price: $ 42840  -  51840
FOB:
Availability:
Quantity:

  • DRZ5257GSSFS

  • Shacman

  • 8705909990

SHACMAN 4000 Gallon Water Wagon Trucks


1. Chassis model: SX1257;

2. Drive System: 6x4;

3. Overall Dimensions: 9935× 2490× 3210mm;

4. Tank volume: 20000L;

5. Cab: F2000 mid-long flat roof cab, single bed, A/C, manual window machine;

6. Engine:   WEICHAI ), EURO 3/4/5 emission standard;

7. Horsepower: 290HP; 340HP,380HP

8. Gearbox: FAST Fuller 9JS119, 9+1 shifts;

9. Clutch: 430 Diaphragm type;

10. Steering: ZF technology;

11. Front axle: MAN 7.5T with drum brake;

12. Rear axle: 13Ton STR casting axle, final ratio 5.73

13. Tyre: 12.00-20;

14. Oil tank: 380L.

15. With power takeoff

           SHACMAM WATER TANK TRUCK ,SPRINKLER

  Traction type:

 6x4

  Cabin:

MAN cab extra lengthened extra width

Normal roof. USB devices.

  Engine brand:

Steyr (Weichai)

  Engine model:

WD615.50

  Engine type:

Diesel 4 stroke direct injection engine, 6 cylinder in

line with water cooling,turbo  charging & intercooling

  Displacement:

9.726 liters

  Max. Output:

280HP@2200rpm

  Max torque:

1160NM@1100 -1600rpm

  Bore/Stroke(mm):

126/130

  Mean Position Speed:

9.53m /s

  Specific fuel consumption:

198g /Kwh

  Engine brake:

WEVB(Weichai Exhaust Valve Brake)

  Gear box:

Fuller 9 speeds (9JS119)

  Clutch:

D430 diaphragm single plate type

  Steering:

ZF technology

  Front axle:

MAN tech. Front axle

  Rear axle:

Steyr strengthened axle(punching welding axle housing, double Reduction driving axle,

 inter wheel differential and differential lock)

  Frame:

300mmx80mmx 8mm(inner: 275mm*70mm*5 mm )

  Spring suspension:

9/12, 10/12

Fuel consumption(L/100km )

36

  Fuel tank capacity (L):

380

  Max. Speed (km/h):

77

  Max. Gradeability(%):

28

  Kerb. Mass:

10900 kg

  Total mass:

25000kg

  Wheel base (mm):

4325+1350

 Front overhang (mm):

1525

 Rear overhang (mm):

2625

 Rear track (mm):

1800

 Approach angle:

16 degree

 Departure angle:

17 degree

 Dimension (mm):

9825x2490x3400

 Want tank:

18 CBM

 Thickness of steel:

5mm

 Thickness of end:

6mm

  Rear spraying

(40CBM/H)

Shacman 6x4 type 270hp-370hp mobile water tanker transport truck 20000 liter


 F2000 Shacman  water Tanker Vehicle 28000L-30000L/5000 -6000gallon

Overall dimensions 12000X2490X3340mm Curb weight 14170kg
Tank dimensions 8200×2300×1535mm Tank volume 30000L

Chassis parameters
Chassis model SX1315NN4561 Chassis brand SHACMAN
Overall dimensions 11850x2490x3270mm Wheel base 1800+4575+1400mm
Front/rear wheel track 1939/1939/1800/1800mm Front/rear suspension 1525/2575mm
Approach/departure angle 18/12° Maximum speed 99km/h
Chassis Manufacturer Shanxi Automobile Group Co., Ltd.
Cab Configuration Delong F2000/ F3000 long a row and a half deluxe cab(with sleeping berth),allowable 3 passengers, electronically controlled automatic constant temperature air conditioner, electric rocking window machine, ordinary air filter, air master seat, four point airbag ,traveling data recorder
Color White ,other color is optional
Engine Model WP10.270E31
Emission Euro 3
Type 6 cylinders,in-line,4-stroke,water-cooled,turbo inter-cooling, exhaust valve brake, direct injection diesel engine
Rated power 270hp,rated power speed 2200rpm
Displacement 9726ml
Bore x stroke 108×130mm
Manufacturer Weichai Power Co., Ltd.
Tire Size 11.00R20 steel wire tire
Number 12+1 nos
Clutch φ430 diaphragm clutch
Frame 850 × 300 (8 + 5)mm
Fuel tank 400L aluminum alloy + fuel anti-theft alarm device
Front axle MAN, 5.5 tons
Rear axle MAN,13 tons single level, main reduction ratio 4.111
Drive form 8X4
Suspension Multi leaf springs
Rated voltage 24V,DC
Transmissions gearbox 9JS119B, 9 speed forward 1 reverse.
Steering device Power assisted steering, steering machine (domestic ZF technology)
Steering wheel Left hand drive
Selective configuration central control door lock,600L aluminum alloy fuel tank, driving room electric flip, engine 300hp,engine 340hp
If there is a slight change in the chassis parameters above, please take the actual product as the standard

Water tank structure
Tank dimensions 8200×2300×1535mm Tank volume 30000L
Tank material Carbon steel Tank thickness 5mm
Nozzle sprinkling width ≥14m Range of water cannon ≥28m
Suction height ≥7m Color and Logo Optional


Item

unit

parameter

Overall   dimensions

mm

11980X2490X3720


Fact cubage

L

28000

GVW

kg

40000

Rated loading weight

kg

28000

Curb weight

kg

11870

Body internal dimensions

mm

9500*2300*900

Wheel base

1800+4500+1350

F/R track base

1939/1939, 2036/2036

Approach/departure angle

°

28/18

Exhaust/kw

ml/kw

10800/283

Max speed

km/h

80

Tire   specification

12.00R20 18PR

Traction   system

8X4

transmission

manual transmssion, 8-speed

Number   of axles

4

Electric system

24v

Operation   control system

Electrically hydraulic control

Allowable passengers in cab

3

Engine

Xian cummins engine company LTD

Production   cycle

10-15 days

Warranty

12 month,from the date of supply


Shacman F2000 8X4 water tank truck  water fire truck sprinkler 5000 gallon-Euro 3


Item

unit

parameter

Overall   dimensions

mm

11910X2500X3670


Fact cubage

L

15000--30000

GVW

kg

44500

Curb weight

kg

14500

Rated loading weight

kg

30000

Body internal dimensions

mm

9250*2460*1550

Wheel base

1800+3200+1350

F/R track base

1939/1939  1850/1850

Approach/departure angle

°

28/20

Exhaust/kw

ml/kw

11596/316

Max speed

km/h

92

Tire   specification

12.00R20 18PR

Traction   system

8X4

transmission

Manual transmission, 12-speed

Number   of axles

4

Electric system

24v

Operation   control system

Electrically hydraulic control

Allowable passengers in cab

3

Equipment

Equipped with front(rear,side)sprinkler(sprinkling width>14m )

Equipped with rear working platform with water   cannon (range>28m)

Equipped with WL pump(suction lift>6m)

Equipped with fire valve,water valve,and   filter gauze

Engine

Weichai wp12.375n

Production   cycle

10-15 days

Warranty

12 month,from the date of supply



  • Water Truck,Shacman 30000L Water Truck,Shacman 30000L Water Bowser,Shacman 30000L Spraying Truck,Shacman 30000L water tank lorry,Shacman 30000L Water Cart,Shacman 30000L  Water Tanker, Shacman 30000L Water Wagon,Shacman 30000L Water Tanker Truck,Shacman 30000L Water Sprinkler Truck,Shacman 30000L Watering Vehicle,Shacman 30000L Watering Cart

  • ------------------

    F2000 Shacman 10 wheels water Tanker Vehicle 20000L

Overall dimensions 9935X2490X3210mm Curb weight 11880kg
Tank dimensions 6600×2490×1535mm Tank volume 20000L


Chassis parameters
Chassis model SX1255NN464 Chassis brand SHACMAN
Overall dimensions 10299X2490X3270mm Wheel base 4575+1400mm
Front/rear wheel track 2011/1800/1800mm Front/rear suspension 1525/2824mm
Approach/departure angle 18/11° Maximum speed 99km/h
Chassis Manufacturer Shanxi Automobile Group Co., Ltd.
Cab Configuration Delong F3000 long a row and a half deluxe cab(with sleeping berth),allowable 3 passengers,electronically controlled automatic constant temperature air conditioner,electric rocking window machine,  ordinary air filter,traveling data recorder
Color White,other color is optional
Engine Model WP10.290E32
Emission Euro 3
Type 6 cylinders,in-line,4-stroke,water-cooled,turbo inter-cooling, exhaust valve brake, direct injection diesel engine
Rated power 290hp,rated power speed 2200rpm
Displacement 9726ml
Max.torque 1160N.m
Bore x stroke 126x130mm
Manufacturer Weichai Power Co., Ltd.
Tire Size 12.00R20 steel wire tire
Number 10+1 nos
Clutch φ430 diaphragm clutch
Frame 850 × 300 (8 + 7)mm
Fuel tank 400L aluminum alloy + fuel anti-theft alarm device
Front axle MAN, 7.5 tons
Rear axle MAN,13 tons casting bridge,main reduction ratio 5.262
Drive form 6X4
Suspension Multi leaf springs, four bolts
Rated voltage 24V,DC
Transmissions gearbox 9JS119, 9 speed forward 1 reverse.
Steering device Power assisted steering,steering machine (domestic ZF technology)
Steering wheel Left hand drive
Selective configuration central control door lock,600L aluminum alloy fuel tank,driving room electric flip,engine 310hp,engine 340hp
If there is a slight change in the chassis parameters above,please take the actual product as the standard

Water tank structure
Tank dimensions 6600×2490×1535mm Tank volume 20000L
Tank material Carbon steel Tank thickness 5mm or stainess steel
Nozzle sprinkling width ≥14m Range of water cannon ≥28m
Suction height ≥7m Color and Logo Optional
Standard configuration Chassis, sub frame, carbon steel water tank, manhole, water pump, front/side/rear spray nozzle,rear working platform,water cannon,fire valve, water valve, filter gauze,water hose, climbing ladder.
Selective configuration Stainless steel/aluminum alloy water tank,insulation layer for water tank,stainless steel water pump, fire pump, fire gun,pesticide plate, cabin gas control operated, Honda pumps, lights, crane, hanging basket, rear spraying device, barrel pesticide spraying device, gasoline pesticide machine, diesel pesticide machine, LED arrow lights
Extended model water transporting truck, thermal insulation water transporting truck, drinking water tank truck, liquid food truck, fire water tank truck, pesticide spraying truck,and etc.


Customization, Cost and Control Built How You Want it, at a Price You Can Afford. for sale call:+86-152 -7135-7675



 -----Fuel tank truck

 -----Refuel tanker

 -----Edible oil tank truck

 -----Insulation oil tanker truck

 -----Crude oil transport tank truck

 -----Fuel tank full trailer

 -----Fuel tank semi trailer

 -----Mild steel oil tanker

 -----Stainless steel oil tank

 -----Aluminum fuel tank

 -----Fuel tank container

 -----Mobile refueling station

 -----Horizontal storage fuel tanker

 -----RHD fuel tank truck

 And more customized products.

 All more details of fuel tank truck, please kindly contact with us.
