FOTON 10 wheels water tanker 12000L Phaser 160HP /180HP LHD / RHD

Overall dimensions 9000×2490×3150mm Curb weight 6500kg
Tank dimensions 5100×2150×1400mm Tank volume 12000L

Phaser 160HP Chassis parameters
Chassis model BJ1163VKPGG-1 Chassis brand FOTON
Overall dimensions 8805x2364x2760mm Wheel base 5000mm
Front/rear wheel track 1900/1800mm Front/rear suspension 1365/2440mm
Approach/departure angle 20/10° Maximum speed 90km/h
Chassis Manufacturer Beijing Foton Daimler Motor Co., Ltd.
Cab Configuration A row and a half cab(with sleeping berth),allowable 3 passengers, ETX2200 flat top,air conditioner
Color Red, other color is optional
Engine Model Phaser160Ti-33
Emission Euro 3
Type 6 cylinders,in-line,4-stroke,water-cooled,turbo inter-cooling, direct injection, dry cylinder liner,diesel engine,
Rated power 160hp,rated power speed 2500rpm
Displacement 5990ml
Max. torque 560N.m
Bore x stroke 100x127mm
Manufacturer Tianjin Lovol Engine Co., Ltd
Tire Size 9.00R20 steel wire tire
Number 6+1 nos
Fuel tank 200L aluminum alloy
Rear axle 8.0 tons
Drive form 4X2
Rated voltage 24V,DC
Transmissions Datong 6 speed forward 1 reverse
Steering device Power assisted steering
Steering wheel Left hand drive
Selective configuration Engine 190hp,8 speed forward 1 reverse, rear axle 9.0 tons
If there is a slight change in the chassis parameters above, please take the actual product as the standard

Phaser 180HP Chassis parameters
Chassis model BJ5163GLFFG-S Chassis brand FOTON
Overall dimensions 8305X2330X2700mm Wheel base 4700mm
Front/rear wheel track 1900/1800mm Front/rear suspension 1365/2240 mm
Approach/departure angle 16/11° Maximum speed 79km/h
Chassis Manufacturer Beijing Foton Daimler Motor Co., Ltd.
Cab Configuration ETX2200cab(with sleeping berth),allowable 3+2 passengers, ETX interior, air conditioner, machinery seat
Color White, other color is optional
Engine Model Phaser180Ti-30
Emission Euro 3
Type 6 cylinders,4 stroke, in-line, direct injection, dry cylinder liner, diesel engine
Rated power 180hp
Displacement 5990ml
Manufacturer Beijing Foton Cummins Engine Co. Ltd.
Tire Size 10.00-20 nylon tire
Number 6+1 nos
Fuel tank 200L aluminum fuel tank
Clutch Φ380 diaphragm clutch
Front axle 5 tons
Rear axle 10 tons
Drive form 4X2
Suspension Multi leaf springs
Rated voltage 24V,DC
Transmissions Gear box F6J95T, 6 speed forward 1 reverse.
Steering device Power assisted steering
Steering wheel Left hand drive
Selective configuration
If there is a slight change in the chassis parameters above, please take the actual product as the standard

Water tank structure
Tank dimensions 5100×2150×1400mm Tank volume 12000L
Tank material Carbon steel Tank thickness 4/5mm
Nozzle sprinkling width ≥14m Range of water cannon ≥28m
Suction height ≥7m Color and Logo Optional

 Forland 4x2 6000L water truck

Overall dimensions 7225X2300X2680mm Curb weight 4240kg

Tank dimensions 4000×1980×1090mm Tank volume 6000L

Chassis parameters
Chassis model BJ1102VDPEA-G1 Chassis brand FOTON
Overall dimensions 6970x2240x2450mm Wheel base 3900mm
Front/rear wheel track 1750/1654mm Front/rear suspension 1175/1895mm
Approach/departure angle 29/22° Maximum speed 80km/h
Chassis Manufacturer BEIQI FOTON MOTOR CO.,LTD
Cab Configuration G1863B single cab, allowable 3 passengers, with warm air, all English signs in car body, English instruction , international general accessories, double front windshield, power switch
Color White, other color is optional
Engine Model 4102QBZL
Emission Euro 2
Type 4 cylinders, in-line, vertical type, turbo-charging, air-to-air inter-cooling, liquid-cooled diesel engine
Rated power 130hp,rated power speed 3000rpm
Displacement 3760ml
Max. torque 290N.m
Bore x stroke 102x115mm
Manufacturer Kunming Yunnei Power Co., Ltd
Tire Size 8.25-16 Double Star nylon tire
Number 6+1 nos
Brake Air break
Fuel tank 120L iron
Front axle 1061 front axle
Rear axle 1092 rear axle
Drive form 4X2
Rated voltage Camel brand,24V,DC
Transmissions 5 speed forward 1 reverse
Steering device Power assisted steering
Steering wheel Left hand drive
Selective configuration Steel wire tire, air conditioner
If there is a slight change in the chassis parameters above, please take the actual product as the standard
Water tank structure parameters
Tank dimensions 4000×1980×1090mm Tank volume 6000L
Tank material Carbon steel Tank thickness 4/5mm
Nozzle sprinkling width ≥14m Range of water cannon ≥28m
Suction height ≥7m Color and Logo Optional

  Foton 4x2 5000L water spray truck LHD / RHD

Overall dimensions 5990X1955X2300mm Curb weight 3200kg
Tank dimensions 3500×1700×1280mm Tank volume 5000L
Chassis parameters
Chassis model BJ1073VEJEA-A Chassis brand FOTON
Overall dimensions 5875x1915x2150mm Wheel base 3360mm
Front/rear wheel track 1415/1485mm Front/rear suspension 1085/1430mm
Approach/departure angle 23/19° Maximum speed 95km/h
Chassis Manufacturer BEIQI FOTON MOTOR CO.,LTD
Cab Configuration D1695 single row cab, allowable 2 passengers, with warm air, all English signs in car body, English instruction ,international general accessories, double front windshield, power switch
Color White, other color is optional
Engine Model 4DW91-63NG2 /4DW92-73
Emission Euro 2
Type 4 cylinders, in-line, turbo charger, diesel engine
Rated power 65HP-78hp
Displacement 2545ml
Bore x stroke 90x100mm
Manufacturer Wuxi Diesel Engine Branch
Tire Size 6.50-16 Double star nylon tire
Number 6+1 nos
Fuel tank 70L iron oil tank
Rear axle 4.0 tons
Drive form 4X2
Rated voltage Camel brand,24V,DC
Transmissions 5 speed forward 1 reverse
Steering device Steering wheel
Steering wheel Right hand drive RHD
Selective configuration Steel wire tire, air conditioner
If there is a slight change in the chassis parameters above, please take the actual product as the standard

Water spray truck structure
Tank dimensions 3500×1700×1280mm Tank volume 5000L
Tank material Carbon steel Tank thickness 4/5mm
Nozzle sprinkling width ≥14m Range of water cannon ≥28m
Suction height ≥7m Color and Logo Optional
Standard configuration Chassis, sub frame, carbon steel water tank, manhole, water pump, front/side/rear spray nozzle, rear working platform, water cannon, fire valve, water valve, filter gauze, water hose, climbing ladder.
Selective configuration Stainless steel/aluminum alloy water tank, insulation layer for water tank, stainless steel water pump, fire pump, fire gun, pesticide plate, cabin gas control operated, Honda pumps, lights, crane, hanging basket, rear spraying device, barrel pesticide spraying device, gasoline pesticide machine, diesel pesticide machine, LED arrow lights
Extended model water transporting truck, thermal insulation water transporting truck, drinking water tank truck, liquid food truck, fire water tank truck, pesticide spraying truck, and etc.

Foton 4x2 Stainless Steel Drinking Water Truck LHD

Overall dimensions 5990X1955X2300mm Curb weight 3200kg
Tank dimensions 3500×1700×1280mm Tank volume 5000L

Tank material stainless  steel Tank thickness 4/5mm
Nozzle sprinkling width ≥14m Range of water cannon ≥28m
Suction height ≥7m Color and Logo Optional

FOTON stainless steel water tank truck 6cbm LHD

Overall dimensions 5990X1955X2300mm Curb weight 3200kg

Tank dimensions 3850X1700X1280mm Tank volume 6000L
Tank material stainless  steel Tank thickness 4/5mm

1, Attached parts and tools put into standard export box.

2, Water tank truck will be cleaned and covered with wax before delivery.

3, Water tank truck will be covered by waterproof cloth at the departure port.

4,Roll-on/Roll-off ship or bulk cargo ship is optional according to the customers` requirements.

5,Some small water tank truck can be put into container according to its overall dimensions.
