Beiben 4X4 NORTH BENZ VACUUM TANKER

Beiben 4X4 NORTH BENZ VACUUM TANKER
Availability:
Quantity:
  • DRZ5160

  • BEIBEN

  • 8705

Beiben Vacuum tanker truck   Beiben 4X4 NORTH BENZ VACUUM TANKER
1627 NORTH BENZ VACUUM SEWAGE  SUCKING  TANKER

 off Road Vacuum Tanker Truck Sewage Pump Tanker
 Product Tags: Beiben 4x4 off road vacuum tanker truck sewage pump tanker   Beiben vacuum tanker truck 4x4   north benz 4x4 tanker trucks

1.Beiben ND1160,ND2060 4 wheel drive sewage suction truck based on Mercedes Benz technology
2.  Common rail engine, World famous weichai engine
3.FAST(Fuller) gearbox
4.Benz front axle and rear axle, for military using.

  Euro 3,     Euro 4  septik truck  sewage tanker  Cesspool Emptying Truck   Septic tank Truck


         4*2/4x4         ND1160A41         4100         WP6.180
         ND1163A48J         4800         WP10.270
         WP10.290



         4*4         ND2161E48         4800         WP10.270
         ND2162E48J         WP10.300N
         ND21600E41J         4500         WP10.336


         Model

         ND2160E48J (4*4)

         Engine

         290 HP EURO II-V

         chassis

         BeiBen 4x4 military chassis

         Outside dimension(mm)

         8826×2500×3355

         volume of tank

          6000L~ 10000L

         Material of tank

         Carbon steel

         Thickness

         6mm

         Total mass (kg)

         16000

         Kerb mass (kg)

         7960

         Rated payload(kg)

         7910

         Wheelbase (mm)

         4800

         Tread(front/rear)

         1995/1800

         Approach/departure angle

         30/28

         Front /rear suspension

         1410/2616

         Minimum turning diameter

         20.4

         Clutch type

         GFX420, diaphragm spring clutch

         Gear box type

         9JS119,mechanical , 9 forwards, manual

         Tire  type

         14.00R20 (6+1)

         Fuel tank capacity (L)

         300

         Max.gradient

         60

         Max. Speed(Km/h)

         85

         Battery(V)

         Electrical system storage battery 2X12V/135Ah

         generator

         28V-35A

         Starter

         5.4Kw/24V

         A/C

         YES


Vacuum tanker  septik truck  sewage tanker ,CAPACITY 8000 UPTO 12000  Sewage Tank,Sewer JettingTruck,Vacuum Suction tanker , vacuum suction truck  ,vacuum truck,Sewer Jet Truck ,vacuum sewage suction truck ,Septic Tank Truck ,Cesspit Emptier Customization, Cost and Control Built How You Want it, at a Price You Can Afford. for sale call:+86-152 -7135-7675 Vaccum tanker vacuum sewage suction truck

 optional inner lined PE for chemical wast acid with vacuum pump for non-potable water, sewage suction and transport jetting water pump uum Trailers Stainless Steel Vacuum Tanks
