High Pressure Cleaning Water Jetting Tanker Truck 8000 ~10000L Euro 3-6
| Quantity: | |
|---|---|
- 1000
- T/T, Western Union
- Nil
Dongfeng high pressure cleaning truck
high pressure cleaning water tanker truck 6000 ~7000Litres
water/ oil tanker truck Customization, Cost and Control Built How You Want it, at a Price You Can Afford. for sale 86-152 -7135-7675
High Pressure Jetting Truck water jetting trucks
Application
This high pressure watering and dredging truck is multi-functional equipment combined with water spraying, cleaning of road surface, curbs, handrails, billboard, verge by high pressure water, emergency firefighting, spraying dust, watering the green belt, clearing the sewer outfall and cleaning industrial cleaner. This kind of machine can be widely used in daily work of variable grades of highway, municipal administration, and sanitation.
Structural feature
Emission standard EUROIII, EUROIV
Water tank is designed as elliptical cross section with advanced preservative treatment on the surface, being equipped with flow meter; level gauge and low water level alarm inside, the power will be cut down automatically when water level reaches the lowest limit.
Low pressure waterway system realizes cleaning of road surface, water spraying, watering the green belt, and firefighting.
High-power water spraying truck is driven by self-priming centrifugal with large flow and high lift.
Front spraying and back impacting function, high pressure back impacting by 20m cleaning width. Controlled by air-control ball valve, can be operated inside cab.
Back spraying gun can be turned by 360°
High pressure waterway system realizes front impacting, left & right spraying in corners, spraying dust device, handheld-gun operation and draining.
Safety valve and overflow valve, double protection to high pressure water pump.
Front water spraying device can be stretched and turned left and right.
All nozzles are imported parts, fine spraying particles, large spraying range.
Draining, hose retracted by hydraulic reel.
water tank truck , dongfeng Water tank , WATER TANK , Water tank Truck , water tanker
High Pressure Jetting Truck water jetting trucks
Product | Dongfeng new model high pressure cleaning truck (Both Italy pump and domestic pump can be used) | |
Chassis type | DFL1160BX | |
| Cubage(CBM) | 9-10m3 | |
| Parameters | Overall dimension length/width/height (mm) | 7900×2490×3050 |
| Total Mass(kg) | 16000 | |
| Payload(kg) | 8000 | |
| Kerb Mass(kg) | 8000 | |
| Approach angle/ Departure angle(mm) | 25/15 | |
| Front suspension/rear suspension(mm) | 1205/2195 | |
| Fuel Type | diseel | |
| Fuel Consumption/100 km | 90 | |
| Max Speed | 90 | |
| Engine | Type | ISB180-40 |
| Displacement/Power(kw) | 5900/132 | |
| Manufacturer | Dongfeng Commins Diesel Engine Co., Ltd | |
| Type | 4-stroke 6-in-line, inner-cooling supercharged diesel engine | |
| Chassis | Drive type | 4×2 |
| Wheelbase(mm) | 5000 | |
| Tread(front/rear) | 1940/1860 | |
| Front axle | 4.5T | |
| Rear axle | 9T | |
| Steering gear | Duel-armed steering wheel, power steering | |
| Transmission | 6 gear mechanical drive transmission | |
| Clutch | Diaphragm clutch, hydraulic remote control, pneumatic servo | |
| Braking system | Split air braking system, spring braking, exhaust braking | |
| Cab | Non-longheaded, one and a half row cab,whole metal-enclosed | |
| Number of spring axle(front/rear) | 8/10+8 | |
| Tire Type | 9.00-20 | |
| Air-condition | Choose to fix | |
Application
This high pressure watering and dredging truck is multi-functional equipment combined with water spraying, cleaning of road surface, curbs, handrails, billboard, verge by high pressure water, emergency firefighting, spraying dust, watering the green belt, clearing the sewer outfall and cleaning industrial cleaner. This kind of machine can be widely used in daily work of variable grades of highway, municipal administration, and sanitation.
Structural feature
Emission standard EUROIII, EUROIV
Water tank is designed as elliptical cross section with advanced preservative treatment on the surface, being equipped with flow meter; level gauge and low water level alarm inside, the power will be cut down automatically when water level reaches the lowest limit.
Low pressure waterway system realizes cleaning of road surface, water spraying, watering the green belt, and firefighting.
High-power water spraying truck is driven by self-priming centrifugal with large flow and high lift.
Front spraying and back impacting function, high pressure back impacting by 20m cleaning width. Controlled by air-control ball valve, can be operated inside cab.
Back spraying gun can be turned by 360°
High pressure waterway system realizes front impacting, left & right spraying in corners, spraying dust device, handheld-gun operation and draining.
Safety valve and overflow valve, double protection to high pressure water pump.
Front water spraying device can be stretched and turned left and right.
All nozzles are imported parts, fine spraying particles, large spraying range.
Draining, hose retracted by hydraulic reel.
1.The profile of the high pressure washing truck. | ||
| Model | 4x2 | |
| Dimensions(L*W*H) | mm | 7500x2400x3300 |
| 2. Engine | ||
| Engine Model | ISDe180 40 | |
Fuel Type | Diesel | |
| Engine Horsepower | Hp/Kw | 185/136 |
| Exhaust | ml | 5900 |
| Transmission | 6-speed with over drive | |
| Electric system | 24 V | |
| Manufacturer | Dongfeng(DFAC) Cummins | |
| Emission Standard | EURO 4 | |
| Max torque | 700 N.m | |
| Maximum torque speed | 1400 | |
| Rated speed | 2500RPM | |
| Intake Forms | Intercooled diesel engine | |
| 3. Washing equipment specifications & functions | ||
| Water tanker, Washing equipment | ||
| Water tank capacity | Approx 5 T | |
| Water tank dimensions | 2100x2100x1880 mm | |
| Width of high pressure cleaning | 2.5~3.5 m | |
| High pressure cleaning pressure | 10, 6, 19 optional | |
| High pressure cleaning water flow | 152, 212,346 optional | |
| Low pressure cleaning width | ≥20 m | |
| Low pressure cleaning water flow | 500~800 L/min | |
| Low pressure water gun range | 38 m | |
chassis EURO4 list
Models | Wheelbase | Chassis Type | Parameter Configuration |
| Dongfeng | 5000mm | DFL1120B13 | 4 × 2 drive, D530 flat head of a row of semi-flat top cab, Cummins ISB180-40 electronically controlled common rail engine, wheelbase 5000mm, Dongfeng six-speed gearbox DF6S900, 4.5T front axle, 9T single reduction axle, 250mm double (7 + 4) girders, 900R20 steel tire. Original ABS, tachograph, manual windows and doors, with air conditioning. |
| DFL1160BX18 | 4 × 2 drive, D530 flat head of a row of semi-flat top cab, Dongfeng EQH160-40 electronically controlled common rail engine, wheelbase 5000mm, Dongfeng six-speed gearbox DF6S900, 3.6T front axle, rear 8T single reduction axle, 250mm singlebeam, 900R20 steel tire. Original ABS, tachograph, manual windows and doors, with air conditioning. | ||
| DFL1160BX5 | 4 × 2 drive, D530 flat head of a row of semi-flat top cab, Cummins ISB180-40 electronically controlled common rail engine, wheelbase 5000mm, Dongfeng six-speed gearbox DF6S900, 4.5T front axle, 9T single reduction axle, 250mm double (7 + 4) girders, 900R20 steel tire. Original ABS, tachograph, manual windows and doors, with air conditioning. | ||
| Dongfeng | 4700mm | DFL1160BX18 | 4 × 2 drive, D530 flat head of a row of semi-flat top cab, Dongfeng EQH160-40 electronically controlled common rail engine, wheelbase 4700mm, Dongfeng six-speed gearbox DF6S900, 3.6T front axle, rear 8T single reduction axle, 250mm singlebeam, 900R20 steel tire. Original ABS, tachograph, manual windows and doors, with air conditioning. |
| Dongfeng | 3800mm 4700mm | DFL1120B3 | 4 × 2 drive, D530 flat head of a row of semi-flat top cab, Cummins ISDe180 40 electronically controlled common rail engine, wheelbase 3800mm, steel 160L fuel tank, Dongfeng six-speed gearbox DF6S750, 4.5T front axle, 9T single reduction axle , 250mm double (7 + 4) girders, 9.00-20 bias tires, original ABS, tachograph, manual windows and doors, with air conditioning. |
| Dongfeng | 4200mm 4500mm | DFL1160BX4 | 4 × 2 drive, D530 flat head of a row of semi-flat top cab, Cummins ISB 180 -40 electronically controlled common rail engine, wheelbase 4200mm or 4500mm, Dongfeng six-speed gearbox DF6S900, 4.5T front axle, 9T single reduction rear axle, 250mm double (7 + 4) girders, 900R20 steel tire.Original ABS, tachograph, manual windows and doors, with air conditioning. |
| Dongfeng | 3800mm | DFL1120B19 | 4 × 2 drive, D530 flat head of a row of semi-flat top cab, Cummins ISB180-40 electronically controlled common rail engine, wheelbase 3800mm or 4200mm, Dongfeng six-speed gearbox DF6S900, 3.6T front axle, rear 8T single reduction axle, 250mm single beam, 900R20 steel tire. Original ABS, tachograph, manual windows and doors, with air conditioning. |
| Dongfeng small triaxial | A variety of optional | DFL1250BX5A | 6 × 2 drive, D530 flat head of a row of semi-flat top cab, Cummins ISB180-40 or ISB210-40 electronically controlled common rail engine, rear Datong seven-speed gearbox DC7J100TA, 5T front axle, 10T single reduction axle, 250mm double girder , 295 / 80R22.5 18PR steel tire. Original front disc brakes ABS speed, tachograph, manual windows and doors, with air conditioning. |
M:8615271357675
TIC TRUCKS , www.truckinchina.com
Our water tank truck with different chassis, eg:DFAC, DFL, SINOTRUCK, CNHTC,NORTH BENS, FOTON, ISUZU, JAC, JMC, KAMA, YUEJIN, etc.
Our water tank series:
-----water tanker truck
-----sanitation water tank truck
-----sprinkler truck
-----water wagon truck
-----insulation water tank truck
-----pesticide sprinkling truck
-----water spraying truck
-----Mild steel water tank cart
-----Stainless steel tank water truck
-----Aluminum alloy water tanker
-----RHD watering cart
-----Water tank semi trailer
-----Storage water tanker
TIC TRUCKS , www.truckinchina.com
