JAC Water Truck 30000L 8x4 EURO 3/4

 JAC Water Truck 30000L 8x4 EURO 3/4

Overall dimensions 10980X2500X3755mm Curb weight 15200kg
Tank dimensions 7600×2450×1650mm Tank volume 30000L

Chassis parameters
Chassis model HFC1311P2K4H45F Chassis brand JAC
Overall dimensions 11730x2495x3220mm Wheel base 1900+4500+1350mm
Front/rear wheel track 2040/2040,1847/1847 mm Front/rear suspension 1495/2485mm
Approach/departure angle 22/17° Maximum speed 95km/h
Chassis Manufacturer Anhui Jianghuai Automobile Co., Ltd
Cab Configuration A row and a half deluxe cab(with sleeping berth), allowable 3 passengers, air condition, electric window, traveling data recorder
Color Red, other color is optional
Engine Model WP10.270E40
Emission Euro 4
Type 6 cylinders, in-line, 4-stroke, turbo inter-cooling, direct injection, diesel engine
Rated power 270hp, rated power speed 1900rpm
Displacement 9726ml
Max.torque 1270N.m
Bore x stroke 126x130mm
Manufacturer Weichai Power Co.,Ltd
Tire Size 11.00R20 steel wire tire
Number 12+1 nos
Clutch Φ diaphragm clutch
Frame 302X90X(8+4)mm
Fuel tank 300 L iron oil tank
Rear axle ANKAI 457, 26 tons
Drive form 8X4
Suspension Multi leaf springs
Rated voltage 24V,DC
Transmissions gearbox 9JS119(T)A, 9 speed forward 1 reverse.
Steering device Power assisted steering
Steering wheel Left hand drive
Selective configuration
If there is a slight change in the chassis parameters above, please take the actual product as the standard

Water tank structure
Tank dimensions 7600×2450×1650mm Tank volume 30000L
Tank material Carbon steel Tank thickness 5mm
Nozzle sprinkling width ≥14m Range of water cannon ≥28m
Suction height ≥7m Color and Logo Optional

JAC gallop 6x4 Water Tank Truck 22000L  EURO3/4

Water Truck,JAC 22000L Water Truck,ISUZU 20000L Water Bowser,JAC 22000L Spraying Truck,JAC 22000L water tank lorry,JAC 22000L Water Cart,JAC 22000L Water Tanker, JAC 22000L Water Wagon,JAC 22000L Water Tanker Truck,JAC 22000L Water Sprinkler Truck,JAC 22000L Watering Vehicle,JAC 22000L Watering Cart

 JAC Water Truck 10000L  EURO 4

Overall dimensions 8500X2500X3150mm Curb weight 7405kg
Tank dimensions 5200X2000X1100mm Tank volume 10000L


Chassis parameters
Chassis model HFC1161P3K2A47F Chassis brand JAC
Overall dimensions 7230x2495x3070mm Wheel base 4700mm
Front/rear wheel track 1963 ,1800 mm Front/rear suspension 1530/1000mm
Approach/departure angle 20/19° Maximum speed 95km/h
Chassis Manufacturer Anhui Jianghuai Automobile Co., Ltd
Cab Configuration A row and a half deluxe cab(with sleeping berth), allowable 3 passengers, air condition, electric window, traveling data recorder
Color Red, other color is optional
Engine Model YC4E160-42
Emission Euro 4
Type 4 cylinders, in-line, 4-stroke,water-cooled, turbo inter-cooling, direct injection, diesel engine
Rated power 160hp, rated power speed 2600rpm
Displacement 4260ml
Max.torque 550N.m
Bore x stroke 110X112mm
Manufacturer Guangxi Yuchai Machinery Group Co., Ltd
Tire Size 11.00R20 steel wire tire
Number 6+1 nos
Clutch Φ430 diaphragm clutch
Frame 245X75X7mm
Fuel tank 300L iron oil tank
Rear axle Boying 8 tons
Drive form 4X2
Suspension Multi leaf springs
Rated voltage 24V, DC
Transmissions gearbox CA6T138-85, 6 speed forward 1 reverse.
Steering device Power assisted steering
Steering wheel Left hand drive
Selective configuration
If there is a slight change in the chassis parameters above, please take the actual product as the standard

Water tank structure
Tank dimensions 5200X2000X1100mm Tank volume 10000L
Tank material Carbon steel Tank thickness 4/5mm
Nozzle sprinkling width ≥14m Range of water cannon ≥28m
Suction height ≥7m Color and Logo Optional

Stainless Steel Water Tank Vehicle , JAC Water Cleaning Vehicle , JAC Fire Fighting Vehicle , Stainless Steel Water Vehicle , Stainless Steel Storage Tank Vehicle , Stainless Steel Water Tank Truck , Stainless Steel Water Tank Auto , Stainless Steel Water Tanker Truck,JAC Water Tanker , 190hp Water Truck , JAC Water Tank Truck , Water Tanker , FAW Water Tank , JAC Water Truck , DFAC Water Tank Truck , 15000L Water Tanker

--------

-------------------------

 JAC water tanker fire truck

 optional tank capacity as clients speical need.

Overall dimensions 8500X2500X3150mm Curb weight 7405kg
Tank dimensions 5200X2000X1100mm Tank volume  water:5000   ~7000L

Chassis parameters
Chassis model HFC1161P3K2A47F Chassis brand JAC
Overall dimensions 7230x2495x3070mm Wheel base 4700mm
Front/rear wheel track 1963 ,1800 mm Front/rear suspension 1530/1000mm
Approach/departure angle 20/19° Maximum speed 95km/h
Chassis Manufacturer Anhui Jianghuai Automobile Co., Ltd
Cab Configuration A row and a half deluxe cab(with sleeping berth), allowable 3 passengers, air condition, electric window, traveling data recorder
Color Red, other color is optional
Engine Model YC4E160-42
Emission Euro 4
Type 4 cylinders, in-line, 4-stroke,water-cooled, turbo inter-cooling, direct injection, diesel engine
Rated power 160hp, rated power speed 2600rpm
Displacement 4260ml
Max.torque 550N.m
Bore x stroke 110X112mm
Manufacturer Guangxi Yuchai Machinery Group Co., Ltd
Tire Size 11.00R20 steel wire tire
Number 6+1 nos
Clutch Φ430 diaphragm clutch
Frame 245X75X7mm
Fuel tank 300L iron oil tank
Rear axle Boying 8 tons
Drive form 4X2
Suspension Multi leaf springs
Rated voltage 24V, DC
Transmissions gearbox CA6T138-85, 6 speed forward 1 reverse.
Steering device Power assisted steering
Steering wheel Left hand drive
Selective configuration
If there is a slight change in the chassis parameters above, please take the actual product as the standard

Water tank structure parameters
Tank dimensions 5200X2000X1100mm Tank volume 5000   ~7000L
Tank material Carbon steel Tank thickness 4/5mm
Nozzle sprinkling width ≥14m Range of water  fire cannon ≥50m
Suction height ≥7m Color and Logo Optional
Standard configuration Chassis, sub frame, carbon steel water tank, manhole, water pump, front/side/rear spray nozzle,rear working platform,water cannon,fire valve, water valve, filter gauze,water hose, climbing ladder.
Selective configuration Stainless steel/aluminum alloy water tank,insulation layer for water tank,stainless steel water pump, fire pump, fire gun,pesticide plate, cabin gas control operated, Honda pumps, lights, crane, hanging basket, rear spraying device, barrel pesticide spraying device, gasoline pesticide machine, diesel pesticide machine, LED arrow lights
Extended model water transporting truck, thermal insulation water transporting truck, drinking water tank truck, liquid food truck, fire water tank truck, pesticide spraying truck,and etc.

 Customization, Cost and Control Built How You Want it, at a Price You Can Afford. for sale call:+86-152 -7135-7675  M:8615271357675
