JAC 4x2 /4x4 water tanker fire truck

JAC 4x2 /4x4 water tanker fire truck
Tank volume water:5000 ~7000L
Price: $ 50000
Discount Price: $ 40000
FOB:
Availability:
Quantity:

  • DRZ5161TSFH

  • DRZ

  • 8705309000

JAC 4x2 4x4 water tanker fire truck

DTA-JAC-fire-truck0006-JAC -4x2 4x4 fire-truckwater 5000L ~7000L
optional tank capacity as clients speical need.

 Online call me Call me!Tom

 JAC water tanker fire truck

 optional tank capacity as clients speical need.

Overall dimensions 8500X2500X3150mm Curb weight 7405kg
Tank dimensions 5200X2000X1100mm Tank volume  water:5000   ~7000L

Chassis parameters
Chassis model HFC1161P3K2A47F Chassis brand JAC
Overall dimensions 7230x2495x3070mm Wheel base 4700mm
Front/rear wheel track 1963 ,1800 mm Front/rear suspension 1530/1000mm
Approach/departure angle 20/19° Maximum speed 95km/h
Chassis Manufacturer Anhui Jianghuai Automobile Co., Ltd
Cab Configuration A row and a half deluxe cab(with sleeping berth), allowable 3 passengers, air condition, electric window, traveling data recorder
Color Red, other color is optional
Engine Model YC4E160-42
Emission Euro 4
Type 4 cylinders, in-line, 4-stroke,water-cooled, turbo inter-cooling, direct injection, diesel engine
Rated power 160hp, rated power speed 2600rpm
Displacement 4260ml
Max.torque 550N.m
Bore x stroke 110X112mm
Manufacturer Guangxi Yuchai Machinery Group Co., Ltd
Tire Size 11.00R20 steel wire tire
Number 6+1 nos
Clutch Φ430 diaphragm clutch
Frame 245X75X7mm
Fuel tank 300L iron oil tank
Rear axle Boying 8 tons
Drive form 4X2
Suspension Multi leaf springs
Rated voltage 24V, DC
Transmissions gearbox CA6T138-85, 6 speed forward 1 reverse.
Steering device Power assisted steering
Steering wheel Left hand drive
Selective configuration
If there is a slight change in the chassis parameters above, please take the actual product as the standard

Water tank structure parameters
Tank dimensions 5200X2000X1100mm Tank volume 5000   ~7000L
Tank material Carbon steel Tank thickness 4/5mm
Nozzle sprinkling width ≥14m Range of water  fire cannon ≥50m
Suction height ≥7m Color and Logo Optional
Standard configuration Chassis, sub frame, carbon steel water tank, manhole, water pump, front/side/rear spray nozzle,rear working platform,water cannon,fire valve, water valve, filter gauze,water hose, climbing ladder.
Selective configuration Stainless steel/aluminum alloy water tank,insulation layer for water tank,stainless steel water pump, fire pump, fire gun,pesticide plate, cabin gas control operated, Honda pumps, lights, crane, hanging basket, rear spraying device, barrel pesticide spraying device, gasoline pesticide machine, diesel pesticide machine, LED arrow lights
Extended model water transporting truck, thermal insulation water transporting truck, drinking water tank truck, liquid food truck, fire water tank truck, pesticide spraying truck,and etc.

 Customization, Cost and Control Built How You Want it, at a Price You Can Afford. for sale call:+86-152 -7135-7675  M:8615271357675

 Weichat:King253725877  WhatsApp:8615271357675  Skype:tomsongking
