4T 108HP Boom Truck Crane Foton

4T 108HP Boom Truck Crane Foton
Availability:
Quantity:

 4T 108HP Boom Truck Crane Foton for sale

 4T Boom Truck Crane

 Brand: FOTON

 Specification: 4T

 Horse Power: 108HP

 Drive Type: 4x2


 Forland dump truck with crane tipper trucks  Palfinger Telescopic boom 7T truck mounted crane Whatsp:8615271357675Forland dump truck with crane tipper trucks  Palfinger Telescopic boom 7T truck mounted crane Whatsp:8615271357675Forland dump truck with crane tipper trucks  Palfinger Telescopic boom 7T truck mounted crane Whatsp:8615271357675Forland dump truck with crane tipper trucks  Palfinger Telescopic boom 7T truck mounted crane Whatsp:8615271357675Forland dump truck with crane tipper trucks  Palfinger Telescopic boom 7T truck mounted crane Whatsp:8615271357675Forland dump truck with crane tipper trucks  Palfinger Telescopic boom 7T truck mounted crane Whatsp:8615271357675Forland dump truck with crane tipper trucks  Palfinger Telescopic boom 7T truck mounted crane Whatsp:8615271357675Forland dump truck with crane tipper trucks  Palfinger Telescopic boom 7T truck mounted crane Whatsp:8615271357675Forland dump truck with crane tipper trucks  Palfinger Telescopic boom 7T truck mounted crane Whatsp:8615271357675Forland dump truck with crane tipper trucks  Palfinger Telescopic boom 7T truck mounted crane Whatsp:8615271357675Forland dump truck with crane tipper trucks  Palfinger Telescopic boom 7T truck mounted crane Whatsp:8615271357675Forland dump truck with crane tipper trucks  Palfinger Telescopic boom 7T truck mounted crane Whatsp:8615271357675

 Palfinger Telescopic boom truck mounted crane

 Forland truck with crane 4ton,5 ton,6.3ton,7ton optional

 Forland dump truck with crane tipper trucks  Palfinger Telescopic boom 7T truck mounted crane Whatsp:8615271357675

Custermizing
the best Boom Truck Crane



to worldwide. We specialise in the on-road load handling solutions, and help customers enhance their efficiency and productivity.
Crane brand: XCMG ,Palfinger, HIAB.,DRZE..
Crane type: Telescopic boom crane or knuckled boom crane.
Crane capacity: 2T, 3.2T, 4T, 5T, 6.3T, 8T, 10T, 12T, 14T, 16T, 25Tons.



No. of crane Arms: 2, 3, 4, 5, 6.
Chassis model: 4*2, 4*4, 6*4, 6*6, 8*4,8*8 / tractor / trailer
Cabin model: LHD or RHD

       Parts        Technical Parameter
       Overall        Chassis Model        BJ1063VCJFA
       Curb Weight        8000kg
       Rated Loading Weight        5000kg
       Overall Size (L*W*H)        7350x2420x3350mm
       Engine        Type of Fuel        Diesel
       Brand/Model        QuanChai/4DX22-110
       Horse Power        108HP
       Chassis        Brand        FOTON
       Wheelbase        3800mm
       Cabin        Left-hand driving, Air conditioner, Flat headed
       Transmission        WLY5-35
       Brake System        Air brake
       Tyre        Specification        8.25-16
       Number of Tyre        6+1 spare tyre
       Crane        Type        Telescopic boom crane
       Max Loading weight        4000KG
       Max lift moment        10T.M
       Recommend Power Needed At Recommend Oil Flow        16KW
       Max Oil Flow of Hydraulic System        25L/MIN
       Rated Pressure Of Hydraulic System        26MPA
       Crane weight        1350KG
       Lifting height        9.5m
       Working radius        7.93m
       No. of Arms        3
       Note        Some components are optional according to your requirements.
