SAG200-3
SANY
84292090
Specifications
Engine Model | 6CTAA8.3-C215 (Stage II) |
Rated Power/Speed | 160kW/2200rpm |
Max. Torque/Speed | 980kW/1500rpm |
Dimensions (Standard) | 8790mm×2725mm×3260mm |
Operating Weight(Standard) | 15400kg |
EXCELLENT EFFICIENCY AND SMART CONTROL
Auto change of gears, easy to operate, highly efficient
Speed range and initial gear can be set by operator, making operating extremely easy
Intelligent reversing technology, reducing the time for direction shift
POWERFUL TRANSMISSION
Combines advantages of both hydraulic and mechanical transmission, which is powerful
Rear axle applies no-spin differential lock technology,enhancing synchronization
Large torque rotary motor and worm-gear case with overload protection, making the blade more powerful in ground leveling
Hydraulically controlled inching technology produces outstanding low speed work
SAFETY AND COMFORT
Step-less speed change, low gear-shifting impact and comfortable operation
Joystick requires less exertion of physical force and less distance, is able to realize synchronous actions
Tripple braking (when travelling, when parked, and assisted by the hydraulic
system) leading to greater safety and reliability
CONVENIENT MAINTENANCE
Engine cabin door on each of the two sides which can be opened wider, making maintenance points more accessible and giving more space for maintenance work
Commonly used electrical devices centrally arranged, making it easier to check
Filters centrally arranged, easier to access and maintain
Specifications
Engine Model | 6CTAA8.3-C215 (Stage II) |
Rated Power/Speed | 160kW/2200rpm |
Max. Torque/Speed | 980kW/1500rpm |
Dimensions (Standard) | 8790mm×2725mm×3260mm |
Operating Weight(Standard) | 15400kg |
EXCELLENT EFFICIENCY AND SMART CONTROL
Auto change of gears, easy to operate, highly efficient
Speed range and initial gear can be set by operator, making operating extremely easy
Intelligent reversing technology, reducing the time for direction shift
POWERFUL TRANSMISSION
Combines advantages of both hydraulic and mechanical transmission, which is powerful
Rear axle applies no-spin differential lock technology,enhancing synchronization
Large torque rotary motor and worm-gear case with overload protection, making the blade more powerful in ground leveling
Hydraulically controlled inching technology produces outstanding low speed work
SAFETY AND COMFORT
Step-less speed change, low gear-shifting impact and comfortable operation
Joystick requires less exertion of physical force and less distance, is able to realize synchronous actions
Tripple braking (when travelling, when parked, and assisted by the hydraulic
system) leading to greater safety and reliability
CONVENIENT MAINTENANCE
Engine cabin door on each of the two sides which can be opened wider, making maintenance points more accessible and giving more space for maintenance work
Commonly used electrical devices centrally arranged, making it easier to check
Filters centrally arranged, easier to access and maintain
SAG160-5 160hp Hydraulic Motor Grader
SAG200-5 200hp Hydraulic Motor Grader
SAG200C-6 200hp Hydraulic Motor Grader
ENGINE | GROUP | GROUP | GROUP | |
---|---|---|---|---|
Engine model | Cummins QSB4.5-C160 | Cummins QSB6.7-C220 | 8850×2620×3260 mm | |
Emissions | Tier III | Tier III | 9000×2620×3260 mm | |
Rated power/speed | 119/2200 kW/rpm | 164/2200 kW/rpm | 9880×2740×3260 mm | |
Max.torque/speed | 949/1500 N.m/rpm | 949/1500 N.m/rpm | 10010×2740×3260 mm | |
POWER TRAIN | GROUP | GROUP | 11100×2620×3260 mm | |
Forward/Reverse gears | 6/3 | 5/5 | 6279 mm | |
Speed forward | 5/9/11/18/26/41 km/h | 6/10/16/28/38 km/h | 1538 mm | |
Speed reverse | 5/11/26 km/h | 6/10/16/28/38 km/h | 400 mm | |
HYDRAULIC SYSTEM | GROUP | GROUP | GROUP | |
Max.hydraulic pressure | 18 Mpa | 18 Mpa | 15200 Kg | |
Transmission system pressure | 1.6-1.8 Mpa | 1.6-2.3 Mpa | 16000 Kg | |
OPERATING SPECIFICATIONS | GROUP | GROUP | 17400 Kg | |
Max. front wheel turning angle | ±50° | ±50° | 16520 Kg | |
Max.front wheel tilt angle | ±17° | ±17° | 17920 Kg | |
Max.oscillation angle of front axle | ±16° | ±16° | 98 KN | |
Max.oscillation angle of tandem box | ±15° | ±15° | GROUP | |
Min.turning radius | 7.3 m | 7.4 m | 3660 mm(12ft)standard configuration | |
Rear axle ground clearance | 400 mm | 400 mm | 620 mm | |
BLADE RANGE | GROUP | GROUP | ±90° | |
Moldboard width×Arc radius | 3660×620 mm | 3660×620 mm | 360 ° | |
Max.blade position angle | ±90° | ±90° | GROUP | |
Blade==Max.lift above ground | 480 mm | 480 mm | 10 forward and 10 reverse | |
Blade==Max.depth of cut | 715 mm | 715 mm | operating mode:3/5/7/9/13; travelling mode:6/10/16/28/38 | |
Blade tip range | 27°-72° | 27°-72° | operating mode:3/5/7/9/13; travelling mode:6/10/16/28/38 | |
Circle rotation | 360° | 360° | ±50° | |
Max.penetrating angle | 65° | 63° | ±17° | |
RIPPER | GROUP | GROUP | ±24° | |
Max.scarifying depth | 395 mm | 435 mm | ±16° | |
Ripper==Max.lift above ground | 577 mm | 595 mm | 7.4° | |
Max.departure angle | 17° | 15° | 17.5-25(12PR) standard configuration | |
Ripper==Max.working width | 2300 mm | 2060 mm | GROUP | |
DOZER PLATE | GROUP | GROUP | 210L | |
Dozer==Max.depth of cut | 160 mm | 229 mm | 310 L | |
Dozer==Max.working width | 2440 mm | 2740 mm | ||
WEIGHTS | GROUP | GROUP | ||
Operating weight (Standard) | 15200 kg | 16000 kg | ||
Max.operating weight | 15950 kg | 17920 kg | ||
DIMENSIONS | GROUP | GROUP | ||
Dimensions (Standard) | 8950×2540×3220 mm | 9000×2680×3260 mm | ||
Dimensions | 10730×2540×3220 mm | 10900×2740×3260 mm |
SAG160-5 160hp Hydraulic Motor Grader
SAG200-5 200hp Hydraulic Motor Grader
SAG200C-6 200hp Hydraulic Motor Grader
ENGINE | GROUP | GROUP | GROUP | |
---|---|---|---|---|
Engine model | Cummins QSB4.5-C160 | Cummins QSB6.7-C220 | 8850×2620×3260 mm | |
Emissions | Tier III | Tier III | 9000×2620×3260 mm | |
Rated power/speed | 119/2200 kW/rpm | 164/2200 kW/rpm | 9880×2740×3260 mm | |
Max.torque/speed | 949/1500 N.m/rpm | 949/1500 N.m/rpm | 10010×2740×3260 mm | |
POWER TRAIN | GROUP | GROUP | 11100×2620×3260 mm | |
Forward/Reverse gears | 6/3 | 5/5 | 6279 mm | |
Speed forward | 5/9/11/18/26/41 km/h | 6/10/16/28/38 km/h | 1538 mm | |
Speed reverse | 5/11/26 km/h | 6/10/16/28/38 km/h | 400 mm | |
HYDRAULIC SYSTEM | GROUP | GROUP | GROUP | |
Max.hydraulic pressure | 18 Mpa | 18 Mpa | 15200 Kg | |
Transmission system pressure | 1.6-1.8 Mpa | 1.6-2.3 Mpa | 16000 Kg | |
OPERATING SPECIFICATIONS | GROUP | GROUP | 17400 Kg | |
Max. front wheel turning angle | ±50° | ±50° | 16520 Kg | |
Max.front wheel tilt angle | ±17° | ±17° | 17920 Kg | |
Max.oscillation angle of front axle | ±16° | ±16° | 98 KN | |
Max.oscillation angle of tandem box | ±15° | ±15° | GROUP | |
Min.turning radius | 7.3 m | 7.4 m | 3660 mm(12ft)standard configuration | |
Rear axle ground clearance | 400 mm | 400 mm | 620 mm | |
BLADE RANGE | GROUP | GROUP | ±90° | |
Moldboard width×Arc radius | 3660×620 mm | 3660×620 mm | 360 ° | |
Max.blade position angle | ±90° | ±90° | GROUP | |
Blade==Max.lift above ground | 480 mm | 480 mm | 10 forward and 10 reverse | |
Blade==Max.depth of cut | 715 mm | 715 mm | operating mode:3/5/7/9/13; travelling mode:6/10/16/28/38 | |
Blade tip range | 27°-72° | 27°-72° | operating mode:3/5/7/9/13; travelling mode:6/10/16/28/38 | |
Circle rotation | 360° | 360° | ±50° | |
Max.penetrating angle | 65° | 63° | ±17° | |
RIPPER | GROUP | GROUP | ±24° | |
Max.scarifying depth | 395 mm | 435 mm | ±16° | |
Ripper==Max.lift above ground | 577 mm | 595 mm | 7.4° | |
Max.departure angle | 17° | 15° | 17.5-25(12PR) standard configuration | |
Ripper==Max.working width | 2300 mm | 2060 mm | GROUP | |
DOZER PLATE | GROUP | GROUP | 210L | |
Dozer==Max.depth of cut | 160 mm | 229 mm | 310 L | |
Dozer==Max.working width | 2440 mm | 2740 mm | ||
WEIGHTS | GROUP | GROUP | ||
Operating weight (Standard) | 15200 kg | 16000 kg | ||
Max.operating weight | 15950 kg | 17920 kg | ||
DIMENSIONS | GROUP | GROUP | ||
Dimensions (Standard) | 8950×2540×3220 mm | 9000×2680×3260 mm | ||
Dimensions | 10730×2540×3220 mm | 10900×2740×3260 mm |
