M315D2
-
CAT
-
84295212
NEW WHEEL EXCAVATORS M315D2 price
The M315D2 Wheel Excavator provides fast cycle times, great lift capacity and high bucket and stick forces. This combination maximizes your productivity in any job.
| Engine Model | Cat® C4.4 |
| Net Power | 95.0 kW |
| Bore | 105.0 mm |
| Stroke | 127.0 mm |
| Displacement | 4.4 L |
| Cylinders | 4 |
| Maximum Torque at 1,400 rpm | 550.0 N·m |
| Net Power (ISO 14396) at 2,000 rpm | 102.0 kW |
| Net Power – ISO 14396 | 102.0 kW |
| Net Power – ISO 9249/SAE J1349 | 95.0 kW |
| Emissions | Equivalent to U.S. Environmental Protection Agency (EPA) Tier 3, EU Stage IIIA, Korea Tier 3 and China Stage II emission standards |
| Ratings | 2000.0 rpm |
WEIGHTS
| Operating Weight | 13 500 to 15 200 kg (29762 to 33510 lb) |
| VA Boom* – Rear Dozer Only | 14200.0 kg |
| VA Boom* – Front Dozer, Rear Outriggers | 15100.0 kg |
| One-Piece Boom (Standard) – Rear Dozer Only | 13800.0 kg |
| One-Piece Boom (Standard) – Rear Dozer, Front Outriggers | 14750.0 kg |
| One-Piece Reach Boom* – Rear Dozer Only | 13800.0 kg |
| One-Piece Reach Boom* – Front Dozer, Rear Outriggers | 14750.0 kg |
| Sticks – Short (2000 mm) | 370.0 kg |
| Sticks – Medium (2300 mm) | 390.0 kg |
| Counterweight – Standard | 2900.0 kg |
| Counterweight – Optional | 3300.0 kg |
| Note | * Machine weight with medium stick, 3300 kg counterweight, with operator and full fuel tank, with 450 kg bucket. |
| Note (cont'd) | Weight varies depending on configuration. |
SWING MECHANISM
| Swing Speed | 10.5 rpm |
| Swing Torque | 35.0 kN·m |
HYDRAULIC SYSTEM
| Tank Capacity | 95.0 L |
| System | 180.0 L |
| Maximum Pressure – Implement Circuit – Normal | 350.0 bar |
| Maximum Pressure – Implement Circuit – Heavy Lift | 375.0 bar |
| Maximum Pressure – Travel Circuit | 350.0 bar |
| Maximum Pressure – Auxiliary Circuit – High Pressure | 350.0 bar |
| Maximum Pressure – Auxiliary Circuit – Medium Pressure | 185.0 bar |
| Maximum Pressure – Swing Mechanism | 350.0 bar |
| Maximum Flow – Implement/Travel Circuit | 190.0 L/min |
| Maximum Flow – Auxiliary Circuit – High Pressure | 190.0 L/min |
| Maximum Flow – Auxiliary Circuit – Medium Pressure | 40.0 L/min |
| Maximum Flow – Swing Mechanism | 80.0 L/min |
TRANSMISSION
| Drawbar Pull | 76.0 kN |
| Maximum Gradeability | 58% |
| Forward/Reverse – 1st Gear | 9.0 km/h |
| Forward/Reverse – 2nd Gear | 37.0 km/h |
| Creeper Speed – 1st Gear | 3.0 km/h |
| Creeper Speed – 2nd Gear | 13.0 km/h |
SERVICE REFILL CAPACITIES
| Cooling | 31.0 L |
| Engine Crankcase | 8.0 L |
| Final Drive | 2.4 L |
| Powershift Transmission | 2.5 L |
| Fuel Tank | 235.0 L |
| Rear Axle Housing (differential) | 11.2 L |
| Front Steering Axle (differential) | 9.0 L |
TIRES
| Standard | 10.00-20 (dual pneumatic) |
UNDERCARRIAGE
| Ground Clearance | 370.0 mm |
| Maximum Steering Angle | 35° |
| Oscillation Axle Angle | ±9° |
| Minimum Turning Radius – Outside of Tire | 6200.0 mm |
| Minimum Turning Radius – End of VA Boom | 6700.0 mm |
| Minimum Turning Radius – End of One-Piece Boom | 8100.0 mm |
DRIVE
| Maximum Travel Speed | 37.0 km/h |
SOUND LEVELS
| Exterior Sound | Labeled spectator sound power level measured according to test procedures and conditions specified in 2000/14/EC is 102 dB(A). |
CAB/FOGS
| Standards | Cab with Falling Object Guard Structure (FOGS) meets ISO 10262. |
BUCKET SPECIFICATIONS
| Bucket Capacities | 0.20 to 0.76 m3 (0.26 to 1.0 yd3) |
WORKING RANGES
| Maximum Reach at Ground Level | 8740.0 mm |
| Maximum Digging Depth | 5450.0 mm |
M315D2 STANDARD EQUIPMENT
ELECTRICAL
Alternator, 75A
Lights: – Boom working light – Cab interior light – Roading lights two front – Roading lights two rear – Working lights, cab mounted (front and rear)
Main shut-off switch
Heavy-duty maintenance free batteries
Signal/warning horn
ENGINE
Automatic engine speed control
Automatic starting aid
Cat C4.4 emits at levels equivalent to U.S. EPA Tier 3 and EU Stage IIIA emission standards
Fuel/water separator with level indicator
HYDRAULICS
Heavy lift mode
Load-sensing plus hydraulic system
Anti-drift valves for boom stick and bucket
Manual work modes (economy, power)
Separate swing pump
Stick regeneration circuit
OPERATOR STATION
Adjustable armrests
Air conditioner, heater and defroster with automatic climate control
Ash tray with cigarette lighter (24V)
Beverage cup/can holder
Bolt-on FOGS capability
Bottle holder
Bottom mounted parallel wiping system that covers the upper and lower windshield glass
Camera mounted on counterweight displays through cab monitor
Coat hook
Floor mat, washable, with storage compartment
Fully adjustable suspension seat
Instrument panel and gauges: – Information and warning messages in local language – Gauges for fuel level, engine coolant and hydraulic oil temperature – Filters/fluids change interval – Indicators for headlights, turning signal, low fuel, engine dial setting – Clock with 10-day backup battery
Laminated front windshield: – 70/30 split, openable
Left side console, tiltable, with lock out for all controls
Literature holder in right console
Mobile phone holder
Parking brake
Positive filtered ventilation
Power supply, 12V-7A
Rear window, emergency exit
Retractable seat belt
Skylight
Sliding door windows
Steering column, tiltable
Storage area suitable for a lunch box
Sunshade for windshield and skylight
Visor for rain protection
UNDERCARRIAGE
Heavy-duty axles, advanced travel motor, adjustable braking force
Oscillating front axle with remote greasing
Tires, 10.00-20 16 PR, dual
Tool box in undercarriage
Second tool box for undercarriage
Two-piece drive shaft
OTHER EQUIPMENT
Automatic swing brake
Cat Product Link
Counterweight, 2900 kg
Mirrors, frame and cab
M315D2 OPTIONAL EQUIPMENT
AUXILIARY CONTROLS AND LINES
Auxiliary boom and stick lines
Anti-drift valves for tool control/multi-function circuits
Basic control circuits: – Medium pressure: Two-way, medium pressure circuit, for rotating or tilting of work tools – Hammer circuit – Tool control/multi function: One/two-way high pressure for hammer application or opening and closing of a work tool; Programmable flow and pressure for up to 10 work tools – selection via monitor; Quick coupler control
SmartBoom
FRONT LINKAGE
Booms: – One-piece reach boom, 4815 mm – VA boom (two piece), 5020 mm – One-piece boom, 4500 mm
Bucket linkage with diverter valve
Sticks: – 2000, 2300 mm
ELECTRICAL
Back-up alarm with three selectable modes
Lights: – Rotating beacon on cab
Refueling pump
OPERATOR STATION
Falling object guards
Joystick steering
CD/MP3 Radio (12V) at rear location including speakers and 12V converter
Seat, adjustable high-back: – mechanical suspension – air suspension (vertical)
UNDERCARRIAGE
Dozer blade, rear mounted
Outriggers, rear mounted and blade front
Spacer rings for tires
OTHER EQUIPMENT
Cat Machine Security System
Counterweight, 3300 kg
Ride Control
