Availability: | |
---|---|
Quantity: | |
Beiben jet refuelling vechicle Aviation Refuellers
Tank Equipments (all API Standard)
Beiben jet refuelling vechicle Aviation Refuellers
Tank Equipments (all API Standard)
Clutch | Model | GFX420, Single dry frictional disc,Hydraulic boosting |
Gearbox | Model | mechanism, 9 forward gears, 1 reverse gear, manual, made in China, produed by Bei Ben Transmission) |
Transfer-case | VG1400(Benz technical,made by BEIBEN AXLE) | |
Brake system | Service brake | Brake gap can be adjusted automatically, double circulation air brake system |
Assistant brake | Engine exhaust brake | |
Park brake | Potential springs pressing on middle and rear wheels | |
Steering system | Model | ZF8098 |
Frame of vehicle | Fish belly shape, variable width, variable section side beam structure | |
Front axle (Mercedes Benz Technology) | Double-shoe pneumatic brake, non-driving steering axle | |
Middle and Rear axle (Mercedes Benz Technology) | Double-shoe pneumatic brake, ductile casting casing, with hub redactor, double reduction driving axle | |
Tyre | 12.00R20 | |
Electrical system | Battery | 2X12V/135Ah |
Generator | 28V -35A | |
Starter | 5.4Kw/24V | |
Cab | Short cab, made by full steel material, anticrash performance can be ensured by double hollow chamber structure. Inner A/C |
Configurations: | |
1. Working environmental | Smooth road in the airport |
2. Temperature | 35℃~-40℃ |
3. Relative humidity | <95% |
4. Altitude | <4000 m |
5. Speed in the airport | ≤40km/h |
6. Speed on the road | ≤70km/h |
7. Main assembly | Truck chassis, Oil tank, Operation cabin, Pipe system, Pneumatic control system, Hydraulic system, Electrical system |
8. Noise | Meeting with the requirement of GJB4433, operation noise≤90dB(A) |
9. Reliability | Meeting with the requirement of GJB4433, MTBF≥80h |
10. Maintaining | Meeting with the requirement of GJB368B, MTTB≤30min |
11. Oil tank capacity | 18000L |
12. Oil tank material | Stainless steel 0Cr19Ni9 |
13. DN63 single pipe pressure refuel | 1200L/min |
14. DN38 single pipe gravity refuel | ≥300L/min |
15. DN38 double pipes gravity refuel | ≥600L/min |
16. Suck the oil from the pipe of oil tank | ≥300L/min(Single pipe)with measurement |
17. Self refuel ability | ≥2000L/min |
18. Connector closed pressure | 0.345Mpa±0.03Mpa |
19. Refuel accuracy | 0.2, instant, one time and total measurement |
20. Refuel from 0 to max flow rate time | ≤15s |
21. Filter performance | stainless steel horizontal filter, filtering capacity ≥2000L/min, filtering accuracy 1 micro meter, filtering quality ≤0.26mg/L, non dissolved water ≤15ppm, the oil quality after filter meeting with the requirement o f GJB610 |
22. The oil exhausting capacity | ≤31L/Km |
23. Braking length under 30km/h | ≤9m |
24. Speed limited in the air port | <40km/h |
25. Noise while acceleration | ≤89dB(A) |
26. Noise while operation | ≤90 dB(A) |
27. Min turning radius | ≤9.3m |
Off-raod Fuel Tank Truck North Benz (6X6 drive / 18,000 Litres) | ||
General | Vehicle Brand | TIC |
Chassis Brand | North Benz | |
Overall Dimension | 9580 * 2500 * 3400 mm | |
GVW / Kerb Weight | 25,000 kg / 12,400 kg | |
Cab | Cab Capacity | 2 persons allowed |
Air Conditioner | Air conditioner is equipped | |
Engine | Fuel Type | Diesel |
Engine Brand | Weichai engine(Chinese top brand) | |
Power | 336 Ps (247 KW) | |
Displacement | 9726 ml | |
Emission Standard | Euro III | |
Chassis | Drive Type | 6X6, left hand drive |
Transmission | 9-speed front, 1 reverse | |
Wheelbase/No. of axle | 4450+1450 mm / 3 | |
Tyre Specification | 12.00-20 | |
Tyre Number | 10 tyres and 1 spare tyre | |
Max Speed | 85 km/h | |
Paint | Metallic paint | |
Superstructure | Tank Capacity | 18,000 Litres ( About 4,700 gallons ) |
Tank Material | Carbon steel | |
Pump | Equipped for overhead delivery, 1000 litres / min | |
Suction Head | 6 m | |
Hose | High quality, wire strengthened hose, with cooper wire, anti-static | |
All standard accessories: manhole, ladder, anti-static belt, anti-slip walkway, handrail, fire extinguisher, inlet, discharge, reflective stickers…….. | ||
Optional | ** Tank material could be carbon steel, stainless steel, aluminum (aluminum tanker)…… ** It can be divided into many compartments. ** Devices can be equipped: fuel counter (flow gauge), fuel dispenser, hose reel, level gauge…… ** Heat preservation & heating system could be added. ** Bottom loading system can be equipped. |
