6 Units 40KL 44KL 40FT ISO Steel Lined PE Dilute Sulfuric Acid Tank Container To Kazakhstan

Views: 2162     Author: Dong Runze Special Vehicle     Publish Time: 2023-12-24      Origin: Site

6 Units 40KL 44KL 40FT ISO Steel Lined PE Dilute Sulfuric Acid Tank Container To Kazakhstan

6 Units 40KL 44KL  40FT ISO Steel Lined PE dilute sulfuric acid Tank Container to Kazakhstan

40FT Tank Container PE Lined Tank

Used to contain: HCl (max 35%), NaOH (max 50%), PAC (max 17%),H2SO4(max 94%) Sulphuric Acid   etc…

Tank Capacity: 40,000 Liters;44,000 Liters

Steel sheet 6mm, head 6mm

Liner thickness: 16mm PE

01pc butterfly valve CS/F46 and 01pc ball valve CS/F46

40 feet 93.0% H2SO4 ISO tank container; Shell of tank container Materials using Wisco Q235 High quality carbon steel 6 mm; internal strengthen lozenge expanded 4mm metal mesh transition,Plastic-lining thickness 16mm;PE Lined steel baffle;steel line PE Manhole cover,loading on top and unloading at bottom.Used for road transport or storage purpose: Water ,HCl, NaOH, H2SO4 etc. Tank capacity: 44,000 liters in ISO 40FT frame.40Ft Iso Tank Container

40ft Tank container ( 40ft only Empty tank can lift by crane or forklift )


Ext. Length

12144/12192 mm

Ext. Width

2438mm


Ext. Height

2400mm; 2591mm

M.G.W.

90000kg ;92000kg


Tare

11600Kg;

12000kg

Max. Payload

80000Kgs


Cubic Capacity

40m3;44m3

Tank Design Standard

GB 150 ,GB/ T 16563, GB/ T 1413, GB/ T 1836, GB/ T 1835.


Max. Design Pressure

0.1Mpa

Calculated Pressure

0.1Mpa


Testing Pressure

0.1Mpa

Design Operating Temp.

-20℃~55℃


Lining

PE7042 lined 16mm

Material of Tank Body

Q235


Manhole Dia.

580mm

Tank Body Thickness

6 .0mm


Facilities Tank Capacity: 44,000 Liters

Steel sheet 6mm, head 6mm Liner , inner welded reinforcement 4mm steel mesh ,thickness: 16mm~18mm PE;Tank in 40ft rectangular frame, 2 pcs of bottom valves, Connect each outlet pipe,   01pc butterfly valve CS/F46 and 01pc ball valve CS/F46, Both valves are all connected by DN80-DIN PN16 flange, The connection type: butterfly valve - ball valve - connection flange,  protection frame and bracket for the valve , full plastic manhole cover,  the painting of tank is anti-corrosive painting,

40Ft Dilute Sulfuric Acid Iso Tank Container (4)40Ft Dilute Sulfuric Acid Iso Tank Container (6)40Ft Dilute Sulfuric Acid Iso Tank Container (8)40Ft Dilute Sulfuric Acid Iso Tank Container (10)

Product Name

40 FT TANK CONTAINER

Product No。:

DRAU2311011

DRAU2311027

DRAU2311032

Date

2023.12. 6

MPaG

0.1      MPa

Type

ROAD

MOP point

MPa

Medium

HCL / H2SO4

Temp



Test pressure

MPa

Net weight

12000 kg

Volume

44 M3

Main material

Q235+PE

Standards

ISO

Class

A2 C2 C3

Registration


Product Name

40 FT TANK CONTAINER

Product No。:

DRAU2311048

DRAU2311053

DRAU2311069

Date

2023.12. 12

MPaG

0.1      MPa

Type

ROAD

MOP point

MPa

Medium

HCL / H2SO4

Temp



Test pressure

MPa

Net weight

11600   kg

Volume

40 M3

Main material

Q235+PE

Standards

ISO

Class

A2 C2 C3

Registration


Hydrocyanic Acid Tank , Hydrocyanic Acid Tank Tanker

40Ft Dilute Sulfuric Acid Iso Tank Container (3)

Hydrochloric acid tank, Sodium hypochlorite Tank body,

Tank body Carbon steel Shell 6mm inner lined 16mm PE,

for transport Ammonia liquid, glacial acetic acid, dilute sulfuric acid, hydrochloric acid,Caustic soda ,etc
