Tanker Manhole Cover , API Loading And Unloading Valve ,Adaptor,Vapor Vent Valve Accessories

Share to:

Tanker Manhole Cover , API Loading And Unloading Valve ,Adaptor,Vapor Vent Valve Accessories

Availability:

Quantity:


Inquire Add to Basket

Product Description
Technical Data Sheet

Tanker Manhole Cover , API Loading And Unloading Valve ,Adaptor,Vapor Vent Valve Tanker more parts with after-sale services in terms of follow-up inspections, maintenance and repair and uninterrupted supplies of a wide range of high quality parts and accessories from world renowned manufacturers.

Tanker Manhole Cover , API Loading And Unloading Valve ,Adaptor,Vapor Vent Valve more parts

Aluminum Alloy Fuel Tanker Manhole Cover manhole cover for semi-trailer20 Inch four holes tank manhole coverAluminum Alloy Fuel Tanker Manhole Cover d460Aluminium Fuel Tank Top Loading Tanker CoverAluminum API Loading And Unloading ValveAluminum Oil And Gas Vapor Vent ValveAluminum Vapoor Adaptor Valve2.5" 3" 4"Aluminum Vapor Recovery JointAluminum Optic Anti-Overfill Top SensorFuel Tanker Pneumatic Control Block

1. Manhole Cover Manhole Cover is installed on the top of the tanker to prevent the inside fuel from leakage when the tanker is over rolled. With P/V vent inside to adjust the pressure.When there is pressure differences inside and outside the tanker ,it will automatically inlet or exhaust air to adjust the pressure so that it can ensure the safety and environment protection.It is suitable to transpore petroleum ,diesel,kerosene,and the other light fuel,etc.

Model:C801A-460

Brand Name:JIALONG

Brief Description:1.Whole diameter: 16" 2.Nominal diameter:10" 3.Emergency open pressure: 21kpa -32kpa 4.Material: Aluminum alloy

Application:Trailer

2. Benefit & Feature

* Emergency Exhausting Design

when the tanker truck is in high temperature condition,the manhole will automatically exhaust the air inside to release the pressure,ensuring the safety of the tanker.

* With P/V Vent inside

When there is pressure differences inside and outside the tanker,it will automatically inlet or exhaust air to adjust the pressure so that it can ensure the safety and environmental preotection.

* Secondary Open Design

When open the up binder plate ,it will release the pressure out to prevent the workers from pushing over.

* Blinding Holes Design

In the main plate of the Manhole ,there are two blinding holes can be installed with Vapor Vent Valve,Optic Sensor,Dip Tube or Exernal Vacuum Valve according to the user's demand.

* Larger Angle Opening

The new designed blinder plate can make the cat hole opening's angle larger than the old one.

Additional Information

Name	Model	DO	D1	H	b	z-d
Manholes	C801A-560	Φ 560	Φ 530	88	12	24 - Φ 11
Manholes	C801A-580	Φ 580	Φ 542	88	12	24 - Φ 11

- manhole cover for semi-trailer

1.Whole diameter: 20" 2.Nominal diameter:10" 3.Emergency open pressure: 21kpa -32kpa 4.Material: Aluminum Alloy
20 Inch four holes tank manhole cover

1.Whole diameter: 20" 2.Nominal diameter:10" 3.Emergency open pressure: 21kpa -32kpa 4.Material: Aluminum alloy Main Size Data

Aluminium Fuel Tank Top Loading Tanker Cover

1.Whole diameter: 16" 2.Nominal diameter:10" 3.Emergency open pressure: 21kpa ~32kpa 4.Material: Aluminum alloy Installation drawings

Name

Model DO D1 H b z-d

Manholes C801A-560 Φ 560 Φ 530 88 12 24 - Φ 11

Manholes C801A-580 Φ 580 Φ 542 88 12 24 - Φ 11

manhole cover for semi-trailer
4" Aluminum Fuel Dust Cap Model: C8062 1.Outlet Size: 4" 2.Working Pressure: 0.3Mpa 3.Material :Aluminum Alloy4.high quality and competitive price

D ust Cap * With Lead Sealing Position To meet the demand of lead sealing.

Aluminum API Loading And Unloading Valve

Material : Aluminum Alloy/Stainless Steel Temperature range: -20 -- +70

Model: C806D-100

Model:

C806C-100

Brief Description: 1.Nominal diameter: 4" 2.Working pressure: 0.6Mpa 3.Max flow rate: 2500L/min 4.Open method: Mechanical

Aluminum API Loading And Unloading Valve

Model: C806B-100

Brief Description: 1.Nominal diameter: 4" 2.Working pressure: 0.6Mpa 3.Max flow rate: 2500L/min 4.Open method: Mechanical

Model: C806M-100

Stainless Steel API Openable Adaptor Valve

Model: H806D-100

Model: C8061-65/80/100

Brief Description: 1.Outlet Size: 2.5", 3", 4" 2.Working Pressure: 0.3Mpa 3.Material :Aluminum alloy

Model: F806S-100

Brief Description: 1.Temperature range: -20-- +70 2.Working pressure :0.2 Mpa 3.Material : Enhanced plastic

Model: C8062

Model: C806J-80

Aluminum Fuel Tanker Adaptor Valve

Model: C806S-80

Model: QF01-50/65/80/100

4 inch Aluminum Straight-through Ball Valve

Model: QF02F-50/65/80/100

Aluminum Float Ball Valve

Model: QF03

pneumatic fuel tanker actuator ball valve

Model: QF02FQA

Fuel Tanker Pneumatic Ball Valve

Model: QF02FQB

Fuel Tanker T- Type Strainer

Model: LW50/65/80

Model: C804CQ-100

Aluminum 3 Inch Pneumatic Bottom Valve

Model: C804CQ-80

Fuel Tanker Pneumatic Emergency Shutoff Bottom Valve

Model: C805Q-100

Model: C804AS-100

Model: C804CS-100

Model: C804BS-80

Model: C804CS-80

Model: C804TQ-100

4 Inch Oil Tanker Pneumatic Bottom Valve

Model: C804DPQ-100

Balance T Type Emergency Bottom Valve

Model: C804LPQ-100

Aluminum Pressure Balancing Pneumatic Control Bottom Valve

Model: C804TPQ-100

Stainless Steel Square Outlet Fuel Tank Bottom Valve

Model: H804A-80

Model: H804B-1000

Aluminum Optic Anti-Overfill Top Sensor

Model: CFY01/CFY01A

Aluminum Optic Sockets

Model: CFY02

Brief Description: 1. CFY02 Optic Socket is used to transfer the electrostatic signal and overflow signal between the Tanker and the Loading Pla

Ground Bolt

Model: CFY03

CFYJ Optic Sensor System Tester

Model: CFYJ-01/02

Nylon Fuel Predictor

Model: GT01

Aluminum Fuel Predictor

Model: GT02

Model: JLKJ01

Loading & Unloading Elbow

Model: JLKJ02

Brief Description: 1. Material : Aluminum alloy 2.JLKJ02 : Loading and Unloading Elbow 3.Competitive price ,high quality

Oil tanker Spill Container

Model: JLRQ01

Brief Description: 1. Material : Carton Steel 2. Feature:This container is to collect the leakage fuel when the tanker is loading.

Aluminum Vacuum vent relief Valve

Model: KHX-50

Brief Description: 1.Material: Aluminum Alloy 2.Pressure 3.Size: DN504.Competitive price ,high quality

Oil Tanker Vapor Recovery Joints

Model: KGH-80

Brief Description: 1. Material: Aluminum Alloy 2.Ways of COnnection:Pipeline type 3.Diamter :3"

T- Float Valve

Model: KSF-80

Brief Description: 1.Material: Aluminum alloy 2.Diameter : 3" 3.Ways of Connection: Screwd-type 4.Working pressure : 0.3 MPa

Fuel Tanker Pneumatic Control Block

Model: QK01/02/03/04...07

Brief Description: 1. Air hose dimeter :6 mm 2. Working pressure : 0.5--0.8 MPa 3. Temperature range:-20 -- +50

Emergency Button

Model: QAN01

Fuel Water Vapor Separator

Model: QSY01 .

Push & Pull Button

Model: SL01

Aluminum Pneumatic Air Interlock Valve

Model: QL01/QL01L

Tanker Manual Component Bottom Loading Handles

Model: SZJ-01/02/03...08 .

Oil tanker mechanical Discharge Cable Set

Model: LS01

Discharge Cable Controller

Model: LZ01/02/03

Aluminum Fuel Tanker Mechanical Top loading Handier

Model: LG01

Aluminum Handier

Model: LG02

.

Aluminum Fast Coupler Cap

Model: DC25/40/50/65/80/100

Quick Coupler Inner Plug

Model: DNI25/40/50/65/80/100

Male Quick Coupler For Fuel Tanker

Model: DN25/40/50/65/80/100

Quick Female Coupler

Model: DN25/40/50/65/80/100

Quick Change Coupler Round Tube Joint

Model: DN65/80/100

Aluminum Male Coupler With Flange

Model: DN50/65/80/100

Pipeline Male Coupler With Flange Quick Coupler

Model: DN65/80/100

Female Coupler With Threaded Outside Quick Coupler

Model: DN25/40/50/65/80/100

Aluminum Quick Connect Coupler

Model: DN25/40/50/65/80/100

Female to Female Coupler

Model: DN25/40/50/65/80/100

Aluminum throughway float valves

Model: QF02Y-50/65/80/100/125/150

manhole cover for semi-trailer

Model: C801A-560/580

Brief Description: 1.Whole diameter: 20" 2.Nominal diameter:10" 3.Emergency open pressure: 21kpa -32kpa 4.Material: Aluminum Alloy

20 Inch four holes tank manhole cover

Model: C801B-560/580

al: Aluminum alloy

Aluminium Fuel Tank Top Loading Tanker Cover

Model: C801C-460

Cast Iron Hooped Type Manhole Cover

Model: C801TB-500

Stainless Steel Full Opening Manhole Cover

Model: H801A-500/H801B-500

Stainless Steel Oil Safety Valve

Model: H802-80

Aluminum Alloy Fuel Tanker Manhole Cover d460

Model: C801A-460
