24000L 290HP Water Bowser 6x4 for sale
Overall dimensions 9800X2495X3130mm Curb weight 12840kg
Tank dimensions 6500×2300×1535mm Tank volume 20000L
Chassis parameters
Chassis model SX1255UM434 Chassis brand SHACMAN
Overall dimensions 9271x2490x3121mm Wheel base 4325+1350mm
Front/rear wheel track 1939/1800/1800mm Front/rear suspension 1576/2020mm
Approach/departure angle 18/17° Maximum speed 92km/h
Chassis Manufacturer Shanxi Automobile Group Co., Ltd.
Cab Configuration Aolong medium a row and a half deluxe cab(with sleeping berth),allowable 3 passengers, manual windows shake machine,hydraulic main seat, traveling data recorder
Color White,other color is optional
Engine Model WP10.290E32
Emission Euro 3
Type 6 cylinders,in-line,4-stroke,water-cooled,turbo inter-cooling, exhaust valve brake, direct injection diesel engine
Rated power 290hp,rated power speed 2200rpm
Displacement 9726ml
Max.torque 1160N.m
Bore x stroke 126x130mm
Manufacturer Weichai Power Co., Ltd.
Tire Size 12.00R20 steel wire tire
Number 10+1 nos
Clutch φ430 diaphragm clutch
Frame 850 × 300 (8 + 5)mm
Fuel tank 380L iron oil tank
Front axle STR,6.5 tons
Rear axle STR,13.0 tons double level,main reduction ratio 4.8
Drive form 6X4
Suspension Multi leaf springs
Rated voltage 24V,DC
Transmissions gearbox 9JS119, 9 speed forward 1 reverse.
Steering device Power assisted steering,domestic steering machine
Steering wheel Left hand drive
Selective configuration Air conditioner, wheel base 4600+1350mm,5000+1350mm,5625+1350mm
If there is a slight change in the chassis parameters above,please take the actual product as the standard
Water tank structure
Tank dimensions 6500×2300×1535mm Tank volume 20000L
Tank material Carbon steel Tank thickness 5mm or stainless steel
Nozzle sprinkling width ≥14m Range of water cannon ≥28m
Suction height ≥7m Color and Logo Optional
Standard configuration Chassis, sub frame, carbon steel water tank, manhole, water pump, front/side/rear spray nozzle,rear working platform,water cannon,fire valve, water valve, filter gauze,water hose, climbing ladder.
Selective configuration Stainless steel/aluminum alloy water tank,insulation layer for water tank,stainless steel water pump, fire pump, fire gun,pesticide plate, cabin gas control operated, Honda pumps, lights, crane, hanging basket, rear spraying device, barrel pesticide spraying device, gasoline pesticide machine, diesel pesticide machine, LED arrow lights
Extended model water transporting truck, thermal insulation water transporting truck, drinking water tank truck, liquid food truck, fire water tank truck, pesticide spraying truck,and etc.
Overall dimensions 11996X2496X3474mm Curb weight 14470kg
Tank dimensions 8100×2300×1535mm Tank volume 30000L
Chassis parameters
Chassis model SX1315TM4561 Chassis brand SHACMAN
Overall dimensions 11726x2490x3170mm Wheel base 1800+4500+1350mm
Front/rear wheel track 1939/1800/1800mm Front/rear suspension 1576/2500mm
Approach/departure angle 18/14° Maximum speed 92km/h
Chassis Manufacturer Shanxi Automobile Group Co., Ltd.
Cab Configuration Aolong medium a row and a half deluxe cab(with sleeping berth),allowable 3 passengers,ordinary air filter,manual windows shake machine,hydraulic main seat, traveling data recorder
Color White,other color is optional
Engine Model WP10.310E32
Emission Euro 3
Type 6 cylinders, in-line, 4-stroke,water-cooled,turbo inter-cooling, exhaust valve brake, direct injection,diesel engine
Rated power 310hp,rated power speed 2200rpm
Displacement 9726ml
Max.torque 1250N.m
Bore x stroke 126x130mm
Manufacturer Weichai Power Co., Ltd.
Tire Size 12.00R20 steel wire tire
Number 12+1 nos
Clutch φ430 diaphragm clutch
Frame 850×300(8+5)mm
Fuel tank 380L iron oil tank
Front axle STR,6.5 tons
Rear axle STR,13.0 tons double level,main reduction ratio 4.8
Drive form 8X4
Suspension Multi leaf springs
Rated voltage 24V,DC
Transmissions gearbox 9JS135, 9 speed forward 1 reverse.
Steering device Power assisted steering,steering machine (domestic ZF technology)
Steering wheel Left hand drive
Selective configuration Air conditioner, engine 340hp
If there is a slight change in the chassis parameters above,please take the actual product as the standard
Water tank structure
Tank dimensions 8100×2300×1535mm Tank volume 30000L
Tank material Carbon steel Tank thickness 5mm
Nozzle sprinkling width ≥14m Range of water cannon ≥28m
Suction height ≥7m Color and Logo Optional
4x2, 4x4, 6x4, 6x6, 8x4 Water Bowser for your selection, LHD and RHD cabin are both available.
Water Truck,Shacman 24000L Water Truck,Shacman 24000L Water Bowser,Shacman 24000L Spraying Truck,Shacman 24000L water tank lorry,Shacman 24000L Water Cart,Shacman 24000L Water Tanker, Shacman 24000L Water Wagon,Shacman 24000L Water Tanker Truck,Shacman 24000L Water Sprinkler Truck,Shacman 24000L Watering Vehicle,Shacman 24000L Watering Cart
| Parts | Technical Parameter | Remark |
| Overall | Chassis Model | SX1255UM434 |
|
| Curb Weight | 10305kg |
|
| Rated Loading Weight | 24000kg |
|
| Overall Size (L*W*H) | 9900×2500×3380mm |
|
| Engine | Type of Fuel | Diesel |
|
| Brand/Model | WP/WP10.290E32 |
|
| Horse Power | 290HP |
|
| Chassis | Brand | SHACMAN |
|
| Wheelbase | 4325+1350mm |
|
| Cabin | Left-hand driving, Air conditioner, Flat headed, One sleeping berth |
| Transmission | 9JS119 |
| Brake System | Pneumatic brake |
| Tyre | Specification | 12.00R20 |
|
| Number of Tyre | 10+1 spare tyre |
|
| Tanker | Tanker Capacity | 24000L |
|
| Compartment | Single/Multi | Optional |
| Material | Q235-A carbon steel | WuHan Iron and Steel (Group) Corp. |
| Thickness | 5mm |
|
| Pumping System | A pump with the function of loading and unlaoding |
| Note | Some components are optional according to your requirements. |
Our water tank truck with different chassis, eg:DFAC, DFL, SINOTRUCK, CNHTC,NORTH BENS, FOTON, ISUZU, JAC, JMC, KAMA, YUEJIN, etc.
Our water tank series:
-----water tanker truck
-----sanitation water tank truck
-----sprinkler truck
-----water wagon truck
-----insulation water tank truck
-----pesticide sprinkling truck
-----water spraying truck
-----Mild steel water tank cart
-----Stainless steel tank water truck
-----Aluminum alloy water tanker
-----RHD watering cart
-----Water tank semi trailer
-----Storage water tanker
Water Truck
30000L Water Truck
24000L Water Bowser
6000L Spraying Truck
4000L Pesticide Truck
3000L Water Cart
22000L Water Tanker
20000L Water Wagon
12000L Water Tanker Truck
10000L Water Sprinkler Truck
8000L Watering Vehicle
7000L Watering Cart
Water truck can be used for spraying water, suppressing dust, high and low spraying, pesticide spraying, rail and construction washing and other functions, but also has the function of water transport, milk transport, water drainage, emergency fire and so on.
