Sino Steyr 6x4 Wrecker Truck

Sino Steyr 6x4 Wrecker Truck
Availability:
Quantity:
DTA5250TQZZ Sino Steyr 6x4 wrecker truck



         Name




         Steyr ZZ1256M4646C towing and crane separate wrecker




         Chassis model




          ZZ1256M4646C




         Towing (T)




         55




         Crane lifting capacity  (T)




         16




         Lifting  (T)




         20




         Specs of truck




         Outside dimension(LWH mm)




          9500*2500*3550,3600




         Total mass(kg)




          25000




         Loading mass(kg)









         Kerb mass(kg)




          19880




         Approach/departure angle (mm)




          15/14




         Front/rear suspension(mm)




          1560/1990




         Fuel type




         Diesel




         fuel consumption (L)




          24




         Max Speed




          90




         Specs of engine




         model




          WD615.92,WD615.93




         Displacement / power(kw)




          9726/196,213(266HP,290HP)




         Producer




         China heavy truck motor group.




         type




          6 cylinder inline, electrical control and Turbo Charged diesel engine




         Specs of chassis




         Driving type




          6×4




         wheelbase(mm)




          4600+1350




         Tread( front/rear)




          1939,1800/1800




         Front axle




          6.5T




         Rear axle




          16T*2




         Steering




          Power




         Gear box




         8 controller




         cab




          Flat head




         Spring file(front/rear)




          9/12




         Tire specs




          11.00-20




         Air condition




         Optional




         Specs of wrecker




         Rating lifting capacity (kg) 5500



         Telescopic distance(mm) 1700



         Max length of arms(mm)2850



         Max. towing speed(km/h) 40




         Specs of crane




         Rating capacity (kg) 10000*2



         Max. height (mm) 9600



         Telescopic distance(mm) 3530



         Telescopic distance of supporting leg(mm) 800



         Max. Supporting fertility (KN):120




         Winch




         Number 2



         Rating towing capacity (kg) 30000



         length of steel rope (m) 40



          Speed of steel rope (m/min) 4



 Standard equipment
 Two stage extension boom
 Two hydraulic winches
 Monolithic tool box
 Three lights
 A group of fitting
 Wheel lifting device
 Auxiliary plug-in electric-pneumatic devices



 Optional equipment
 Wired remote control system
 Rescuing equipment and tools
 Black-and-white monitor


 Technical data
 Chassis Model: ZZ1256M4646C

 Axle: Tandem

 Engine: 196kw, six cylinder, Weichai Pover

 Transmission: Howo 10-speed, Manual

 Cab: Extended cab with A/C

 Max. Lifting capacity (kg): 18,000
 Max. Towing and drawing capacity (kg): 25,000
 Max. Lifting height (mm): 6,500
 Swing angle of lift boom (°): 5.0~33
 Winch rated pulling force (KN): 100x2
 Length of the wire rope (m):  45x2
 Wheelbase (mm): 5825+1350



  In need of a custom built Recovery Vehicle?



 Well look no further and learn how the skilled team is ready to build your next recovery vehicle to your specifications!



 Whether your starting or expanding a fleet, we can provide an affordable solution to satisfy your recovery needs without sacrificing quality. Our base model recovery bodies are very capable; however, customers have a variety of additional upgrades to build their own recovery vehicle to handle the toughest tasks. We offer customers the freedom to choose everything from recovery body to wheelbase length, hydraulic winch and your choice of color. Only new engines, hydraulic systems and P.T.O. systems are installed to insure dependability and overall customer satisfaction.



 That's our specialty and with a talented team of welders, electricians, and mechanics the craftsmanship is displayed throughout our custom built recovery vehicle.

  Customization, Cost and Control Built How You Want it, at a Price You Can Afford. for sale call:+86-152 -7135-7675

 TIC TRUCKS , www.truckinchina.com

Sino Steyr 6x4 wrecker truck  heavy duty rotator road wrecker
