Availability: | |
---|---|
Quantity: | |
Ask for better price
Cell +8615271357675
The pictures are for your reference only.
1.Fifth wheel height 1300mm.
2.wheelbase:5790+1360+1360mm,king pin size 50# or 90#,
3. 3*13ton fuwa axles with airbag suspension , with ABS ,16T Brake Pads,
Parts | Technical Parameter | Remark | ||
Overall | Curb Weight | 7950kg | ||
Rated Loading Weight | 32050kg | |||
Overall Size (L*W*H) | 13000×2500×3975mm | |||
Brake System | Pneumatic brake | |||
Tyre | Specification | 12.00-20 | ||
Number of Tyre | 12+1 Spare Tire | |||
Tanker | Max Capacity | 48000L | ||
Compartment | Single/Multi | Optional | ||
Material | Stainless steel | SS304 /316L | ||
Thickness | 6mm | |||
Pumping System | Optional | |||
Note | Some components are optional according to your requirements |
Main Dimensions | |
Tank Body | |
Shape | Optional(Round or Suare) |
Dimension | 12000mm*2490mm*3990mm(Exact size depend on the final design) |
Tare Weight | About 8000Kg-12800Kg |
Total Volume(m3) | 25m3-60m3 |
Tanker Body Material | 5mm or 6mm Stailess steel |
End Plate | 5mm or 6mm/Q235 Stailess steel |
Manhole Cover | Stailess steel API manhole cover ,500mm |
Bottom Volume | Stailess steel API Pneumatic Bottom Valve |
Discharging Valve | Diameter is 3 or 4 inch |
Compartments | Optional |
Discharging Pipe | 4" rubber hose,2 pcs,6m/each |
Cat Walk | With (Common model or special design) |
Chassis | |
Main Beams | Welding design or special design I beam ,connected by bolts and nuts Q345 carbon steel material |
Axle | 2 or 3 axles, BPW/FUWA/HUAJING brand |
Landing Gear | JOSTD200T or China brand 28T |
King Pin | JOST 2.00 OR 3.5 inch bolt-in king pin |
Suspension | Mechanical suspension(Germany or American type)/air suspension |
Leaf spring | 90(w)mm*13(Thickness0mm*10 layer or 100mm*12mm*12/without |
Pneumatic Braking System | WABCO RE 6 relay valve;Spring brake chamber;2 pieces of 45L air tanks. |
Rim | 9.00-22.5/8.00-20/8.5-20 China brand |
Tire | 12.00R22.5/315 80R22.5/11.00R20/12.00R20 Brand can be optional |
ABS | Optional |
Painting | Complete Chassis and blasting to clean rust,1 coat of anticorrosive prime,2 coats of final paint |
Accessories | One standard tool lox |
Shipping Terms | By bulk cargo ship, RORO or 40HQ container |
2
30,000L-45,000L 3-axle Tank Semi-trailer | |||
Feature: | Carry Fuel, Oil, Diesel, Drink water, Milk, Beer and other chemical liquid | ||
Dimension(L*W*H): | 11000*2500*3700mm(30,000L) 11700*2500*3750mm(40,000L) 12700*2500*3750mm(50,000L) 13000*2500*3750mm(60,000L) 13700*2500*3750mm(70,000L) | ||
Model | DRZ9350GRY | ||
Material: | Carbon Steel | Stainless Steel | Aluminum |
Compartment: | 3-6 | ||
Capacity(kgs): | 35,000L-45,000L | ||
Tare weight(kgs): | 10,000-11,000kgs | 10,000-11,000kgs | 6,000-7,000kgs |
Kingpin | The world-famous JOST brand bolt-in/welded type 3.5"/2" | ||
Landing gear | JOST brand two-speed manual operation 19" | ||
Tire size | 11.00R20,11R22.5,12R22.5,315/80R22.5,385/65R22.5 | ||
Rim size | 8.25*22.5,9.00*22.5,11.75*22.5 | ||
Axle | Original BPW-12T/ FUWA-13T | ||
Leafs spring | Germany type with 12pcs of leafs spring/ Fuwa brand with 8pcs of leafs spring/ Airbag suspension | ||
Brake system | One unit WABCO RE 4 relay valve; four units T30/30 spring brake chamber; two units T30 spring brake chamber; two units reliable local brand 45L air tank; two units reliable local brand standard coppery air-connector. | ||
Manhole: | Aluminum alloy ø500mm(20") manhole with aluminum alloy cover; with breather valve; | ||
Discharge Valve | Aluminum alloy discharge valve with cover | ||
Foot Valve | Pneumatic control DN80 aluminum alloy foot valves | ||
Pneumatic Control system | 1set Pneumatic Control combined switch 1unit emergency switch | ||
Discharge Hose | 2 units 3"×6M factory PVC hose with quick coupling on both ends | ||
Vapor Recovery & Overfill system | Optional | ||
Fire Extinguisher Carrier | 2 units at the left of rear of tanker, include 2 units 8kg dry powder type fire extinguisher inside | ||
Electric system: | One unit of 24V 7-pin ISO standard socket; with brake light, turn light, reverse light, side light, reflector, fog light; one set of 6-pin standard cable | ||
Prime & Topcoat painting | S.A.2.5standard sandblasting ;Zinc-rich & Polyurethane painting | ||
We can build the trailers according to customer's design and requirement |
Customization, Cost Control Built How You Want it, at a Price You Can
Afford. for sale call:+86-152 -7135-7675
Cell :+8615271357675
Ask for better price
Cell +8615271357675
The pictures are for your reference only.
1.Fifth wheel height 1300mm.
2.wheelbase:5790+1360+1360mm,king pin size 50# or 90#,
3. 3*13ton fuwa axles with airbag suspension , with ABS ,16T Brake Pads,
Parts | Technical Parameter | Remark | ||
Overall | Curb Weight | 7950kg | ||
Rated Loading Weight | 32050kg | |||
Overall Size (L*W*H) | 13000×2500×3975mm | |||
Brake System | Pneumatic brake | |||
Tyre | Specification | 12.00-20 | ||
Number of Tyre | 12+1 Spare Tire | |||
Tanker | Max Capacity | 48000L | ||
Compartment | Single/Multi | Optional | ||
Material | Stainless steel | SS304 /316L | ||
Thickness | 6mm | |||
Pumping System | Optional | |||
Note | Some components are optional according to your requirements |
Main Dimensions | |
Tank Body | |
Shape | Optional(Round or Suare) |
Dimension | 12000mm*2490mm*3990mm(Exact size depend on the final design) |
Tare Weight | About 8000Kg-12800Kg |
Total Volume(m3) | 25m3-60m3 |
Tanker Body Material | 5mm or 6mm Stailess steel |
End Plate | 5mm or 6mm/Q235 Stailess steel |
Manhole Cover | Stailess steel API manhole cover ,500mm |
Bottom Volume | Stailess steel API Pneumatic Bottom Valve |
Discharging Valve | Diameter is 3 or 4 inch |
Compartments | Optional |
Discharging Pipe | 4" rubber hose,2 pcs,6m/each |
Cat Walk | With (Common model or special design) |
Chassis | |
Main Beams | Welding design or special design I beam ,connected by bolts and nuts Q345 carbon steel material |
Axle | 2 or 3 axles, BPW/FUWA/HUAJING brand |
Landing Gear | JOSTD200T or China brand 28T |
King Pin | JOST 2.00 OR 3.5 inch bolt-in king pin |
Suspension | Mechanical suspension(Germany or American type)/air suspension |
Leaf spring | 90(w)mm*13(Thickness0mm*10 layer or 100mm*12mm*12/without |
Pneumatic Braking System | WABCO RE 6 relay valve;Spring brake chamber;2 pieces of 45L air tanks. |
Rim | 9.00-22.5/8.00-20/8.5-20 China brand |
Tire | 12.00R22.5/315 80R22.5/11.00R20/12.00R20 Brand can be optional |
ABS | Optional |
Painting | Complete Chassis and blasting to clean rust,1 coat of anticorrosive prime,2 coats of final paint |
Accessories | One standard tool lox |
Shipping Terms | By bulk cargo ship, RORO or 40HQ container |
2
30,000L-45,000L 3-axle Tank Semi-trailer | |||
Feature: | Carry Fuel, Oil, Diesel, Drink water, Milk, Beer and other chemical liquid | ||
Dimension(L*W*H): | 11000*2500*3700mm(30,000L) 11700*2500*3750mm(40,000L) 12700*2500*3750mm(50,000L) 13000*2500*3750mm(60,000L) 13700*2500*3750mm(70,000L) | ||
Model | DRZ9350GRY | ||
Material: | Carbon Steel | Stainless Steel | Aluminum |
Compartment: | 3-6 | ||
Capacity(kgs): | 35,000L-45,000L | ||
Tare weight(kgs): | 10,000-11,000kgs | 10,000-11,000kgs | 6,000-7,000kgs |
Kingpin | The world-famous JOST brand bolt-in/welded type 3.5"/2" | ||
Landing gear | JOST brand two-speed manual operation 19" | ||
Tire size | 11.00R20,11R22.5,12R22.5,315/80R22.5,385/65R22.5 | ||
Rim size | 8.25*22.5,9.00*22.5,11.75*22.5 | ||
Axle | Original BPW-12T/ FUWA-13T | ||
Leafs spring | Germany type with 12pcs of leafs spring/ Fuwa brand with 8pcs of leafs spring/ Airbag suspension | ||
Brake system | One unit WABCO RE 4 relay valve; four units T30/30 spring brake chamber; two units T30 spring brake chamber; two units reliable local brand 45L air tank; two units reliable local brand standard coppery air-connector. | ||
Manhole: | Aluminum alloy ø500mm(20") manhole with aluminum alloy cover; with breather valve; | ||
Discharge Valve | Aluminum alloy discharge valve with cover | ||
Foot Valve | Pneumatic control DN80 aluminum alloy foot valves | ||
Pneumatic Control system | 1set Pneumatic Control combined switch 1unit emergency switch | ||
Discharge Hose | 2 units 3"×6M factory PVC hose with quick coupling on both ends | ||
Vapor Recovery & Overfill system | Optional | ||
Fire Extinguisher Carrier | 2 units at the left of rear of tanker, include 2 units 8kg dry powder type fire extinguisher inside | ||
Electric system: | One unit of 24V 7-pin ISO standard socket; with brake light, turn light, reverse light, side light, reflector, fog light; one set of 6-pin standard cable | ||
Prime & Topcoat painting | S.A.2.5standard sandblasting ;Zinc-rich & Polyurethane painting | ||
We can build the trailers according to customer's design and requirement |
Customization, Cost Control Built How You Want it, at a Price You Can
Afford. for sale call:+86-152 -7135-7675
Cell :+8615271357675
