3Axle gooseneck detachable Lowbed Trailer export

Views: 1657     Author: Dong Runze Special Vehicle      Publish Time: 2017-07-10      Origin: Dong Runze Special Vehicle

3Axle gooseneck detachable Lowbed Trailer export

 3Axle gooseneck detachable Lowbed Trailer

for 60Ton-80ton HEAVY & OVERSIZE LOAD US $43,000-48,000 / Set

Trailer Model

3Axle gooseneck detachable Lowbed Trailer

Overall Dimension(Lx W x H)(mm)

14900*3000*1500

Platform size (Lx W x H)(mm)

700*3000*700

Function

Transport  excavator

Tare Weight(KG)

14500

Loading Weight( KG)

80000

Axle Brand

FUWA 13TON

Axle Number

Three

Gooseneck

Hydraulic detachable

The width of Outrigger

30cm, 22pcs

Wheelbase(mm)

762+1244+1244

Suspension system

Common Mechanical suspension

Steel Spring

10/10/10 leaf spring suspension

The material of Main beam

The height of the beam is 500 mm,

upper plate is18mm,down plate is 20mm,

middle plate is 12mm.

Platform plate

3mm Diamond plate

Tire Type and quantity

1100R22.5  12units

Traction Pin

2'', 1 set

Tool Box

1 Standard

Landing Gear

Standard 28Ton

Brake system

Dual Line braking system ,none ABS.

Brake air chamber

Two double and two single chamber

Side Guard

According to customer's requirement

Painting

Red or white

Packing

Polish with wax before shipping

  Details Pictures Manufacturing process

Hydraulic Gooseneck-144Ton-Hyraulic Detachable Lowboy.jpgGooseneck deatachable trailer-84Ton-Hyraulic Detachable Lowboy.jpgHydraulic Gooseneck-125Ton-Hyraulic Detachable Lowboy.jpg

Gooseneck Low Bed ,Hydraulic-neck low-bed trailer,Hydraulic Detachable Gooseneck, Detachable Gooseneck  Lowboy,Removable Gooseneck Lowboy Trailer,Hyraulic Detachable Neck Low Bed ,Detaching lowbed neck,
