JAC 3 ton compactor garbage truck for sale
Views: 1744 Author: Dong Runze Special Vehicle Publish Time: 2017-09-01 Origin: Dong Runze Special Vehicle
JAC Small compression garbage trucks
JAC 3 ton compactor garbage truck for sale US $20,000-22,000 / Set
JAC Small 7 ton compression garbage trucks For Sale
[Chassis Specifications] | |||
Chassis Model | HFC1070P93K1C3ZV | Chassis name | Truck chassis(II) |
Chinese Brand | Jianghuai brand | manufacturers | Anhui Jiang Huai Automobile Corp |
Outline dimension(mm) | 5815,5773,5255×1860,1830×2180 | Tires | 6 |
Approach / departure angle(°) | 27/17.5 | Tire specifications: | 7.00R16,7.00-16 |
Number of leaf springs | 8/4+6,11/9+7,7/4+6 | Track front(mm) | 1440 |
Fuel | diesel | Track rear(mm) | 1425,1395 |
Emission standard | GB17691-2005 Euro5,GB3847-2005 | ||
Chassis Model | Engine manufacturer | Displacement(ml) | Power(Kw) |
WP3Q130E50
HFC4DF1-2D2
D25TCIE1
HFC4DA1-2D | Weichai Power Yangzhou Diesel Engine Co. Ltd. Hefei Jianghuai chaochai Power Co. Ltd. Kunming Yunnei Limited by Share Ltd Anhui Jiang Huai Automobile Corp | 2970
2544
2499
2771 | 96
86
105
88 |
JAC Small Garbage Truck
This kind of garbage truck is made of the chassis, cargo box, open-door structure, lifting structure,
and electro-hydraulic control system.
It is mainly used to transporting the daily wastes, but sometimes it is also could be used to transport bulk construction materials, like ash, sand, stone, soil, etc, and carry ore and coal in mines.
Chassis type | HFC1065K1DT | |
Cubage(cbm) | 5-5.5 | |
Parameters | Overall dimension length/width/height (mm) | 6530×2050×2400 |
Total Mass(kg) | 6495 | |
Kerb Mass(kg) | 5070 | |
Approach angle/ Departure angle(mm) | 23/10 | |
Front suspension/rear suspension(mm) | 1105/2117 | |
Fuel Type | diesel | |
Max Speed | 95 | |
Engine | Type | HFC4DA1-2B2/YC4F115-30 |
Displacement/Power(kw) | 2771 /88 | |
Manufacturer | Anhui Jianghuai engine company/ Guangxi Yuchai engine company | |
Type | ||
Chassis | Drive type | 4×2 |
Wheelbase(mm) | 3308 | |
Tread(front/rear) | 1580 / 1395 | |
Front axle | 2.5Ton | |
Rear axle | 4Ton | |
Steering gear | Recirculation ball steering | |
Transmission | 5 forward gear,1 reverse gear,manual mechanical type | |
Clutch | Uniwafer, dry clutch, hydraulic remote control | |
Braking system | Air brakingcam drum braking | |
Cab | Non-long headed cabin | |
Number of spring axle(front/rear) | 3/9+7,5/9+7 | |
Tire Type | 6.50-16,7.00-16 | |
Air-condition | Choose to fix | |
China garbage truck manufacture direct sale for JAC HFC1070P73K2C3Z compactor garbage vehicle 4*2 6 cbm sale invietnam
US $24500-27500 / Unit
Volume: 6001 - 10000L
Drive Wheel: 4x2
Emission Standard: Euro 4
JAC compactor garbage truck prices,8CBM garbage compression truck price
US $21800.0 / Set
Drive Wheel: 4x2
Gross Vehicle Weight: 16000
Engine Capacity: 6700
Transmission Type: Manual
Emission Standard: Euro 3
2016 New type 10 ton jac compactor garbage trucks for sale in DR Congo
US $32000-45000 / Piece
1 Piece (Min. Order)
Dimensions (L x W x H) (mm): 9800X2496X3048
Transmission Type: Manual
Gross Vehicle Weight: 25000
Brand Name: 20ton compactor garbage truck
low price factory sale JAC 10m3 side self-loading medical garbage truck
US $18800-19300 / Set
Model Number: DRZ5041XYY4
Drive Wheel: 4x2
Engine Capacity: 2771
Type: Recycling
China garbage truck company direct sale for HFC1166K1R1ZF JAC gallop LHD 6 wheels street cleaning vehicle 10cbm sale in uae
US $43000-46000 / Unit
Model Number: SCS5161ZYSZ
Volume: 6001 - 10000L
Drive Wheel: 4x2
Gross Vehicle Weight: 15950
JAC Small 7 ton compression garbage trucks For Sale
US $35000.0-38000.0 / Set | Buy Now
Gross Vehicle Weight: 7360
Engine Capacity: 2970
Transmission Type: Manual
After-sales Service Provided: Engineers available to service machinery overseas
Brand Name: JAC
JAC 12 m3 compactor garbage collection truck
US $10000-30000 / Unit
Model Number: DRZ
Gross Vehicle Weight: 14490
Engine Capacity: 6500
Type: Compactor
Size: 8845*2495*3005mm
International JAC 4x2 LHD RHD 8m3 Garbage Compactor Truck Waste Rubbish Refuse Collector Manufacturer
US $5000-38000 / Unit
Dimensions (L x W x H) (mm): 9000*2490*3600
Transmission Type: Manual
Brand Name: DRZ
Drive Wheel: 4*2 4*4 6*2 6*4 6*6 8*4 8*6
JAC 6X4 rear loader refuse compactor refuse compactor garbage truck
US $22375-23375 / Unit
Volume: > 15000L
Engine Capacity: 6494ml
Transmission Type: Manual
JAC 10 cubic meters waste compactor trucks
US $20000-35000 / Unit
Drive Wheel: 4x2
Engine Capacity: >5 L
Type: Compactor,JAC 10 cubic meters waste compactor trucks
Transmission Type: Manual
Emission Standard: Euro 4
Size: 3845*1560*1636
China JAC Compactor Truck for sale insouth africa
US $36000.0-38000.0 / Set
Model Number: DRZ5070ZYS
Volume: 6001 - 10000L
Good quality 6 wheels JAC 4 CBM 5 CBM garbage compactor truck rear loader truck for hot sale
US $18000-28000 / Unit
Model Number: DRZ5070ZYS
Volume: 3001 - 6000L
Type: Compactor
Emission Standard: Euro 3
JAC 3ton mini compactor rubbish truck
US $20000-21000 / Set
Drive Wheel: 4x2
Engine Capacity: 3707
Type: Compactor
Emission Standard: Euro 3
Brand Name: JAC
JAC 3ton mini compactor rubbish truck
diesel engine
capacity:4cbm
rear loading
hydraulic operate
Specifications:
Main specifications | ||||||||||
Product model,name | DRZ5060ZYSJAC Compression Garbage Truck | |||||||||
Gross weight(Kg) | 6495 | Driving type | 4*2 | |||||||
Payload (Kg) | 1230 | Overall dimension (mm) | 6530×2050×2400 | |||||||
Curb weight(Kg) | 5070 | Cab seats (man) | 2 | |||||||
Approach/departure angle (°) | 23/10 | Front/rear hang(mm) | 1105/2117 | |||||||
Axle No. | 2 | Wheelbase (mm) | 3308 | |||||||
Axle load(Kg) | 2550/3945 | Max speed(Km/h) | 95 | |||||||
Chassis specifications | ||||||||||
Chassis model | HFC1071K1T | Manufacture | Dongfeng automobile company | |||||||
Brand name | JAC | Overall dimension (mm) | 5793*1825*2150 | |||||||
Tire specification | 7.00-16 | Tires No. | 6+1 | |||||||
Steel spring number | 3/9+7 | Front track(mm) | 1580 | |||||||
Fuel type | Diesel | Rear track(mm) | 1395 | |||||||
Emission standard | Euro Ⅲ | Gear box | 5 forward | |||||||
Cab | Flat cab with sleeper, luxurious interiors and seats, air conditioning is optional | |||||||||
Engine model | Engine manufacture | Displacement(ml) | Power(Kw) | |||||||
CY4100-E3F | Dongfeng chaoyang chaochai power co.,ltd | 3707 | 70 | |||||||
Performance | ||||||||||
Body capacity(m3) | 5 | Hopper capacity(m3) | 1.0 | |||||||
Compression cycle time(S) | 30 | Unload garbage time(S) | 40 | |||||||
Control system | Manual +Automatic | |||||||||
Main Characteristic | ||||||||||
1,Can choose 240L(single bin,double bins)or 360L,660L,1100L standard bin lifting and turnover mechanism,can also choose ground hopper and other kinds of loading mechanism. 2,With manual and automatic two sets of control method, the operator can control in the cabin, in the middle side or the back of the truck , very convenient and efficient. 3,With working device of emergency braking stop button. 4,Garbage body use frame design, elegant, strong structure, large effective capacity. 5,Equipped with special collection box, sewage directly into the sewage tank in the process of compression, that is effectively prevent second pollution caused by sewage leaks. 6,Through hydraulic system design, the truck achieve the function of two-way garbage compression, that is improve the compressibility ,make the compression ratio up to 1:2.5,the garbage can reach more then 600~800kg/m3 after compression. | ||||||||||
