ISUZU 700P 4x2 9000L-10000L water tanker for export USD 27000.00 - 28000.00 / Set/

Views: 1767     Author: Dong Runze Special Vehicle     Publish Time: 2017-06-01      Origin: Dong Runze Special Vehicle

ISUZU 700P 4x2 9000L-10000L water tanker for export USD 27000.00 - 28000.00 / Set/

ISUZU 700P 4x2 9000L-10000L water tanker for export USD 27000.00 - 28000.00 / Set/ Water tank truck is composed of automobile chassis, and out of the water system and tanker. According to the different use of the environment and the purpose of a variety of spraying and water transport function. Multifunctional sprinkler set a variety of functions as one, generally can be used by the user requirements of special restructuring.700P 4X2 8000L water street sprinkler truck 2_1700P 4X2 8000L water street sprinkler truck 4_1.jpg700P 4X2 8000L water street sprinkler- truck 2_1.jpgWater Tank Truck is suitable for various pavement washing, trees, green belt, green lawn, roads, construction of factories and mines, high-altitude construction flushing.

Water tank truck can be used for spraying water, suppressing dust, high and low spraying, pesticide spraying, rail and construction washing and other functions, but also has the function of water transport, milk transport, water drainage, emergency fire and so on.

Vehicle parameters

Vehicle Model DRZ511009GSSQ1

Overall dimensions 8490X2390X2550mm Curb weight 6150kg

Tank dimensions 4900X2380X1400mm Tank volume 9000L-10000L

Hot sale ISUZU water trucks_7000L

Chassis parameters

Chassis model QL11009MARY Chassis brand ISUZU

Overall dimensions 7930x2170x2330mm Wheel base 4475mm

Front/rear wheel track 1680/1650mm Front/rear suspension 1110/2345mm

Approach/departure angle 21/11° Maximum speed 110km/h

Chassis Manufacturer QingLing Motors (Group) Co., Ltd.

Cab Configuration 700P,single row cab,allowable 3 passengers,air conditioner, USB radio interface,cab can be flipped.

Color White,other color is optional

Engine Model 4HK1-TCG40

Emission Euro 4

Type 4 cylinders,4 valve,4-stroke,in-line,common rail,precision electronic control,multistage injection,optimal combustion,exhaust gas recirculation, diesel engine.

Rated power 190hp

Displacement 5193ml

Manufacturer Isuzu (ChongQing) Engine Co., Ltd.

Tire Size 8.25-20-14PR nylon tire

Number 6+1 nos

Frame 216x70(6+3)mm

Front axle 4.0tons

Rear axle 7.0 tons

Drive form 4×2

Suspension Multi leaf springs

Rated voltage 24V,DC

Transmissions Isuzu MLD six speed transmission,6 speed forward 1 reverse.

Steering device Power assisted steering

Steering wheel Left hand drive

Selective configuration Tire:825R16,825-20,825R20,235/75R17.5

If there is a slight change in the chassis parameters above, please take the actual product as the standard


Water tank structure parameters

Tank dimensions 4900X2380X1400mm Tank volume 15000L

Tank material Carbon steel Tank thickness 4mm

Nozzle sprinkling width ≥14m Range of water cannon ≥28m

Suction height ≥7m Color and Logo Optional

Selective configuration aluminum alloy water tank, insulation layer for water tank, stainless steel water pump, fire pump, fire gun, pesticide plate, cabin gas control operated, Honda pumps, lights, crane, hanging basket, rear spraying device, barrel pesticide spraying device, gasoline pesticide machine, diesel pesticide machine, LED arrow lights

Extended model water transporting truck, thermal insulation water transporting truck, drinking water tank truck, liquid food truck, fire water tank truck, pesticide spraying truck, and etc.

Water Spray Truck Tanker , Drinking Water Tanker Vehicle , Water Truck Tanker , Water Spray Truck , Water Spraying Truck , Water Spaying Truck

Vehicle model


Chassis brand

Chassis model

Load

Overall dimensions


Wheel base


Engine model


hp/standard

Tire


FOB Price









L

mm




mm











USD

DRZ5240GSSH


CAMC

HN1240P29E2M3J

20000

10420X2500X3560


5220+1350



WP10.270E32


270/Euro 3

11.00R20




42180

DRZ5160GSSD


DONGFENG

DFL1160BX


12000

8290X2370X2760


4700



B190 33


190/Euro 3

9.00-20




24250

DRZ5250GSSD


DONGFENG

DFL1250A9


22000

10770X2480X3100


5350+1300



C260 33


260/Euro 3

11.00R20




40550

DRZ5311GSSD


DONGFENG

DFL1311A4


30000

11980X2500X3690


1850+4600+1350

C260 33


260/Euro 3

11.00R20




44240

DRZ5060GSSE


DONGFENG

EQ1060TJ20D3

5000

5980X1980X2180


3300



CY4102-C3F


95/Euro 3

7.00-16




10750



















DRZ5090GSSE


DONGFENG

EQ1090T9ADJ3AC

6000

6995X2285X2780


3800



CY4102-E3C


120/Euro 3

7.50R16




14080

DRZ5110GSSE


DONGFENG

EQ1100FKJ


8000

7350X2440X2790


3950



YC4E140-33


140/Euro 3

9.00-20




14520


DRZ5108GSSE

DONGFENG

EQ1108KJ

10000

7450X2480X2985

3950

B170 33

170/Euro 3

9.00-20


17770

DRZ5121GSSE

DONGFENG

EQ1121GKJ

10000

7450X2480X2985

3950

YC4E160-33

160/Euro 3

9.00-20


15700

DRZ5126GSSE

DONGFENG

EQ1126KJ1

12000

8500X2460X3000

4700

B190 33

190/Euro 3

9.00-20


19830

DRZ5141GSSE

DONGFENG

EQ1141KJ

15000

8105X2490X3050

4500

B190 33

190/Euro 3

10.00-20


19980

DRZ5290GSSE

DONGFENG

EQ1290WFJ

30000

11995X2495X3690

1950+4250+1300

C280 33

280/Euro 3

11.00-20


40990

DRZ5253GSSE

DONGFENG

EQ5253GFJ2

22000

9950X2480X3550

4350+1300

B210 33

210/Euro 3

10.00-20


27580

DRZ5250GSSC

FAW

CA1250P63K1L5T1AE4Z

20000

10425X2495X3200

4800+1350

BF6M1013-28E4

280/Euro 4

11.00R20


45420

DRZ5250GSSC3

FAW

CA1250P63K2L3T1E

20000

10350X2495X2900

4800+1350

CA6DE3-24E3

240/Euro3

10.00R20


41590

DRZ1310GSSC

FAW

CA1310P63K2L6T4E

30000

11860X2495X3100

1950+4550+1350

CA6DL1-31E3F

310/ Euro 3

11.00R20


46170

DRZ5073GSSB

FOTON

BJ1073VEJEA-A

5000

5990X1955X2300

3360

4DW91-63NG2

98/ Euro 2

6.50-16


9280

DRZ5102GSSB

FOTON

BJ1102VDPEA-G1

6000

7225X2300X2680

3900

4102QBZL

130/ Euro 2

8.25-16


13640

DRZ5163GSSB

FOTON

BJ1163VKPGG-1

12000

9000×2490×3150

5000

Phaser160Ti-33

160/ Euro 3

9.00R20


22780

DRZ5257GPSB

FOTON

BJ5257GNFJH-S1

22000

10350X2490X3010

4725+1300

SC9DK270Q3B1

270/ Euro 3

10.00-20


38340

DRZ5070GSSQ

ISUZU

QL1070A1KAY

6000

7250X2300X2350

3815

4KH1-TCG40

120/ Euro 4

7.00-15


22200

DRZ5160GSSQ

ISUZU

QL1160ANFRY

16000

9000X2465X2900

5000

6HK1-TCNG40

240/ Euro 4

10.00-20


50360

DRZ5250GSSQ

ISUZU

QL1250DNFZY

20000

9480X2495X3550

4350+1300

6HK1-TCSG40

280/ Euro 4

1.00-20


63860

DRZ5050GSSQ

ISUZU

QL10503HARY

5000

5990X1870X2250

3360

4JB1CN

98/ Euro 4

7.00-15


18060

DRZ5090GSSQ

ISUZU

QL11009MARY

10000

8490X2390X2550

4475

4HK1-TCG40

190/Euro 4

8.25-20


28830

DRZ5161GSSH

JAC

HFC1161P3K2A47F

10000

8500X2500X3150

4700

YC4E160-42

160/Euro 4

11.00R20


28170

DRZ5241GSSH

JAC

HFC1241P2K1C54F

20000

11990X2500X3560

1900+5400

CA6DF4-20E4

200/ Euro 4

11.00R20


39230

DRZ5311GSSH

JAC

HFC1311P2K4H45F

30000

10980X2500X3755

1900+4500+1350

WP10.270E40

270/ Euro 4

11.00R20


49840

DRZ5254GSSN

North-Benz

ND1254B41J

20000

9770X2480X3030

4100+1350

WP10.270E32

270/ Euro 3

11.00R20


39370

DRZ5310GSSN

North-Benz

ND1310D46J7Z01

30000

11960X2495X3100

1950+4650+1350

WP10.310E32

310/ Euro 3

11.00R20


47640

DRZ5255GSSFS

SHACMAN

SX1255NN464

20000

9935X2490X3210

4575+1400

WP10.290E32

290/ Euro 3

12.00R20


42840

DRZ5315GSSFS

SHACMAN

SX1315NN4561

30000

12000X2490X3340

1800+4575+1400

WP10.270E31

270/ Euro 3

11.00R20


42400

DRZ5165GSSS

SHACMAN

SX1165UN461

15000

8620X2490X3100

4600

WP10.270E31

270/ Euro 3

12.00R20


32370

DRZ5255GSSS434

SHACMAN

SX1255UM434

20000

9800X2495X3130

4325+1350

WP10.290E32

290/ E3

12.00R20


38780


Pressure washing truck

Here the price is for standard configuration. Selective configuration and any change according to the buyer’s requirements please confirm the price with our company.Standard configurationChassis,sub frame,pressure washing tank,Italy UDOR plunger pump VX-B 130/160 R-L,reel with 60 meters pressure hose,10 units stainless steel high pressure nozzles,tool box.Selective configuration Add a sewage suction tank and vacuum pump system Extended model vacuum suction and pressure washing truck

Vehicle model

Chassis brand


Chassis model

Load


Overall dimensions

Wheel base

Engine model

hp/standard

Tire

FOB Price





L


mm

mm





USD

DRZ5160GQXD

DONGFENG


DFL1160BX

10000


8825X2495X29400

4700

B190 33

190/Euro 3

9.00-20


32000

DRZ5250GQXD

DONGFENG


DFL1250A9

18000


10790X2495X3030

5350+1300

C260 33

260/Euro 3

11.00R20


50280

DRZ5060GQXE

DONGFENG


EQ1060TJ20D3

4000


6200X2000X2200

3300

CY4102-C3F

95/Euro 3

7.00-16


16810

DRZ5090GQXE

DONGFENG


EQ1090T9ADJ3AC

5000


7000X2285X2500

3800

CY4102-E3C

120/Euro 3

7.50R16


19900

DRZ5110GQXE

DONGFENG


EQ1100FKJ

5000


7150X2450X2700

3950

YC4E140-33

140/Euro 3

9.00-20


20050

DRZ5108GQXE

DONGFENG


EQ1108KJ

6000


7320X2490X2950

3950

B170 33

170/Euro 3

9.00-20


23590

DRZ5126GQXE

DONGFENG


EQ1126KJ1

10000


8825X2495X2940

4700

B190 33

190/Euro 3

9.00-20


27580

DRZ5141GQXE

DONGFENG


EQ1141KJ

8000


7900X2490X2900

4500

B190 33

190/Euro 3

10.00-20


26700

DRZ5253GQXE

DONGFENG


EQ5253GFJ2

16000


10720×2500×3030

4350+1300

B210 33

210/Euro 3

10.00-20


36730

DRZ5250GQXC

FAW


CA1250P63K1L5T1AE4Z

16000


9940X2500X2990

4800+1350

BF6M1013-28E4

280/Euro 4

11.00R20


54860

DRZ5073GQXB

FOTON


BJ1073VEJEA-A

4000


5990X1955X2300

3360

4DW91-63NG2

98/Euro 2

6.50-16


15330

DRZ5102GQXB

FOTON


BJ1102VDPEA-G1

5000


6700X2200X2580

3900

4102QBZL

130/Euro 2

8.25-16


19460

DRZ5163GQXB

FOTON


BJ1163VKPGG-1

10000


9000X2480X2700

5000

Phaser160Ti-33

160/Euro 3

9.00R20


30520

DRZ5257GQXB

FOTON


BJ5257GNFJH-S1

18000


10372X2490X3020

4725+1300

SC9DK270Q3B1

270/Euro 3

10.00-20


48080

DRZ5070GQXQ

ISUZU


QL1070A1HAY

4000


5900X1880X2180

3360

4KH1-TCG40

120/Euro 4

7.00-16


27870

DRZ5250GQXQ

ISUZU


QL1250DNFZY

16000


10820X2500X3030

4350+1300

6HK1-TCSG40

280/Euro 4

11.00-20


73300

DRZ511009GQXQ

ISUZU


QL11009MARY

5000


7375X2175X2330

4475

4HK1-TCG40

190/Euro 4

8.25-20


33480

DRZ51609GQXQ

ISUZU


QL11609MFRY

10000


7970X2495X3060

4500

4HK1-TCG40

190/Euro 4

10.00-20


46460

DRZ5161GQXH

JAC


HFC1161P3K2A47F

10000


8374X2495X3090

4700

YC4E160-42

160/Euro 4

11.00R20


36120

DRZ5257GQXZ

SINOTRUK


ZZ1257N4341W

16000


9790X2495X3130

4325+1350

WD615.69

336/Euro 2

12R22.5


50210
