Dongfeng 6X6 EQ6840PT Cross-country Off-road Bus
| Quantity: | |
|---|---|
4wd engineering van off-road bus
Dongfeng 6x6 drive off-road bus
Dongfeng bus manufacturerhigh mobility and gradeability
short delivery time
EQ6840PT off-road bus
| V E H I C L E | length(mm) | 8380 | E N G I N E | Mode | EQ6BT5.9 | ||
| Width mm) | 2350 | ||||||
| height(mm) | 2930,3130(with A.C) | manufacturer | Dongfeng Cummins Engine Co.,Ltd | ||||
| position/fuel | Front settled/ diesel | ||||||
| Wheel base(mm) | 3190+1100 | type | Six cylinder,vertical,four strokes, water cooled, direct injection | ||||
| front/rear overhang(mm) | 1290/2790 | Rated output(kw) | 114 | ||||
| approaching/departure angle(º) | 35/23 | Max.torque(N.m) | 490 | ||||
| displacement(ml) | 5880 | ||||||
| G.V.W(kg) | 9350 | bore×stroke(mm) | 102×120 | ||||
| Seat capacity | 30(including driver) | Emission standard | Euro-Ⅱ | ||||
| Max. speed(km/h) | 85 |
|
| ||||
| Volume of luggage compartment(m3) | 0.8 m3 |
|
| ||||
| Item | Standard allocation | optional | |||||
| C H A S S I S | gearbox | C17CA1-00030-TQ |
| ||||
| By Dongfeng Motor Transmission Co,.Ltd |
| ||||||
| clutch | φ350 single plate,dried,diaphragm spring, clutch booster |
| |||||
| Front axle | Dongfeng axle (3T) |
| |||||
| Mid-axle | Dongfeng axle (3T) |
| |||||
| Rear axle | Dongfeng axle (3T) |
| |||||
| suspension | Steel plate spring |
| |||||
| steering | Power steering |
| |||||
| brake | Dual circuit full air brake;drum brake;spring actuated parking brake for rear axle |
| |||||
| Oil tank | Copper oil tank (270L) |
| |||||
| tires | 11R18 |
| |||||
| batteries | 12V 150A.h×2 |
| |||||
| others | Clutch booster; air drier; air cut brake | ABS(5000RMB);automatic slack adjuster | |||||
| B O D Y | doors | manual rotating passenger door; two doors for driver and assistant driver respectively |
| ||||
| Side windows | Push-pull glass window |
| |||||
| Rear view system | Electric side mirror |
| |||||
| Conditioning |
| Dongfeng Pai’en top settled air conditioner (20KW) | |||||
| Heating |
| Water hearting type with two mouth | |||||
| defroster | 130W defroster |
| |||||
| Video system | mp3 Radio-cassette Player with SD card connector | LCD MP4 video system 15/17/19 inch LCD MP5 video system 15/17/19 inch | |||||
| lights | Combined headlight | High mount stop lamp | |||||
| Rain wiper | Bi-direction electric rain wiper |
| |||||
| seats | General seat (two-point safety belt for passengers and three-point safety belt for drivers) | General handrail/mid-range rotating handrail | |||||
| paint | Domestic paint (three layers) | Metallic paint | |||||
| others | Dong Feng 0ff-the-road bus chassis, 6x6drive, front settled engine, left hand drive,mechanical manual gearbox,, reer abat vent curtain, domestic paint, electric fan in driving compartment, electronic clock, air horn, two safety hummers, bamboo veneer floor+vinyl floor | Scuttle, outer luggage rack), alarm light,aluminum pattern floor for passenger area, bumper | |||||
