SEPTIC, SEWER TRUCKS, VACUUM TRUCK
vacuum tanker truck septik tank truck
1. All the internal structure of the parts are made of acid phosphate treatment, prior to welding spray paint, so you can extend the life of the tank. Full tank surface blasting, the elimination of internal stress generated when the cylinder coil, while enhancing the tank surface paint adhesion.
2. The use of domestic technology leader in vacuum suction sewage truck, suction, suction away, especially suitable for pumping sewage sludge within the, shipping and disposing, especially can absorb sewage mud, silt, gravel, bricks and other large objects.
3. to collect, clean up transit transport sludge, sewage, sanitation vehicles to avoid new secondary pollution, sewage suction truck can be self-priming from the row, work fast, large capacity, easy to transport, suitable for collecting and transporting manure, mud, oil and other liquid substances.
4. pumping manure tank full time: ≤5min, suction: ≥8m. It has a long life, work fast, simple, easy to transport and so on.
|The main technical parameters】|
|product name||Dongfeng DLK suction sewage truck wash||Product number||5070GQWEQ5|
|The total mass (Kg)||7360||Tank volume (m3)||3.59|
|Load weight (Kg)||2740||Dimensions (mm)||5990 × 2020 × 2600|
|Curb weight (Kg)||4490||Cab ride (person)||2|
|Approach / departure angle)||20/16||Front / rear overhang (mm)||1040/1642|
|Number of axes||2||Wheelbase (mm)||33082800|
|Axle load (Kg)||2945/4415||Maximum speed (Km / h)||99|
|other||Notes: 1. With the optional chassis optional front cover and front fog lamps, optional tank left and right side mounting position optional masks before the new styling ... Body side optional kit, on both sides of the tank optional header. 2. Media: a liquid suspension, the density of 800 kg / cubic meter. When the effective tank volume 3.59 m3 tank dimensions (length × diameter of straight section) mm // 3000 × 1250. Lateral protective device material Material: Q235, side protective welding bolting, welding protection after bolting the rear guard section size (width × height) 50 × 100 (mm), rear protective ground clearance: 410mm. ABS manufacturers and models: Lung Cheng Xiangyang Dongfeng Machinery Co., Ltd. / ABS / ASR-24V-4S / 4M.|
|[Chassis technology parameters|
|Chassis Type||EQ1070SJ3BDF||Chassis Name||Truck chassis|
|Brand name||Dongfeng||manufacturer||Dongfeng Automobile Co., Ltd.|
|Dimensions (mm)||5090 × 1980 × 2160||Number of tires||6|
|Approach / departure angle)||20/18||Tire specifications||7.00-16,7.00R16|
|Number of leaf spring||6/6 + 5||Front track (mm)||150314851519|
|Fuel type||Diesel fuel||Rear track (mm)||1494|
|Emission Standards||GB17691-2005 National Ⅴ, GB3847-2005|
|engine model||Engine manufacturers||Displacement (ml)||Power (Kw)|
|CY4BK551||Dongfeng Chaoyang Diesel Engine Co., North Korea||3707||75|
|YC4FA115-50||Guangxi Yuchai Machinery Co., Ltd.||2982||85|
|4B2-115C50||Full Diesel Engine Co., Ltd., Anhui||2545||85|
|ZD30D13-5N||Dongfeng Light Engine Co., Ltd.||2953||96|
|D28D11-5DA||Dongfeng Light Engine Co., Ltd.||2771||85|
|4DW93-84E5||FAW Wuxi Diesel Engine Factory Ltd.||2540||64|
|YN27CRE1||Yunnei Power Co., Ltd.||2672||70|
|YN33CRE1||Yunnei Power Co., Ltd.||3298||85|
