Cheapest 8000 Liters Water Tank Truck
| Quantity: | |
|---|---|
cheapest 8000 Liters water tank truck
cheapest 8000 Liters water tank truck
| Dongfeng 8000 liters Water tank Truck(Euro 2) | ||
| Chassis | EQ3093GD4JAC EQ3071GL93 | |
| Cubage (T) | 8 Ton | |
| Vehicle | Overall dimension mm length/width/height | 7595×2495×3100 |
| G V W(kg) | 9450 | |
| Payload (kg) | 4000*2 | |
| Kerb mass(kg) | 5255 | |
| Approach/Departure Angle(°) | 30/13 | |
| Front/Rear Suspension (mm) | 1340/1820 | |
| Fuel Type | Diesel | |
| Fuel consumption(L/100km) | 15 | |
| Top speed（Km/H） | 95 | |
| Engine | Model | YC4D130-30 YC4E135-21 YC4E140-33 |
| Exhaust/Power(kw) | 4214/96(130hp -135-140) | |
| Manufacturer | Guangxi Yuchai Engine Co., Ltd | |
| Type | 4-in-line | |
| Chassis | Drive type | 4×2 |
| Wheelbase (mm) | 3650,3950 | |
| Tread(front/rear)mm | 1835/1640 | |
| Front Bridge | 3 Ton | |
| Rear Bridge | 8Ton | |
| Transmission | Double spoke wheel, with power steering | |
| Gear box | Five forward gear mechanical transmission | |
| Clutch | Power clutch | |
| Brake system | Air brake | |
| Cab | One and half row non-longhead cab can turn over | |
| Number of spring axles(front/rear) | 8/12+10 | |
| Tire specification | 9.00-20 | |
| Air condition | Chose to fix | |
| Water system performance | Water pump | Self-sucking centrifugal pump |
| Water spray width (m) | ≥15 | |
| Water monitor range (m) | ≥28 | |
| Vertical suction range (m) | ≥7 | |
| Pressure ( KPa) | 250-450KPa | |
| Watering speed (l/m3) | 0.2-2(l/m3) | |
| Pump lift range (m) | 30m | |
| Priming time | <5min | |
| Flow | 60 m3/h | |
Our water tank truck with different chassis, eg:DFAC, DFL, SINOTRUCK, CNHTC,NORTH BENS, FOTON, ISUZU, JAC, JMC, KAMA, YUEJIN, etc.
Our water tank series:
-----water tanker truck
-----sanitation water tank truck
-----sprinkler truck
-----water wagon truck
-----insulation water tank truck
-----pesticide sprinkling truck
-----water spraying truck
-----Mild steel water tank cart
-----Stainless steel tank water truck
-----Aluminum alloy water tanker
-----RHD watering cart
-----Water tank semi trailer
-----Storage water tanker
TIC TRUCKS , www.truckinchina.com
