DRZ5310GYYN Beiben 3138 8x4 petroleum tanker truck for sale

Views: 14260     Author: Dong Runze Special Vehicle     Publish Time: 2017-04-25      Origin: Dong Runze Special Vehicle

 DRZ5310GYYN Beiben 3138 8x4 petroleum tanker truck for sale

Vehicle Model DRZ5310GYYN
Overall dimensions 11560X2495X3100mm Curb weight 11750kg
Tank dimensions 9000×2400×1600mm Tank volume 30000L

USD 49000.00 - 59000.00 / Set


3138 Beiben refueling vehicle,

Chassis parameters
Chassis model ND1310D46J7Z01 Chassis brand North-Benz
Overall dimensions 11700x2500x3550mm Wheel base 1950+4650+1350mm
Front/rear wheel track 1940/1940/1860/1860mm Front/rear suspension 1480/2270 mm
Approach/departure angle 16/19° Maximum speed 110km/h
Chassis Manufacturer BEIBEN TRUCK
Cab Configuration V3M a row and a half cab(with sleeping berth),allowable 3 passengers,air conditioner
Color White,other color is optional
Engine Model WP10.310E32
Emission Euro 3
Type 6 cylinders,in-line,water-cooled,4-stroke,turbo inter-cooling, direct injection,exhaust valve brake,diesel engine
Rated power 310hp,rated power speed 2200rpm
Displacement 9726ml
Max.torque 1250N.m
Bore x stroke 126x130mm
Manufacturer Weichai Power Co.,Ltd
Tire Size 11.00R20 steel wire tire
Number 12+1 nos
Clutch φ430 diaphragm clutch
Fuel tank 400L aluminum alloy
Front axle 5.5 tons
Rear axle 457 rear axle,13.0 tons
Drive form 8X4
Suspension Multi leaf springs
Rated voltage 24V,DC
Transmissions Gearbox 9JS135B ,9 speed forward 1 reverse
Steering device Power assisted steering
Steering wheel Left hand drive
Selective configuration
If there is a slight change in the chassis parameters above,please take the actual product as the standard
Beiben road tanker 3138Beiben crude oil transport vehicle 30000LBeiben 3138 heavy duty 8x4 oil truckFuel tank structure parameters

Tank dimensions 9000×2400×1600mm Tank volume 30000L
Tank material Carbon steel Tank thickness 5/6mm
Color and Logo Optional
Standard configuration Chassis, carbon steel fuel tank, sub frame,oil pump, two aluminum alloy flow valves, tool box, manhole,climbing ladder, fire extinguisher, oil hose.
Selective configuration Aluminum alloy fuel tank, flow meter, oiling machine, European standard manhole, pneumatic valve, AIP valve, anti overflow sensor plug, oil and gas recovery system

Diesel, kerosene, crude oil

 Oil  oil bowser     refers to the vehicle that loading and transporting of gasoline, diesel, kerosene, lubricating oil, crude oil,and other liquid fuel, etc. It is mainly composed of oil tank, oil pump, flow meter, refueling gun, filling mouth, fuel release valve, manhole covers, oil hose, chain etc. oil bowser  For Sale

According to the different transport medium, oil   oil bowser     can be called, oil tanker, oil bowser  For Sale   , tanker, oil bowser ,  Beiben oil delivery tanker, Beiben  flow oil truck, Beiben refueling vehicle, computer Beiben refueling truck, Beiben  diesel delivery vehicles,  Beiben gasoline delivery vehicles,  Beiben oil transport vehicle,  Beiben edible oil transport vehicle,  Beiben crude oil transport vehicle,  Beiben heavy oil truck,  Beiben oil truck.

According to the brand oil tanker truck can be divided into, Yuejin oil bowser  For Sale     , Dongfeng oil bowser  For Sale, FAW oil bowser  For Sale , Foton oil bowser  For Sale, Sinotruk  oil bowser   ,Auman oil bowser  For Sale , North-Benz  oil bowser  For Sale ,Beiben  oil bowser  For Sale ,  Shacman  oil bowser  , CAMC oil transport oil bowser  For Sale , Beiben oil bowser  For Sale , JMC oil bowser  For Sale , etc.
