Customization, Cost and Control Built How You Want it,
at a Price You Can Afford. for sale call:+86-152 -7135-7675We have well experienced in reseaching and developing different trailers: Container trailer, Low bed trailer, Side wall semi trailer, Stake semi trailer, Tank trailer, Dump trailer, Car carrier trailer,Van trailer, Extendable trailer, Modular trailer, Special trailer and Heavy duty trailer etc Road you success business!
Main Configuration | |||||
Weight (KG) | Tare Weight | 9000 | |||
Load Weight | 50000 | ||||
Total Weight | 59000 | ||||
Dimensions (LxWxH) | Overall Dimensions | 13800x3000x1550 mm | |||
Technical Parameter | |||||
Main Frame | |||||
Main Beam Material | Q345B steel | Main Beam Height | 500mm | ||
Upper Plate | 20mm | Lower Plate | 20mm | ||
Web Plate | 12mm | Platform | 3mm | ||
Side Beam Material | 16# channel steel | Side Beam Height | 200mm | ||
Running Gear | |||||
Axle | 3*13Ton Fuwa axle | Suspension | Leaf spring suspension | ||
Tyre | 12*1100R20 | Rim | 12*8.0-20 | ||
Landing Gear | 28Ton Lengthen type leg | King Pin | 2" or 3.5" bolt-in or welded king pin | ||
Brake System | |||||
Type | Pneumatic brake | Brake Chamber | Six double chambers | ||
Relay Valve | Wabco relay valve | ABS System | Optional | ||
Electrical System | |||||
Lamps | A full set of LED lights | Voltage | 24V | ||
Receptacle | 7 ways | ||||
Accessories | |||||
Tool Box | Equipped one set with basic tools | Spare Wheel Carrier | One or two | ||
Side Guard | 2 units of side guards | Ramp | A pair of mechanical ramp | ||
Suit Your Needs Excellence By Design! |
