T75 iso tank container for LNG. LN2, LO2, LAr, LN2O, LC2H4, LC2H6

Views:1465     Author:Dong Runze Special Vehicle     Publish Time: 2017-12-07      Origin:Dong Runze Special Vehicle

T75 iso tank container for LNG. LN2, LO2, LAr, LN2O, LC2H4, LC2H6

LNG. LN2, LO2, LAr, LN2O, LC2H4, LC2H6 T75 iso tank container

 CONTAINER VOLUME of 19.5 M3 TANK USED to TRANSPORT LIQUEFIED GAS PRODUCTION by CHINA'S NEW 100% @

 CONTAINER BỒN DUNG TÍCH 19.5M3 DÙNG ĐỂ CHỞ KHÍ HÓA LỎNG DO TRUNG QUỐC SẢN XUẤT MỚI 100% @

CÔNG TY CỔ PHẦN ĐẦU TƯ QUỐC TẾ VÀ XUẤT NHẬP KHẨU DHT

Amount (USD) 43350.0
Unit Price (currency) 43350.0 currency  USD
Quantity 1 PCS
Import duty (%) N/A

T75_ISO_Tank_Container Ar_1.jpgT75_ISO_Tank_Container(Ar)1_1.jpg

ASME Standard LOX/LIN/LAR/LCO2 / LNG/LC2H4 T75 Storage Tank Container

Cryogenic Gas ISO Tank Container (T75)

T75 ISO Tank Container for O2, N2, Ar, LNG






Specification: 20ft

Design Standard: ASME

Classification Society: LR

Effective Capacity: 19.8 m³

Working Pressure: 1.6 MPa

Material of Construction: Inner Shell – SA 240 304; Outer Jacket –SA 516M Gr 485

Medium: LNG. LN2, LO2, LAr, LN2O, LC2H4, LC2H6





T75 ISO Tank Container for CO2






Technical Details:

Specification: 20ft

Design Standard: GB 150

Classification Society: CCS/LR

Effective Capacity: 20.8 m³

Working Pressure: 2.4 MPa

Material of Construction: Inner Shell – 15MnDR; Outer Jacket –Q345R

Medium: CO2



ISO T75 tank container high vacuum multi-layer LOX LNI LAR LCO2 LNG C2H4

Size: 20 feet & 40 feet
Loading Medium: LOX/LNI/LAR/LNG/C2H4/LCO2
Design Code:CCS, ASME U&U2, ASME DOT, EN13530, ISO1611, ISO1496, IMDG, RID, ADR, TIR, UIC,CSC, FRA
Max. Working Pressure: 0.78bar~2.4bar, customerization
Insulation Method: High vacuum multi-layer

ISO IMO7/ T75 Tank Container


(1) Capacity: 19.8m3/20.8M3


(2) WP: 0.8/1.6/1.7/1.8/2.4MPA;


(3) Standard: GB150/ASME


(4) Certificate; CCS/LR/DNV



Introduction:



A tank container is built to the ISO Standard, making it suitable for different modes of transportation. Both hazardous and non-hazardous products can be transported in tank containers.



Technical Details:



(1) Model: ISO-T75 20M3-1.6MPA



(2) Standard: ASME



(3) Capacity: 20m3;



(4) WP: 1.6MPA;



(5) Design Pressure: 2.11MPA;



(6) Medium: Liquid Oxygen; Liquid Argon; Liquid Nitrogen; Liquid Natural Gas;



(7) Insulation: Multi-Layer super vacuum insulation;



(8) Dimension: 6058mm X 2438mm X 2591mm



(9) Max Loading Weight: 34000KGS;



(10) Testing: RT / Ultra / Impact / Penetration / Cleaning / Heat Treatment / Pressure / Mechanical / Helium / Painting



(11) Certificate: LR



(12) Delivery Time: 60DAYS.
