MINI Changan o.5 ton fire truck
| FOB: | |
|---|---|
| Quantity: | |
|
| |
-
SC1022
-
DRZ
-
8705309000
changan Cheaper mini fire tender truck 600L-1000L
fire fighting truck water pump
Max. Total mass(kg)1705
Tank capacity(M3)1 CBM
Rated Loading mass(kg)500
External dimensions (L×W×H)(mm)4120×1560×1970(mm)
Kerb mass(kg)1205
Cab seats2
Tire 165/70R13LT (4 pcs)
Approach/departure angle 19/12
F/R overhang 575/1045
Number of axles 2
Wheelbase(mm)2500
Axle loading(kg)2845/3650
Max speed(km/h)80
chassis technical parameter
Chassis model SC1022
Chassis name brand Changan
Fuel of type Diesel
Emission standards Euro 4
Engine model manufacture Displacement(ml)
JL465Q5 Changan Auto technology Co.,ltd 1012ml/39kw
ChangAn mini fire truck
(3)Emergency Rescue Mini Foton Forland Fire Service Truck
Fire Fast (Quick) Attack Fire Truck
GeneralVehicle Brand DRZ
Chassis Brand Foton ,Forland
Overall Dimension 5200x1860x2090 mm
GVW / Kerb Weight 4495 kg / 2375 kg
Cab Cab Capacity 3 persons allowed
Air Conditioner Air conditioner is optional
Engine Fuel Type Diesel
Engine Brand Quanchai engine
Power 68 Ps (50 KW) Displacement 1809 ml
Emission Standard Euro II
Chassis Drive Type 4X2, left hand drive
Transmission 5-speed front, 1 reverse
Wheelbase/No. of axle 2300 mm / 2
Tyre Specification 6.50-16
Tyre Number 6 tyres and 1 spare tyre
Max Speed 90 km/h
Paint Metallic paint
Superstructure Water Capacity
1,000 Litres (About 260 gallons)
Tank Material Carbon steel
Fire Pump Flow speed
20L/s Pressure 1.0MPa
Fire Cannon Flow speed
20 L/s Shot 48 m
Suction Head 6 m Hose High quality, wire strengthened hose, with cooper wire, anti-static
All standard accessories: Typical modern fire apparatus carries equipment for a wide range of firefighting and rescue tasks. These include shovel, pike poles, axes and cutting equipment, halligan bars.…
Optional Ladders, floodlights...
(4)Emergency Rescue Mini SFC Fire Service Truck
MINI TRUCK Model SSF1040HDJ32 ;FS1 Model SSF1040HDJ41; FS2 Model No. SSF1040HDJ54-3 Cabin New FS2 Single Row ;Vehicle wheelbase(Mm) tonnage dimensions
SSF5040ZXX /2300/ 1.88 /3980×1580×1900
SSF5040XLC /2550 /1.5 /4810×1680×2380
SSF5040GSS/ 2700, 2800 /1.49 /5280×1855×2100
SSF5080GSS 3200 4.2/ 5990×2100×2450
3200/2820/ 5300*2200*2500
SSF5090TQZ /3800/ 4.2 /7440×2300×2500
Mini SFC Fire Service Truck SSF5040GSS
Water Tank 1000 Liters Flow Speed:20 L/S
Mini SFC Fire Service Truck SSF5040XLC
Water Tank 600 Liters Flow Speed:20 L/S
Emergency Rescue Mini Foton Forland Fire Service Truck
Emergency Rescue Mini Foton Forland Fire Service Truck
Water Tank 1000 Liters Flow Speed:20 L/S
changan Cheaper mini fire tender truck 1000l gasoline portable fire water pump
Dongfeng mini gasoline portable pump fire truck
optinal fire pump CB10/20 by PTO
About Company
Customizing Whollesale manufacturers of famous brand truck, welcome to wholesale tankers, semi trailer, truck parts of good capacity at competitive price from our factory.
With more than 10 years' producing experience, we have shipped our vehicles to many countries worldwide ----Nigeria, Congo,Ghana, Zambia,Tanzania, Sudan,Uzbekistan, Sri Lanka, Korea, Myanmar, Vietnam, Chile, Argentina,Peru etc.
1. OEM Manufacturing SHACMAN Truck Customizing | Beiben truck Customizing | ISUZU UD HINO Truck Customizing | Recovery Wrecker | Portable Tank Container | Special Car | Tanker and Trailer truck | Aerial platform truck | All Wheel Drive off road truck | Body parts | Chassis parts | Tank body | Bus &truck | Concrete mixer trucks | Crane truck | Garbage Truck | Hooklift | Road Sweeper Truck | Skip Loader | Vacuum truck Combined Jetting | Water Sprinkler truck | Fire Trucks | Road tanker | Milk Tank Truck | Sprayer tank Truck | Chemical Liquid Tank Truck | LPG Tanker Truck | LED Advertising truck | Mobile fast food cooking truck | Mobile generator truck | Mobile workshop maintenance lorry | storage tank | Chemical acid tank trailer | Lowboy trailer | LPG Bobtail ,LNG tanker...
2. Sample order
3. We will reply you for your inquiry in 24 hours.
4. after sending, we will track the products for you once every two days, until you get the products. When you got the
goods, test them, and give me a feedback.If you have any questions about the problem, contact with us, we will offer
the solve way for you.
5.Support Spare Part
Q1. What is your terms of packing?
A: (1)Truck Body and samll trucks By containers
(3)Truck spare Parts Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment?
A: (1)T/T 70% as deposit, and 30% before delivery;(2)T/T 50% as deposit, and 50% before delivery
(2) T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages
before you pay the balance.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A: Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.
