IVECO Technology
4x2 vacuum sewage Truck
4x2 vacuum sewage Truck
Vacuum tanker truck ,vacuum sewage suction truck / Septic Tank Truck / Cesspit Emptier
Hongyan Genlyon 4x2 VACUUNM sewage trucks Truck Specification
| Model | 5165 | |
| Driving Type | 4×2 | |
| GVW (kg) | 16000 | |
| Kerb Mass (kg) | 8750 | |
| Max. Payload (kg) | 7120 | |
| Wheelbase (mm) | 4600 | |
| Outside Dimension(mm) | L | 8005 |
| W | 2500 | |
| H | 3101 | |
| Tank Outside Dimension (mm) | L | 5000 |
| W | 1850 | |
| H | 1100 | |
| VACUUM Tanker (L/Volume) | 7000-12000 | |
| Max. Speed km/h | 80 | |
| Engine | Cursor 9-290HP | |
| Clutch | Single Plate,Φ430 Large Diaphragm-spring Type | |
| Gearbox | 9JS119 | |
| Cab | Long Cab with Low Roof | |
| Leaf Spring NO. | 8/10+6 | |
| Steering | ZF 8098 Rotary Valve Steering | |
| Rear Axle /Ratio | Hub Reduction Rear Axle Whelding Housing/4.8,5.73 | |
| Frame | 865×280×(8+5) | |
| Oil Tank | 280L | |
| Tire | 11.00R20 | |
| Emission STD | China Ⅲ EUROⅢ | |
| Others | Fitted with General Equipment VACUUNM PUMP | |
| VACUUM Tank body | |
| Design volume | 8000 L ~12000 L |
| Main body material | Q235A/6MM ( option steel inner lined PE anticorrosive. will Add $4000) |
| Vacuum pumps model | 50QZXDG-45/400 manufacture: Hangzhou weilong pump Co., LTD |
| vacuuming both sewage and sludge | |
| Maximum AOB | ≥45° |
| Effective suction | ≥ 5 |
| Vacuum system（MPa） | ≥11 |
| Lifting time（s） | ≤45 |
| Cover opening Angle（°） | ≥75° |
| Cover open time （s） | ≤25 |
| Suction pipe diameter (mm) | 100 |
| length of the Hose (mm) | 6000 |
| Tanks full sucked time (min) | ≤12 |
TIC TRUCKS , www.truckinchina.com
