ISUZU GIGA Foam Powder Fire Truck 2 Units Sale

Views:20257     Author:JIN CONG     Publish Time: 2018-08-24      Origin: ISUZU GIGA foam powder fire truck

ISUZU GIGA Foam Powder Fire Truck 2 Units Sale

ISUZU GIGA Foam Powder Fire Truck 2 Units Sale ISUZU GIGA foam powder fire -44-truck

ISUZU GIGA foam powder fire -35-truckISUZU GIGA foam powder fire -34-truckISUZU GIGA foam powder fire -39-truckISUZU GIGA foam powder fire -45-truckISUZU GIGA foam powder fire -33-truckISUZU GIGA foam powder fire -37-truck

ISUZU GIGA  foam powder fire truck

Isuzu QL5400GXFW2VCHY

Engine:6WG1-TCG51Wheelbase (mm):1850+4575+1370
Displacement (cc):15681Dimensions (mm):11285 × 2540 × 3055/2985
Power (kW):338Gross weight (kg):40000
Fuel type:diesel fuelTrailer weight (kg):17/10


Technical Data

MODELMODELQL5310XLCU2VDHJ
DRIVING TYPE8X4
POWER(PS)380
WEIGHTGVW31000
KURB WEIGHT12450
PAYLOAD18550
DIMENSIONOVERALL DIMENSION12000X2540X3055
CARRIER DIMENSION9550X2420X2350
MATERIALCARRIER MATERIALTHRTMAL INSULATION MATERIAL
ENGINEENGINE TYPE6UZ1-TCG50
DISPLACEMENT9.839
POWER(KW)279
MAX TORQUE(N.m)1765
EMISSION STDEURO VI
OTHERSGEARBOXZF8S2030TO
REAR AXLERT210
OIL BOX(L)400
TYRE315/80R22.5




#1Isuzu QL5400GXFW2VCHY fire truck chassis

Isuzu QL5400GXFW2VCHY Isuzu logo (batch #291)

Isuzu fire truck chassis manufactured in China

(Engine: 6WG1-TCG51 Wheelbase (mm): 1850+4575+1370

Displacement (cc): 15681 Dimensions (mm): 11285 × 2540 × 3055/2985

Power (kW): 338 Gross weight (kg): 40000

Fuel type: diesel fuel Trailer weight (kg): 17/10

Isuzu

#2Isuzu QL5190GXFWMFRY fire truck chassis

Isuzu QL5190GXFWMFRY Isuzu logo (batch #289)

Isuzu fire truck chassis manufactured in China

(Engine: 6HK1-TCH Wheelbase (mm): 4500

Displacement (cc): 7790 Dimensions (mm): 8160 × 2490 × 2810

Power (kW): 221 Gross weight (kg): 19000

Fuel type: diesel fuel Curb weight (kg): 5750

Isuzu





#3Isuzu QL5190GXFUKCRY fire truck chassis

Isuzu QL5190GXFUKCRY Isuzu logo (batch #272)

Isuzu fire truck chassis manufactured in China

(Engine: 6UZ1-TCG40 Wheelbase (mm): 3900

Displacement (cc): 9839 Dimensions (mm): 6770 × 2490 × 3025

Power (kW): 257 Gross weight (kg): 19000

Fuel type: diesel fuel Curb weight (kg): 6600

Isuzu

#4Isuzu QL5330GXFURCZY fire truck chassis

Isuzu QL5330GXFURCZY Isuzu logo (batch #272)

Isuzu fire truck chassis manufactured in China

(Engine: 6UZ1-TCG40 Wheelbase (mm): 5100+1300

Displacement (cc): 9839 Dimensions (mm): 10170 × 2490 × 3025

Power (kW): 257 Gross weight (kg): 33000

Fuel type: diesel fuel Curb weight (kg): 8600

Isuzu





#5Isuzu QL5330GXFUTCZY fire truck chassis

Isuzu QL5330GXFUTCZY Isuzu logo (batch #272)

Isuzu fire truck chassis manufactured in China

(Engine: 6UZ1-TCG40 Wheelbase (mm): 5820+1300

Displacement (cc): 9839 Dimensions (mm): 11745 × 2490 × 3025

Power (kW): 257 Gross weight (kg): 33000

Fuel type: diesel fuel Curb weight (kg): 8900

Isuzu

#6Isuzu QL5330GXFUPCZY fire truck chassis

Isuzu QL5330GXFUPCZY Isuzu logo (batch #254)

Isuzu fire truck chassis manufactured in China

(Engine: 6UZ1-TCG40 Dimensions (mm): 9375 × 2490 × 3025

Displacement (cc): 9839 Gross weight (kg): 33000

Power (kW): 257 Curb weight (kg): 8200

Wheelbase (mm): 4605+1300 Axle loads (kg): 7000/26000

Isuzu

#7Isuzu QL5190GXFUACRY fire truck chassis

Isuzu QL5190GXFUACRY Isuzu logo (batch #254)

Isuzu fire truck chassis manufactured in China

(Engine: 6UZ1-TCG40 Dimensions (mm): 8345 × 2490 × 3025

Displacement (cc): 9839 Gross weight (kg): 19000

Power (kW): 257 Curb weight (kg): 6450

Wheelbase (mm): 4650 Axle loads (kg): 7000/12000

Isuzu

#8Isuzu QL5400GXFUVCHY fire truck chassis

Isuzu QL5400GXFUVCHY Isuzu logo (batch #254)

Isuzu fire truck chassis manufactured in China

(Engine: 6UZ1-TCG40 Dimensions (mm): 11745 × 2490 × 3025

Displacement (cc): 9839 Gross weight (kg): 40000

Power (kW): 257 Curb weight (kg): 9100

Wheelbase (mm): 1850+4615+1300 Axle loads (kg): 7000/7000/26000

Isuzu
