ISUZU FVR  water tanker fire truck water 6000 liters EURO 5

ISUZU FVR  water tanker fire truck water 6000 liters
Water Tank : 5000 Liters
Foam Tank  : 1500 Liters
Flow Speed  : 60 Liters/Sec stainless steel tank
Price: $ 86500
Discount Price: $ 81000
FOB:
Availability:
Quantity:

  • DRZ5160TSFQ

  • DRZ

  • 8705309000

Fire fighting

ISUZU   4x2 water tanker fire truck

6HK1-TCNG40 240hp  chassis QL1160

water 6000 liters stainless steel tank Aluminum checkered

ISUZU fire fighting truck-06cbm-water-foam-fire-truckISUZU fire fighting truck-08cbm-water-foam-fire-truckISUZU fire fighting truck-10cbm-water-foam-fire-truckISUZU fire fighting truck-11cbm-water-foam-fire-truckISUZU fire fighting truck-07cbm-water-foam-fire-truck_1

 Fire Pump Truck 6000L , Hubei Dong Runze Special Vehicle Equipment Co., Ltd





Fire fighting water tank lorry truck


FVR  EUR 4

 G.W 15~16T  4*2

Rate loading

9~10T

QL1150AKFR

QL1150AMFR

QL1150AQFR QL1160AKFRY  QL1160AMFRY  QL1160AAFRY  QL1160ANFRY

QL1160AQFRY

QL5160XXYAQFR  QL5160XXYARFR

6HK1-TCNG40 - 240HP  6strock



FVR chassis  with 240-horsepower Isuzu engine 6HK1-TCNG40, six-speed transmission configuration Isuzu MLD / air conditioning / 6.3 tons front axle, rear axle 13 t /Optional  1000-20 ,1000R20 , 1100-20,1100R20   / standard direction of power / central locking / electric windows / steam brake / USB audio / cab flip / frame cross-section: 258 * 85 * 10 + 4mm

Wheelbase

3900

4500

4700

5000

5550

5800

FVR  EUR 4

19T  G.W 4x2 Rate loading

9~10T

QL5190GXFDMFRY

6HK1-TCSG40  300HP



300-horsepower Isuzu engine 6HK1-TCSG40, configure Fast nine files 9JS119TA transmission, 1100R20 tire, the remaining configuration with the above FVR

4500

 Tank Capacity:

6000L


 Fire Pump:

CB10/40


 Fire Monitor:

PS40


 Overall Dimension:

8255×2380×3340 (8105 x 2480 x 3365) mm




Accessories  :

TOOL


Prodution Time :

45~65DAYS


Packing :


NIL



1.0  Truck Chassis:


Name

ISUZU FVR 240HP  QL1160AQFRY


Drive Type

4X2   6-WHEELER


Wheel Base

4500、 5000 / 5500mm


Cabin Structre

Double cabin, full steel material structrue, flat cab tilting by hydraulic


Inside Cabin equipment

hydraulic, adjustable driver's seat and co-driver's seat,


Number of Seats

2+3


Air Condition

A/C


Enging

Model

6HK1-TCNG40


Power

  177KW/240HP


Front Axle

6.3T


Rear Axle

13T


Tyres

1000-20


2.1 SystemTanker :

Name


Water Tank Volume (Liters)

6000L

Tank Material

CARBON STEEL OR  stainless steel

Manhole

CARBON STEEL OR   stainless steel tank





2.2  Pump System

(Kg)Load capacity

water


6000



pump

type

CB10/40




(L/S)flow

Low pressure 40




(Mpa) pressure

1.0



fire monitor

type


PS40




(L/S)flow


40




(Mpa) pressure

1.0

1.0




(m)range

≥55

≥60



 No.

Name

Specification

Q’t

Remark

1

吸水管suction pipe

Ø125×2000mm

4PCS


2

消防水带fire fighting belt

Ø65×2000mm

6


3

消防水带fire fighting belt

Ø80×2000mm

4


4

滤水器water purifier

FJF125

1PC


5

二分水器wyes

FF65

1PC


6

异径接口increasers

KJ65/80

2PCS


7

水带挂钩belt pothook

FG600

4PCS


8

水带包布belt cloth

FP470

4PCS


9

地上消火栓扳手above ground hydrant wrench

FB450

1PC


10

地下消火栓扳手underground hydrant wrench

FBX800

1PC


11

吸水管扳手suction wrench

FS100/125

2PCS


12

直流开关水枪straight stream shut-off nozzle

QZG19

1PC


13

直流水枪straight stream nozzle

QZ19

1PC


14

直流开花水枪

straight stream multi-jet squirt

QZH19

1PC


15

空气泡沫枪 air foam nozzle

PQ8

1SET


16

空气泡沫枪air foam nozzle

PQ4

1SET



消防斧 fire fighting axe




17

消防腰斧fire fighting axe

GF285

1PC


18

铁铤tool

GT1

1PC


19

急救箱emergency box


1set


20

灭火器fire extinguisher


1set



Packaging & Shipping_1.jpg
