Hydraulic Gooseneck Low Bed Semi-Trailer 5axles and 6 axles for 100Ton-150ton HEAVY & OVERSIZE LOAD

Views: 1610     Author: Dong Runze Special Vehicle      Publish Time: 2017-07-10      Origin: Dong Runze Special Vehicle

Hydraulic Gooseneck Low Bed Semi-Trailer 5axles and 6 axles for 100Ton-150ton HEAVY & OVERSIZE LOAD

Hydraulic Gooseneck Low Bed Semi-Trailer 5axles and 6 axles for 100Ton-150ton HEAVY & OVERSIZE LOAD

US $65,000-78,000 / Set  Hydraulic Gooseneck-074Ton-Hyraulic Detachable Lowboy.jpgHydraulic Gooseneck-165Ton-Hyraulic Detachable Lowboy.jpgHydraulic Gooseneck-215Ton-Hyraulic Detachable Lowboy.jpgHydraulic Gooseneck-204Ton-Hyraulic Detachable Lowboy.jpg

 Detaching Removable Gooseneck Lowboy Trailer

Rated Load

100T-150T

Tare Weight

13-15T

Wheel Base

+1360+1360+1360 (mm)

Tyre Specifications

10.00R20 / 12R22.5/315/80R22.5 /295/80R22.5


No. Of the Tyres

24/32

Axle Brand

18 /20 Tonnage X L1 / FUWA Brand

No. Of the Axles

Axles trailer+1Axle dolly /4 Axles trailer+2 Axles dolly

Pieces of leaf-spring

10 / airbag

Suspension

Heavy Duty Leaf Spring or airbag suspension

Front/Rear Overhang

1950 mm

Outside Dimensions

17500x3000x1500 (mm)

19040x3100 (40000)x1660 mm

    22980x3100 (40000)x1660 mm(LxWxH)

Material of the Main Beam

Q345B/ST52-3 manganese plates, automatic submerged arc,

Main-beam Height 500mm,

Lower flange: 20mm

Upper flange: 20mm

Mid Web: 12mm

Usage

For heavy duty machine, as transformer, crane, excavator transportation.

Brake System

Dual Lines Braking System With Automatic Air Chambers

Brake Air Chamber

Four double and two single chamber

Electrical System

24V, 7core socket, lights according to European standards.

Floor

4mm management plate

Tool Box

1 box of standard tools

Spare tire carrier

2 sets

Color and Logo

Depends on the buyer’s requirement.

The traction pin

2’ & 3.5 inter-changeable

Pin Height

According to the height of the tractor saddle.

Hydraulic Gooseneck-118Ton-Hyraulic Detachable Lowboy.jpgHydraulic Gooseneck-216Ton-Hyraulic Detachable Lowboy.jpgHydraulic Gooseneck Low Bed ,Hydraulic-neck low-bed trailer,Hydraulic Detachable Gooseneck, Detachable Gooseneck  Lowboy,Removable Gooseneck Lowboy Trailer,Hyraulic Detachable Neck Low Bed ,Detaching lowbed neck,
