Views: 2432 Author: Dong Runze Publish Time: 2017-04-24 Origin: Dong Runze Special Vehicle
Foton Fuel Transport Vehicle , Forland Oil Transport Truck , Foton Oil Carrier Truck , FAW Fuel Transport Vehicle , FOTON Fuel Transport Vehicle , Shacman Fuel Transport Vehicle , 5tons Flatded Transport Vehicle , Foton Chemical Transportation Vehicle
Unit Price: USD 14700.00 - 15700.00 / Set
Vehicle Model DRZ5102GYYB
Overall dimensions 7000X2250X2600mm Curb weight 5090kg
Tank dimensions 4600×2000×1350mm Tank volume 8000L
Chassis parameters
Chassis model BJ1102VDPEA-G1 Chassis brand FOTON
Overall dimensions 6970x2240x2450mm Wheel base 3900mm
Front/rear wheel track 1750/1654mm Front/rear suspension 1175/1895mm
Approach/departure angle 29/22° Maximum speed 80km/h
Chassis Manufacturer BEIQI FOTON MOTOR CO.,LTD
Cab Configuration G1863B single cab,allowable 3 passengers,with warm air,all English signs in car body, English instruction , international general accessories,double front windshield,power switch
Color White,other color is optional
Engine Model 4102QBZL
Emission Euro 2
Type 4 cylinders,in-line,vertical type,turbo-charging,air-to-air inter-cooling, liquid-cooled diesel engine
Rated power 130hp,rated power speed 3000rpm
Displacement 3760ml
Max.torque 290N.m
Bore x stroke 102x115mm
Manufacturer Kunming Yunnei Power Co., Ltd
Tire Size 8.25-16 Double Star nylon tire
Number 6+1 nos
Brake Air break
Fuel tank 120L iron
Front axle 1061 front axle
Rear axle 1092 rear axle
Drive form 4X2
Rated voltage Camel brand,24V,DC
Transmissions 5 speed forward 1 reverse
Steering device Power assisted steering
Steering wheel Left hand drive
Selective configuration Steel wire tire,air conditioner
If there is a slight change in the chassis parameters above,please take the actual product as the standard
Fuel tank structure
Tank dimensions 4600×2000×1350mm Tank volume 8000L
Tank material Carbon steel Tank thickness 5mm
Color and Logo Optional
Standard configuration Chassis, carbon steel fuel tank, sub frame,oil pump, two aluminum alloy flow valves, tool box, manhole,climbing ladder, fire extinguisher, oil hose.
Selective configuration Aluminum alloy fuel tank, flow meter, oiling machine, European standard manhole, pneumatic valve, AIP valve, anti overflow sensor plug, oil and gas recovery system
Oil Petrol Tank truck refers to the vehicle that loading and transporting of gasoline, diesel, kerosene, lubricating oil, and other liquid fuel, etc. It is mainly composed of oil tank, oil pump, flow meter, refueling gun, filling mouth, fuel release valve, manhole covers, oil hose, chain etc.
According to the different transport medium, oil Petrol Tank truck can be called, oil tanker, tank truck, tanker, fuel trucks, Forland oil delivery tanker, Forland flow oil truck, Forland refueling vehicle, computer Forland refueling truck, Forland diesel delivery vehicles, Forland gasoline delivery vehicles, Forland oil transport vehicle, Forland edible oil transport vehicle, Forland crude oil transport vehicle, Forland heavy oil truck, Forland oil truck.
According to the brand oil tanker truck can be divided into, Yuejin tank truck, Dongfeng Petrol Tank truck , FAW tanker truck, Foton tank truck, Sinotruk Petrol Tank truck ,Auman tanker truck, North-Benz Petrol Tank truck ,JAC tanker truck, Shacman Petrol Tank truck, CAMC oil transport tanker truck, Isuzu tanker truck, JMC tanker truck, etc.
