Dongfeng 8x4 Heated Asphalt Tank Truck Top Discharge with Air Pump

Dongfeng 8x4 Heated Asphalt Tank Truck Top Discharge with Air Pump
Quantity:

Dongfeng 8x4 Heated Asphalt Tank Truck
27000L - 32000L 380 HP - 420 HP
top discharge with air pump

Dongfeng 8x4 Heated Asphalt Tank Truck top discharge with air pump

 Customization, Cost and Control Built How You Want it, at a Price You Can Afford. for sale

 call:+86-152 -7135-7675



 As a leading HEATED BITUMEN TANK manufacturer, HEATED BITUMEN TANK, HEATED ASPHALT TANK supplier,  exporter in china, our asphalt tanker truck / trailer/ tank containers are widely Applied to transport liquid asphalt in a short or long distance. It's an ideal equipment to transport asphalt from asphalt storage depot to asphalt plant, and transport asphalt from oil refinery and wharf to asphalt storage depot. Besides the above functions, also suitable to transport crude oil and residual oil and viscous oil Please see the standard model as below, any special requirements

 SHACMAN F3000 FUEL TANKER TRUCK  also can made as  Asphal & bitument tanker





 rigid chassis    Dongfeng 8x4   Heated Asphalt Tank Truck




           Tank material









         Q235A carbon steel from WISCO




         End plate material









         Q235A carbon steel from WISCO




         Rated work Pressure









         0.2Mpa




         Manhole Cover




         Set




         500mm manhole cover, 2 set




         Outlet discharge Pipe









         2 unit,6m




         Inlet hole









         2 unit 500mm inlet hole




         Discharge hole









         2 unit discharge hole




         Accessories




         Set




         A. One set of spare tire including a carrier, one tool box



         B. Ladder: In left and rear position, width>250



         C. Walkway: Width>1500mm



         D.Two fire hydrant




         Paint




          As required;












         Heating and insulation system












         Insulating layer



         1. Tank containing keep warm by insulation layer



         2. Insulation layer composed of: 50mm rock wool and carbon steel cold plate covered,  it can prevent the heat losing.



         Heating system



         1.Use Burner heater 24 hours continuous heating at back of the tanker



         2.One  Italian BALTUR diesel oil burner



         Capacity: 14*104Kcal/h, brand-new



         3. One general-purpose diesel generator



         4.According to continuous diesel burning to keep warm



         (Diesel consumption:150kg/24hours)



         Note: It’s not necessary to adopt 24 hours continuous burning, you just only need begin to heat ahead of 4-5 hours while approach the destination site.



         It will save oil consumption and cost for you





 Tanker

 Material                  Steel  , Aluminium alloy

 Thickness of shell     4mm

 Thickness of dish      5mm

 Inside baffles            3mm

 Compartments          3 to 4 compartments

 Volume                    25000L to 35000L+ 5% expansion



 Tank Top Accessories

 Ladders fixed on the front and rear; foldable handrail

 Walkway with anti-slip material in the front of reach the manholes,

 Not covering the complete length of the tank.

 Electric Installation

 Complete 24V system in explosion proof installation

 Rear lighting with rear, stop, parking, direction, fog, reverse lights, side lights



 Painting

 Exterior surface treatment by shot blasting.

 Painting by high solid primer directly on the surface

 Painting inside special paint booth with the cargo cabin color or the color chosen by the customer



 Accessories

 Side protection, 2 Fire extinguisher, 1 Spare tire carrier.

 1 Tool box with standard tools, Heavy duty tail bumper


       water tank        Carbon steel/stainless steel tank /water pump/ High pressure squirt gun
       steel option

         Carbon steel Q235/Q345/ 16 manganese steel/



         stainless SS201/SS304 /SS316 tanker


       acids tanker        steel lined plastic for water/alcohol/ethanol acid, alkaline and salt  liquid lubricating oil
       oil/petrol,Fuel diesel/Tank truck        steel tank with oil pump/ gun fuel truck nozzle
       asphalt/bitumen/crude oil tanker        burner/steam heating and insulation system ,pump option

 -----Fuel tank truck

 -----Refuel tanker

 -----Edible oil tank truck

 -----Insulation oil tanker truck

 -----Crude oil transport tank truck

 -----Fuel tank full trailer

 -----Fuel tank semi trailer

 -----Mild steel oil tanker

 -----Stainless steel oil tank

 -----Aluminum fuel tank

 -----Fuel tank container

 -----Mobile refueling station

 -----Horizontal storage fuel tanker

 -----RHD fuel tank truck

 And more customized products.

 All more details of fuel tank truck, please kindly contact with us.




         steel option        Q235/Q345/ 16 manganese steel/SS201/SS304 /SS316   alummin alloy tanker
       acids tanker

         steel lined plastic for water/alcohol/ethanol acid, alkaline and salt HCL, NaOH ,NaCIO Sodium Hypochlorite NaCIO /hydrofluoric acid HF/CAUSTIC SODA  alummin nitric acid


       oil/petrol,Fuel diesel/LPG/LNG        steel tank with oil pump/ gun fuel truck nozzle
       asphalt/bitumen/crude oil tanker/  AN  ammonium  methana Alcohol        burner / steam heating and insulation system ,pump option
