Dongfeng 6X4 Water Truck for Sale 20 Tons Sprinkler Truck
Views: 1302 Author: Dong Runze Special Vehicle Publish Time: 2017-11-07 Origin: Dong Runze Special Vehicle
Dongfeng 6X4 Water Truck for Sale 20 Tons Sprinkler Truck
MAIN FEATURES
1. Tank capacity vary from 3000L to 30000L with different brand of chassis.
2. Material option: carbon steel or stainless steel.
3. Tank color: optional
4. Functional features: front flushing(water column, fan-shaped)
side spraying
back sprinkling(sprinkler, duckbill)
work platform in the rear with water cannons(a range of about 30 meters).
The above functions may be controlled by manual or pneumatic mode.
5. Equipped with self-sucking water pumps hydraulically driven by the PTO of the engine.
PRODUCT SPECIFICATION
Chassis | Model | DRZ5250GSS |
Drive mode | 6X4 | |
Engine model | EQ1250GD4DJ2 | |
Fuel type | Diesel | |
Emission standard | Euro 3 (optional) | |
Tank | Capacity(L) | 15000L |
Material | Q235B | |
Dimension | Overall dimension(L*W*H)(mm) | 10000*2480*3200 |
Tank size(mm) | 6700*2200*1500 | |
Wheelbase(mm) | 5400+1300 | |
Tread(front/rear)(mm) | 1032/1618 | |
Approach/Departure angle | 19°/14° | |
Weight | Load capacity (kg) | 14205 |
Curb weight(kg) | 10600 | |
Total weight(kg) | 25000 | |
Special device | Water pump | Self suction centrifugal pump |
Flow(L/min) | 833 | |
Sprinkling width | ≥14 | |
Sprinkling pressure(kpa) | 250 | |
Sprinkling time(min) | 15-25 |
2
LHD or Rhd Dongfeng 6X4 20000liters 20ton Water Tank Truck for Sale
Item | unit | parameter | ||
Vehicle model | 20000Liter RHD Dongfeng 6*4 Water Tank Truck | |||
Chassis model | EQ1258KB3GJ | |||
Driving model | Right hand drive | |||
Overall dimensions | mm | 9950*2490*3350 | ||
Curb Weight | kg | 9005 | ||
GVW | 25000 | |||
Payload | 15800 | |||
Wheel base | mm | 4350+1300 | ||
Exhaust/hp | ml/ps | 5900/210 | ||
Max speed | km/h | 85 | ||
Tire specification | 10R22.5 | Engine type | B210 33 | |
Traction system | 6*4 | Transmission | 6-speed with over drive | |
Number of axles | 3 | Axle Load(kg) | 7000/18000/18000 | |
Engine | diesel,6-cylinder in-line with water cooling | |||
Tank | Material | Q235 | ||
Paint | Anti-corrasive | |||
Volume | 20000L | |||
Equipment | Cabin | A/C installed,Flat head, metal-enclosed cab, two door, panoramic curved windshield | ||
Front(rear,side) sprinkler | Sprinkling width>14m | |||
Rear working platform with water cannon | Range>28m | |||
Chinese brand Weilong pump | Suction lift >6m | |||
Water valve | 1 | |||
Fire valve | 1 | |||
Pipeline | 3m*2 | |||
sprinkler | 2 | |||
