China Used Crawler Excavators export to GHANA FOB price

Views:2021     Author:DRZ     Publish Time: 2016-05-09      Origin:Dong Runze Special Vehicle

China Used Crawler Excavators export to GHANA FOB price

China Used Crawler Excavators export to GHANA FOB price

econd hand EXCAVATOR  GROSS WEIGHT 46000kg NET WEIGHT 46000kgChina Used Crawler Excavators LG6250.jpg

 2016-05-09


 HS

Product name

Specification model

Quantity

Final destination country

Unit price

Total price

Currency

84295212

EXCAVATOR

second hand

CRAWLER | SELF-PROPELLED | SUPERSTRUCTURE CAN BE ROTATED 360 DEGREES | P |LG6210|1.0M3|120KW|21700KG|  second hand VLG06210E06110801|6110801|

1

GHANA

30000

30000

USD

84295212

EXCAVATOR

second hand

CRAWLER | SELF-PROPELLED | SUPERSTRUCTURE CAN BE ROTATED 360 DEGREES | P |LG6250|1.2M3|134KW|24300KG| second hand VLG06250A06120430|6120430|

1

GHANA

40000

40000

USD

China Used Crawler Excavators.jpg

  SDLG LG6210

Specifications
Breakout force SAE / ISO130.4 kN / 147.1 kN
Climbing capacity35
Counterweight clearance1 032 mm
Cylinders (diameter x travel)6 (101 x 126 mm)
Engine modelDalian Deutz BF6M2012
Engine typeFour stroke booster intercooled
Fuel capacity350 L
Ground pressure standard track shoe45.3 kPa
Hydraulic systemDouble pump constant negative flow control
Hydraulic tank295 L
Maximum cutting height9 450 mm
Maximum digging depth6 730 mm
Maximum digging depth (x)6 510 mm (2.44 m level)
Maximum digging reach9 940 mm
Maximum digging reach on ground9 750 mm
Maximum drawbar pull183 kN
Maximum dumping height6 650 mm
Maximum main pump flow200 L/min
Maximum pilot pump flow20 L/min
Maximum torque671 Nm
Maximum vertical wall digging depth5 830 mm
Minimum ground clearance460 mm
Operating pressure330 / 350 kgf/cm2
Overall height of boom2 920 mm
Overall height of cab2 940 mm
Overall height of engine hood2 345 mm
Overall length9 700mm
Overall width2 800 mm
Overall width of upper structure2 700 mm
Rated power120 kW @ 2 000 r/min
Shoe width600 mm
Standard arm length2.9 m
Standard boom length5.7 m
Standard bucket capacity0.9 m3
Standard operating weight20 700 kg
Standard track shoe width600 mm
Tail slew radius2 860 mm
Tearout force SAE / ISO103.0 kN / 104.9 kN
Track gauge2 200 mm
Track length4 170 mm
Travel speed3.2 - 5.5 km/h
Tumbler length3 370 mm


1. Engine: second generation Deutz electric speed control EMR2 intercooled supercharging engine features big torque, low fuel consumption, low emissions and low noise. The SERDIA troubleshooting port and special oil filter and fuel filter are convenient for engine maintenance and repair.

2. Hydraulic system: dual-pump constant power negative flow control hydraulic system with automatic sensing work mode and controllable single pump/double pump feeding work mode.

3. Electric system: SDLG EECU, VECU and IECU control system with GPS enables multiple work modes for different work conditions, featuring energy-saving and high efficiency; color LCD monitor with self-diagnosis, monitoring and emergency alarm functions improve the human-machine interface.

4. Cab: mounted with 3-side sunshade net, ergonomic seat and air conditioner with double stage air filter contribute to a comfortable environment.

5. Undercarriage system: the long crawler and widened chassis with reinforced X-type lower frame improved the stability. Equipped with reinforced boom and arm, the machine is adapted to tougher work conditions.

Technical parameters

Item

Parameter

Item

Parameter

Operatingweight(kg)

24300

 Slewing speed (r/min)

11.3

Standardbucket capacity(m3)

1.2

Travelspeed(low/high)(km/h)

3.3/5.5

Max.digging force(kN)

176

Gradeability (°)

35

Averageground pressure(kPa)

48.5



  • Status:
    sold
  • No:
    6120683
  • Brand:
    SDLG
  • Catagory:
    Excavator
  • Weight:
  • Model :
    LG6250
  • Production Year:
    2011
