Views: 1785 Author: Dong Runze Special Vehicle Publish Time: 2017-06-01 Origin: Dong Runze Special Vehicle
suction sewer scavenger,suction tumbrel tanker,Vacuum tank ,Vacuum tank truck
Cesspool Emptying Truck Tank volume 6000L Unit Price: USD 16100.00 - 18100.00 / Set
Vehicle Model DRZ5090GXEE
Overall dimensions 6900×2285×2780mm Curb weight 4755kg
Tank dimensions 4350×1530×1050mm Tank volume 6000L
Chassis parameters
Chassis model EQ1090T9ADJ3AC Chassis brand DONGFENG
Overall dimensions 6695x2180x2350mm Wheel base 3800mm
Front/rear wheel track 1750/1586mm Front/rear suspension 1180/1715mm
Approach/departure angle 22/13° Maximum speed 80km/h
Chassis Manufacturer Dongfeng Automobile Co.,Ltd
Cab Configuration Single row cab,air conditioner,allowable 3 passengers,cab can be flipped
Color White,other color is optional
Engine Model CY4102-E3C
Emission Euro 3
Type 4 cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling,diesel engine
Rated power 120hp,rated power speed 2800rpm
Displacement 3856ml
Bore x stroke 102x118mm
Manufacturer Dongfeng Chaoyang Diesel Power Co. Ltd.
Tire Size 7.50R16,steel wire tire
Number 6+1 nos
Frame 192mm
Brake Air break, electronic flame out, exhaust brake
Fuel tank 100L,steel
Front axle 2.4T
Rear axle 4.2T
Drive form 4X2
Rated voltage 24V,DC
Transmissions 5 speed forward 1 reverse.
Steering device Power assisted steering
Steering wheel Left hand drive
Selective configuration Air Conditioner, yuchai engine 140hp
If there is a slight change in the chassis parameters above,please take the actual product as the standard
Fecal suction tank
Tank dimensions 4350×1530×1050mm Tank volume 6000L
Tank material Carbon steel Tank thickness 6mm
Color and Logo Optional
Standard configuration Chassis,sub frame,6mm carbon steel fecal tank,6 meters fecal suction pipe, rotating arm, domestic vacuum pump,oil and gas separator, water vapor separator, anti overflow valve, observation tube, gravity flow valve Φ200mm.
Selective configuration Liquid full alarm device, scraper pump.
(Fecal suction truck), mainly applied to the lower septic tanks, sewer and gutter cleaning and other environmental clean-up of special vehicles, and sprinkler, garbage trucks, and known as the three sanitation models. Fecal suction truck is applied to pump manure, sewage, sludge and slurry mixed with small debris. It is widely used to transport and clean septic tank , dredge city pipeline, biogas wastes and other residue in municipal sanitation, industrial and mining enterprises, residential, schools. Its mobility and convinience makes fecal suction truck widely applied all over the world.
Vehicle Model DRZ5060GXEE
Overall dimensions 6000X1940X2600mm Curb weight 3365kg
Tank dimensions 3390×1600×1060mm Tank volume 4000L
Chassis parameters
Chassis model EQ1060TJ20D3 Chassis brand DONGFENG
Overall dimensions 5820x1940x2080mm Wheel base 3300mm
Front/rear wheel track 1506/1466mm Front/rear suspension 1032/1488mm
Approach/departure angle 19/15° Maximum speed 80km/h
Chassis Manufacturer Dongfeng Automobile Co.,Ltd
Cab Configuration Single row cab,allowable 3 passengers
Color White,other color is optional
Engine Model CY4102-C3F
Emission Euro 3
Type in-line,4-stroke,water-cooled,turbo inter-cooling,diesel engine
Rated power 95hp,rated power speed 3200rpm
Displacement 3856ml
Bore x stroke 102x118mm
Manufacturer Dongfeng Chaoyang Diesel Power Co. Ltd.
Tire Size 7.00-16 nylon tire
Number 6+1 nos
Fuel tank 100L,steel
Front axle 2.0T
Rear axle 4.0T
Drive form 4X2
Rated voltage 24V,DC
Transmissions 5 speed forward 1 reverse.
Steering wheel Left hand drive
Selective configuration Air Conditioner,steel wire tire,power assisted steering
If there is a slight change in the chassis parameters above,please take the actual product as the standard
Fecal suction tank
Tank dimensions 3390×1600×1060mm Tank volume 4000L
Tank material Carbon steel Tank thickness 6mm
Color and Logo Optional
Standard configuration Chassis,sub frame,6mm carbon steel fecal tank,6 meters fecal suction pipe, rotating arm, domestic vacuum pump,oil and gas separator, water vapor separator, anti overflow valve, observation tube, gravity flow valve Φ200mm.
Selective configuration Liquid full alarm device, scraper pump.
Fecal suction truck
Here the price is for standard configuration. Selective configuration and any change according to the buyer’s requirements please confirm the price with our company.
Standard configuration | Chassis,sub frame,6mm carbon steel fecal tank,6 meters fecal suction pipe, rotating arm,domestic vacuum pump,oil and gas separator, water vapor separator, anti overflow | |||||||||
valve, observation tube, gravity flow valve Φ200mm. | ||||||||||
Selective configuration | Liquid full alarm device, scraper pump. | |||||||||
Vehicle model | Chassis brand | Chassis model | Load | Overall dimensions | Wheel base | Engine model | hp/standard | Tire | FOB Price | |
L | mm | mm | USD | |||||||
DRZ5160GXED | DONGFENG | DFL1160BX | 10000 | 8400X2470X3150 | 4700 | B190 33 | 190/Euro 3 | 9.00-20 | 25500 | |
DRZ5060GXEE | DONGFENG | EQ1060TJ20D3 | 4000 | 6000X1940X2600 | 3300 | CY4102-C3F | 95/Euro 3 | 7.00-16 | 11650 | |
DRZ5090GXEE | DONGFENG | EQ1090T9ADJ3AC | 6000 | 6900X2285X2780 | 3800 | CY4102-E3C | 120/Euro 3 | 7.50R16 | 15550 | |
DRZ5110GXEE | DONGFENG | EQ1100FKJ | 6000 | 7165X2470X2900 | 3950 | YC4E140-33 | 140/Euro 3 | 9.00-20 | 15770 | |
DRZ5108GXEE | DONGFENG | EQ1108KJ | 8000 | 7450X2470X2900 | 3950 | B170 33 | 170/Euro 3 | 9.00-20 | 19020 | |
DRZ5126GXEE | DONGFENG | EQ1126KJ1 | 10000 | 8400X2470X3150 | 4700 | B190 33 | 190/Euro 3 | 9.00-20 | 21080 | |
DRZ5141GXEE | DONGFENG | EQ1141KJ | 10000 | 7800X2470X3150 | 4500 | B190 33 | 190/Euro 3 | 10.00-20 | 20780 | |
DRZ5073GXEB | FOTON | BJ1073VEJEA-A | 4000 | 5990X1955X2500 | 3360 | 4DW91-63NG2 | 98/Euro 2 | 6.50-16 | 10170 | |
DRZ5102GXEYB | FOTON | BJ1102VDPEA-G1 | 6000 | 7175X2300X2860 | 3900 | 4102QBZL | 130/Euro 2 | 8.25-16 | 15110 | |
DRZ5163GXEB | FOTON | BJ1163VKPGG-1 | 12000 | 9000X2490X2900 | 5000 | Phaser160Ti-33 | 160/Euro 3 | 9.00R20 | 24330 | |
DRZ50503GXEQ | ISUZU | QL10503HARY | 4000 | 5980X1880X2350 | 3360 | 4JB1CN | 98/Euro 4 | 7.00-15 | 18950 | |
DRZ5161GXEH | JAC | HFC1161P3K2A47F | 10000 | 8180X2350X2950 | 4700 | YC4E160-42 | 160/Euro 4 | 11.00R20 | 29640 |
