professional bus factory, could customize the bus according to user's request engineering van off-road bus
Dimensions | |
Overall Length | 6900 mm |
Overall Width | 2330 mm |
Overall Height | 2760 mm |
Overall Height with AC | 3040 mm |
Wheelbase |
|
Front Overhang | 1280 mm |
Rear Overhang | 1720 mm |
Interior Height | 1700 mm |
First Step Height | 550 mm |
Gross Vehicle Weight |
|
Curb Weight | |
Max Speed | 95 km/h |
Seats Capacity | 7-16 |
Cargo Dimension Inside Gate | 1800*2140*600 mm |
|
professional bus factory, could customize the bus according to user's request engineering van off-road bus
Dimensions | |
Overall Length | 6900 mm |
Overall Width | 2330 mm |
Overall Height | 2760 mm |
Overall Height with AC | 3040 mm |
Wheelbase |
|
Front Overhang | 1280 mm |
Rear Overhang | 1720 mm |
Interior Height | 1700 mm |
First Step Height | 550 mm |
Gross Vehicle Weight |
|
Curb Weight | |
Max Speed | 95 km/h |
Seats Capacity | 7-16 |
Cargo Dimension Inside Gate | 1800*2140*600 mm |
|
Engine | ||
Brand | DONGFENG CUMMINS | |
Fuel | Diesel | |
Model | ISDE140-30 | |
Location | Front engined | |
No. of Cylinders | 4 | |
Type | in-line, 4 strokes, water-cooled; | |
Air Intake Type | turbo-charged inter- cooler | |
Max.output (kw) | 103 | |
Max.Torque (N.m) | 450 | |
Displacement (ml) | 4500 | |
Fuel Capacity (L) | 150L | |
Emission Standard | Euro III |
Dimensions | |
Overall Length | 6300 mm |
Overall Width | 2330 mm |
Overall Height | 2760 mm |
Overall Height with AC | 3040 mm |
Wheelbase | 3300 mm |
Front Overhang | 1280 mm |
Rear Overhang | 1720 mm |
Interior Height | 1700 mm |
First Step Height | 550 mm |
Gross Vehicle Weight | 7800 kg |
Curb Weight | |
Max Speed | 95 km/h |
Seats Capacity | 7-12 |
Cargo Dimension Inside Gate | 1800*2140*600 mm |
|
Chassis | |||
Chassis Model | EQ6590KST | ||
Gear Box | Manual , 5 speed, | ||
Clutch | Single plate, dry friction, diaphragm spring | ||
Front Axle | Dongfeng Axle 3T | ||
Rear Axles | Dongfeng Axle 5T | ||
Suspension | leaf spring type 10/10 | ||
solid axle , with telescopic shock absorber | |||
Steering | Mechanical,power steering | ||
Brake | Dual circuit full air brake, central drum brake | ||
Spring actuated parking brake | |||
Tyres | 7.50R16; front 2, rear 4; | ||
Battery/Alternator | 6-QW-120DF/ 70A, (90A for A/C) | ||
Others | Copper radiator; Clutch booster; | ||
Engine exhaust brake; Air dryer; | |||
Engine preheating device; | |||
Optional: | Automatic brake gap adjustment arm; | ||
ABS; | |||
HVAC | |||
Satndard | Driver's fan | ||
Optional | Dongfeng Pannico top-mounted A/C (14.45KW) | ||
Dongfeng Pannico top-mounted A/C (4KW) | |||
Water heating system; Independent fuel heater; | |||
Radio & Video | |||
Satndard | Mp3 and radio player with USB Interfaces | ||
Optional | Mp4/Mp5 video system; | ||
15-inch/17-inch manual foldable color LCD |
chassis 2.
Chassis
Chassis | |||
Chassis Model | EQ6670KST | ||
Gear Box | Manual , 5 speed, | ||
Clutch | Single plate, dry friction, diaphragm spring | ||
Front Axle | Dongfeng Axle 3T | ||
Rear Axles | Dongfeng Axle 5T | ||
Suspension | leaf spring type 10/10 | ||
solid axle , with telescopic shock absorber | |||
Steering | Mechanical,power steering | ||
Brake | Dual circuit full air brake, central drum brake | ||
Spring actuated parking brake | |||
Tyres | 11R18 ; front 2, rear 2; | ||
Battery/Alternator | 6-QW-120DF/ 70A, (90A for A/C) | ||
Others | Copper radiator; Clutch booster; | ||
Engine exhaust brake; Air dryer; | |||
Engine preheating device; | |||
Optional: | Automatic brake gap adjustment arm; | ||
ABS; | |||
HVAC | |||
Satndard | Driver's fan | ||
Optional | Dongfeng Pannico top-mounted A/C (14.45KW) | ||
Dongfeng Pannico top-mounted A/C (4KW) | |||
Water heating system; Independent fuel heater; | |||
Radio & Video | |||
Satndard | Mp3 and radio player with USB Interfaces | ||
Optional | Mp4/Mp5 video system; | ||
15-inch/17-inch manual foldable color LCD |
Engine | ||
Brand | DONGFENG CUMMINS | |
Fuel | Diesel | |
Model | ISDE140-30 | |
Location | Front engined | |
No. of Cylinders | 4 | |
Type | in-line, 4 strokes, water-cooled; | |
Air Intake Type | turbo-charged inter- cooler | |
Max.output (kw) | 103 | |
Max.Torque (N.m) | 450 | |
Displacement (ml) | 4500 | |
Fuel Capacity (L) | 150L | |
Emission Standard | Euro III |
Dimensions | |
Overall Length | 6300 mm |
Overall Width | 2330 mm |
Overall Height | 2760 mm |
Overall Height with AC | 3040 mm |
Wheelbase | 3300 mm |
Front Overhang | 1280 mm |
Rear Overhang | 1720 mm |
Interior Height | 1700 mm |
First Step Height | 550 mm |
Gross Vehicle Weight | 7800 kg |
Curb Weight | |
Max Speed | 95 km/h |
Seats Capacity | 7-12 |
Cargo Dimension Inside Gate | 1800*2140*600 mm |
|
Chassis | |||
Chassis Model | EQ6590KST | ||
Gear Box | Manual , 5 speed, | ||
Clutch | Single plate, dry friction, diaphragm spring | ||
Front Axle | Dongfeng Axle 3T | ||
Rear Axles | Dongfeng Axle 5T | ||
Suspension | leaf spring type 10/10 | ||
solid axle , with telescopic shock absorber | |||
Steering | Mechanical,power steering | ||
Brake | Dual circuit full air brake, central drum brake | ||
Spring actuated parking brake | |||
Tyres | 7.50R16; front 2, rear 4; | ||
Battery/Alternator | 6-QW-120DF/ 70A, (90A for A/C) | ||
Others | Copper radiator; Clutch booster; | ||
Engine exhaust brake; Air dryer; | |||
Engine preheating device; | |||
Optional: | Automatic brake gap adjustment arm; | ||
ABS; | |||
HVAC | |||
Satndard | Driver's fan | ||
Optional | Dongfeng Pannico top-mounted A/C (14.45KW) | ||
Dongfeng Pannico top-mounted A/C (4KW) | |||
Water heating system; Independent fuel heater; | |||
Radio & Video | |||
Satndard | Mp3 and radio player with USB Interfaces | ||
Optional | Mp4/Mp5 video system; | ||
15-inch/17-inch manual foldable color LCD |
chassis 2.
Chassis
Chassis | |||
Chassis Model | EQ6670KST | ||
Gear Box | Manual , 5 speed, | ||
Clutch | Single plate, dry friction, diaphragm spring | ||
Front Axle | Dongfeng Axle 3T | ||
Rear Axles | Dongfeng Axle 5T | ||
Suspension | leaf spring type 10/10 | ||
solid axle , with telescopic shock absorber | |||
Steering | Mechanical,power steering | ||
Brake | Dual circuit full air brake, central drum brake | ||
Spring actuated parking brake | |||
Tyres | 11R18 ; front 2, rear 2; | ||
Battery/Alternator | 6-QW-120DF/ 70A, (90A for A/C) | ||
Others | Copper radiator; Clutch booster; | ||
Engine exhaust brake; Air dryer; | |||
Engine preheating device; | |||
Optional: | Automatic brake gap adjustment arm; | ||
ABS; | |||
HVAC | |||
Satndard | Driver's fan | ||
Optional | Dongfeng Pannico top-mounted A/C (14.45KW) | ||
Dongfeng Pannico top-mounted A/C (4KW) | |||
Water heating system; Independent fuel heater; | |||
Radio & Video | |||
Satndard | Mp3 and radio player with USB Interfaces | ||
Optional | Mp4/Mp5 video system; | ||
15-inch/17-inch manual foldable color LCD |
